▶ EngineEngine Manufacturer Mahindra John Deere Engine Model Not Published PowerTech 4045 (4.5L) PWL Engine Type Four-stroke, turbocharged, direct injection, water-cooled diesel 4-cylinder, turbocharged and aftercooled diesel, electronic fuel control No. of Cylinders 4 4 Displacement 215.4 in³ 276 in³ Rated Engine Speed 2300 rpm 2400 rpm Engine Power (Gross) 91.5 hp 90 hp PTO Power 75 hp 76.7 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Water-cooled Liquid-cooled Air Cleaner Not Published Dry type with safety element Fuel System Common rail direct injection High pressure common rail, electronic fuel control Alternator 140 A OOS: 90 A; Cab: 120 A ▶ HydraulicsPump Type Not Published Tandem gear pump, two engine-mounted pumps Implement Flow 17 gpm 15.9 gpm Steering Flow 5.2 gpm 6.6 gpm Total Hydraulic Flow 22.2 gpm 22.5 gpm Overall Hydraulic Pump Flow 22.2 gpm 22.5 gpm Hydraulic System Type Open center with position and draft control Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 2 rear; 0 mid No. of Optional Remote Valves 3rd valve optional 3 rear; up to 3 mid ▶ Fluid CapacityFuel Tank Capacity 25.9 gal 25 gal (open operator station); 30 gal (cab) Coolant Capacity Not Published 2.5 gal (open operator station); 3 gal (cab) Crankcase Capacity Not Published 3.2 gal Transmission / Hydraulic System Capacity Not Published 11.5 gal Front Axle Fluid Capacity Not Published 1.3 gal (MFWD differential housing); 0.74 qt (each wheel hub) ▶ PTO & HitchPTO Type 2-speed independent single lever PTO Independent, electro-hydraulic engagement, wet PTO clutch PTO Rear 540/1000 rpm 540/540E standard; 540/1000 optional Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch CAT II with telescoping stabilizers & flex links Category 2, convertible to Category 1 Hitch Lift Capacity 5,500 lb 5,159 lb (maximum lift force at hitch ball); 3,846 lb throughout lift range Hitch Lift Capacity (at 24”) Not Published 4,630 lb (electrohydraulic hitch) Lift Control Type Position and draft control Electro-hydraulic hitch with electronic quick raise and lower (premium cab); top-link draft sensing ▶ Transmission & DrivetrainTransmission Type Full synchro mesh with forward/reverse power shuttle and constant-mesh range PowrReverser 12F/12R standard; PowrReverser Hi-Lo 24F/12R optional No. of Speeds 12F / 12R 12 forward, 12 reverse (standard); 24 forward, 12 reverse (Hi-Lo) Max Travel Speed (Forward) Not Published 21.7 mph (electronically limited) Max Travel Speed (Reverse) Not Published 21.7 mph (electronically limited) Clutch Power shuttle with torsional damper (wet) Wet Differential Lock & Limited Slip Options Not Published Rear differential lock ▶ Chassis, Steering & ControlsFrame Type Steel frame Foldable ROPS (open operator station); standard or premium cab; MFWD Steering Power steering Hydrostatic power steering Brakes Oil-immersed brakes, 7-in disc, mechanically actuated Hydraulic wet disc, self-equalizing and self-adjusting, dual-stage Seat Suspension & Adjustability Seat with integrated folding armrests, recline, and air-suspension standard Mechanical seat standard; air-suspension seat optional for cab Front Axle Type Not Published MFWD Front Axle Rating Not Published 6,615 lb Drawbar Capacity Not Published 2,755 lb (standard drawbar, 9.8 in extended); 2,425 lb (standard drawbar, 350 and 15.7 in extended); 3,195 lb (heavy-duty drawbar, 9.8 in extended); 2,645 lb (heavy-duty drawbar, 350 and 15.7 in extended) ▶ Dimensions & ManeuverabilityOverall Width 83 in 83.6 in (minimum, 16.9-30 R1 tires); 85.1 in (minimum, 18.4-30 R1 tires) Wheelbase 95.6 in 92.5 in Ground Clearance 14.1 in 17 in (front axle) Min. Turn Radius without Brakes 15.5 ft 11.6 ft (MFWD) Height to Top of ROPS Not Published 101.1 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 111.2 in 102.4 in Overall Length 176.6 in 159.13 in ▶ WeightTractor Weight (Base) 8,587 lb 7,275 lb (MFWD open operator station, shipping weight); 8,150 lb (MFWD cab, shipping weight) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published 18.4-30 R1 bias rear standard; 16.9-30 R1 also listed R1 Agricultural - Front 12.4 x 24 12.4-24 R1 Agricultural - Rear 18.4 x 30 18.4-30 R1 bias R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Skid steer style quick attach Quick attach option with integrated parking stand Loader Model 8100CL 520M (NSL and MSL); 540M (NSL) Loader Lift Height 8100CL: 139 in 520M MSL: 132.0 in Loader Lift Capacity (Full Height) 8100CL: 4,200 lb (at pivot pin) 520M MSL: 2,606 lb (to maximum height, measured at pivot) Loader Breakout Force 8100CL: 6,050 lb 520M NSL: 4,511 lbf; 520M MSL: 4,793 lbf (at pivot point) ▶ WarrantyWarranty Length & Coverage Not Published Powertrain 5 years or 2,000 hours, as sold new
