▶ EngineEngine Manufacturer Mahindra KIOTI Engine Model Not Published 4J243TA-TP5B Engine Type Four-stroke, turbocharged, direct injection, water-cooled diesel 4-cylinder, in-line vertical, water-cooled, turbocharged and intercooled CRDI diesel (4J243TA-TP5B) No. of Cylinders 4 4 Displacement 215.4 in³ 233.9 in³ Rated Engine Speed 2300 rpm 2200 rpm Engine Power (Gross) 91.5 hp 90 hp PTO Power 75 hp 70 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Water-cooled Water-cooled Air Cleaner Not Published Dry element with evacuator valve Fuel System Common rail direct injection CRDI Alternator 140 A Not Published ▶ HydraulicsPump Type Not Published Gear Implement Flow 17 gpm 19.8 gpm Steering Flow 5.2 gpm 12.2 gpm Total Hydraulic Flow 22.2 gpm 32 gpm Overall Hydraulic Pump Flow 22.2 gpm 32 gpm Hydraulic System Type Open center with position and draft control Open Center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 3 No. of Optional Remote Valves 3rd valve optional 4th remote valve ▶ Fluid CapacityFuel Tank Capacity 25.9 gal 47.6 gal Coolant Capacity Not Published 4.6 gal Crankcase Capacity Not Published 3.9 gal Transmission / Hydraulic System Capacity Not Published 20.34 gal Front Axle Fluid Capacity Not Published 2.6 gal ▶ PTO & HitchPTO Type 2-speed independent single lever PTO Independent PTO Rear 540/1000 rpm 540 / 540E / 1000 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch CAT II with telescoping stabilizers & flex links Category II Hitch Lift Capacity 5,500 lb 8,079 lb Hitch Lift Capacity (at 24”) Not Published 8,002 lb Lift Control Type Position and draft control Electronic control ▶ Transmission & DrivetrainTransmission Type Full synchro mesh with forward/reverse power shuttle and constant-mesh range Power Shuttle w/ Hi-Lo Shift No. of Speeds 12F / 12R 24 forward / 24 reverse Max Travel Speed (Forward) Not Published 23.83 mph Max Travel Speed (Reverse) Not Published 23.67 mph Clutch Power shuttle with torsional damper (wet) Wet Multi Disc Differential Lock & Limited Slip Options Not Published Mechanical rear differential lock (standard); front limited-slip differential ▶ Chassis, Steering & ControlsFrame Type Steel frame Not Published Steering Power steering Hydrostatic Power Steering Brakes Oil-immersed brakes, 7-in disc, mechanically actuated Wet Disc Seat Suspension & Adjustability Seat with integrated folding armrests, recline, and air-suspension standard Heated air suspension seat, 20 degree swivel both directions, adjustable fore/aft Front Axle Type Not Published 4WD, outboard planetary drives, limited-slip differential Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Max. Drawbar vertical load: 3,307 lb; Max. Trailer loading weight: 9,921 lb ▶ Dimensions & ManeuverabilityOverall Width 83 in 88.6 in Wheelbase 95.6 in 94.9 in Ground Clearance 14.1 in 18.9 in Min. Turn Radius without Brakes 15.5 ft 12.7 ft (with brake applied) Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 111.2 in 111.9 in Overall Length 176.6 in 170.8 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 8,587 lb 10,230 lb (with AG tires) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published R1 Agricultural (bias 13.6-24 / 18.4-34, radial 13.6R-24 / 18.4R-34); R14 radial (340/85R24 / 460/85R34) R1 Agricultural - Front 12.4 x 24 13.6-24 R1 Agricultural - Rear 18.4 x 30 18.4-34 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Skid steer style quick attach KL1155: quick-attach system with built-in parking stand; single-lever joystick control with float; bucket level indicator Loader Model 8100CL KL1155 Loader Lift Height 8100CL: 139 in KL1155: 150.6 in (to pivot pin) Loader Lift Capacity (Full Height) 8100CL: 4,200 lb (at pivot pin) KL1155: 4,216 lb (at pivot pins) Loader Breakout Force 8100CL: 6,050 lb KL1155: 8,554 lb (at pivot pins) ▶ WarrantyWarranty Length & Coverage Not Published Non-commercial: basic 24 months, unlimited hours, parts and labor, 0% deductible; powertrain 48 months, unlimited hours, HX series
