▶ EngineEngine Manufacturer Daedong YANMAR Engine Model Not Published 4TNV98C Engine Type Turbo-charged, indirect injection 4-cylinder, naturally aspirated diesel No. of Cylinders 4 4 Displacement 148.6 in³ 202.5 in³ Rated Engine Speed 2600 rpm 2500 rpm Engine Power (Gross) 59 hp 58.9 hp PTO Power 48.5 hp 52 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Not Published Liquid cooled Air Cleaner Not Published Dual stage cyclonic (resin 6.5") Fuel System Not Published Common rail direct injection Alternator 50 A, 12 V 55 A, 12 V ▶ HydraulicsPump Type Not Published Not Published Implement Flow 11 gpm 9.4 gpm Steering Flow 5.4 gpm 5.3 gpm Total Hydraulic Flow Not Published 14.7 gpm (9.4 + 5.3, computed) Overall Hydraulic Pump Flow Not Published 14.7 gpm (9.4 + 5.3, computed) Hydraulic System Type Open Center with position and draft control Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 1 2 No. of Optional Remote Valves 3 1 ▶ Fluid CapacityFuel Tank Capacity 18.5 gal 12.7 gal Coolant Capacity Not Published 7.8 qt Crankcase Capacity Not Published 8.0 qt Transmission / Hydraulic System Capacity Not Published 7.7 gal Front Axle Fluid Capacity Not Published 2.4 gal ▶ PTO & HitchPTO Type Independent Independent (electro-hydraulic) PTO Rear 540 rpm @ 2600 rpm 540 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category 2, with telescopic check chains Category I Hitch Lift Capacity 3527 lb 3,307 lb Hitch Lift Capacity (at 24”) Not Published 2,756 lb Lift Control Type Position and draft control Position control ▶ Transmission & DrivetrainTransmission Type Sync, shuttle w/ part synchromesh I-HMT (Integrated Hydro Mechanical Transmission) No. of Speeds 12F / 12R 3 ranges (variable speed) Max Travel Speed (Forward) 20.0 mph 18 mph (with R1 tires) Max Travel Speed (Reverse) 20.5 mph 18 mph (with R1 tires) Clutch Single plate, dry Clutch-less shifting (i-HMT) Differential Lock & Limited Slip Options Not Published Rear differential lock (foot pedal engagement) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic/Tiltable Fully hydraulic power steering Brakes Wet Disc Mechanical wet disc Seat Suspension & Adjustability Not Published Not Published Front Axle Type Not Published 2WD/4WD selectable engagement Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 141.3 in 132.1 in Overall Width 71.5 in 70.6 in (with R4 tires) Wheelbase Not Published 77.4 in Ground Clearance Not Published 12.8 in (with R4 tires) Min. Turn Radius without Brakes 12.5 ft Not Published Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 99.2 in 89.5 in (with R4 tires) ▶ WeightTractor Weight (Base) 4850 lb 4,442 lb (cab, R4 tires, full fluid) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published 5,538 lb ▶ Tire OptionsTire Size & Options Not Published R1 Agricultural; R3 Turf; R4 Industrial R1 Agricultural - Front 9.5x20 8-16 R1 Agricultural - Rear 14.9x28 14.9-24 R3 Turf - Front LSW305-521 27x10.5-15 R3 Turf - Rear LSW570-648 44x18-20 R4 Industrial - Front 10.5/80x18 10-16.5 R4 Industrial - Rear 18.4x24 17.5L-24 ▶ Loader & AttachmentsQuick Attach Loader System Not Published YL610: Skid-steer-style loader quick attachment system Loader Model ML161 YL610 Loader Lift Height ML161: 115.4 in YL610: 113 in (to bucket pivot pin) Loader Lift Capacity (Full Height) ML161: 3122 lb YL610: 2,500 lb at pivot pins Loader Breakout Force ML161: 5225 lb YL610: 3,969 lb at pivot pins ▶ WarrantyWarranty Length & Coverage Not Published Tractor: 24 months or 2,000 hours; Powertrain: 10 years or 3,000 hours; Attachments: 1-year limited warranty
