▶ EngineEngine Manufacturer Mahindra Kubota Engine Model Not Published V3800CR-TIEF4 Engine Type Four-stroke, turbocharged, direct injection, water-cooled diesel 4-cylinder, turbocharged and intercooled, common-rail diesel, DPF, DOC and SCR No. of Cylinders 4 4 Displacement 215.4 in³ 230 in³ Rated Engine Speed 2300 rpm 2400 rpm Engine Power (Gross) 91.5 hp 92.5 hp PTO Power 75 hp 76 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Water-cooled Liquid-cooled Air Cleaner Not Published Dry paper, dual element, 8 in diameter, with pre-cleaner Fuel System Common rail direct injection Common rail direct injection Alternator 140 A 60 A ▶ HydraulicsPump Type Not Published Gear pump Implement Flow 17 gpm 15.9 gpm Steering Flow 5.2 gpm 5.4 gpm Total Hydraulic Flow 22.2 gpm 21.3 gpm Overall Hydraulic Pump Flow 22.2 gpm 21.3 gpm Hydraulic System Type Open center with position and draft control Open center Rear Remote Hydraulic Flow Not Published 15.7 gpm No. of Standard Remote Valves 2 2 standard (3 maximum) No. of Optional Remote Valves 3rd valve optional Not Published ▶ Fluid CapacityFuel Tank Capacity 25.9 gal 27.7 gal Coolant Capacity Not Published 11 qt Crankcase Capacity Not Published 11.3 qt Transmission / Hydraulic System Capacity Not Published 63.4 qt Front Axle Fluid Capacity Not Published 6.3 qt (differential) plus 3.7 qt (each bevel gear case) ▶ PTO & HitchPTO Type 2-speed independent single lever PTO Live-independent PTO, electro-hydraulic clutch with brake PTO Rear 540/1000 rpm 540 rpm (540/540E on 12-speed models) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch CAT II with telescoping stabilizers & flex links Category II Hitch Lift Capacity 5,500 lb 7,055 lb Hitch Lift Capacity (at 24”) Not Published 4,630 lb (8-speed); 6,063 lb (12-speed) Lift Control Type Position and draft control Position, draft (top link sensing) and mixed control ▶ Transmission & DrivetrainTransmission Type Full synchro mesh with forward/reverse power shuttle and constant-mesh range Fully synchronized main gear shift with electro-hydraulic shuttle No. of Speeds 12F / 12R 8 forward, 8 reverse (8-speed models); 12 forward, 12 reverse (12-speed models) Max Travel Speed (Forward) Not Published 17.7 mph (8-speed); 22.6 mph (12-speed) Max Travel Speed (Reverse) Not Published 8-speed: 18.4 mph; 12-speed: 23.5 mph Clutch Power shuttle with torsional damper (wet) Multiple wet disc Differential Lock & Limited Slip Options Not Published Front: limited-slip differential; Rear: mechanical differential lock ▶ Chassis, Steering & ControlsFrame Type Steel frame Not Published Steering Power steering Hydrostatic power steering Brakes Oil-immersed brakes, 7-in disc, mechanically actuated Hydraulic wet disc Seat Suspension & Adjustability Seat with integrated folding armrests, recline, and air-suspension standard Suspension seat with fore and aft travel adjustment, suspension tension knob, backrest tilt adjustment and arm rest Front Axle Type Not Published Bevel gear type with 55 degree turning angle (4WD) Front Axle Rating Not Published 5,730 lb Drawbar Capacity Not Published 3,300 lb ▶ Dimensions & ManeuverabilityOverall Width 83 in 78.3 in Wheelbase 95.6 in 88.6 in Ground Clearance 14.1 in 17.7 in (minimum, drawbar bracket) Min. Turn Radius without Brakes 15.5 ft 13.8 ft Height to Top of ROPS Not Published 98.9 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 111.2 in Not Applicable Overall Length 176.6 in 155.9 in ▶ WeightTractor Weight (Base) 8,587 lb 6,151 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published Front: 7.50-18, 9.5L-15, 9.5-22, 10.00-16, 11.2-24, 12.4-24; Rear: 16.9-30, 16.9-34, 18.4-30 R1 Agricultural - Front 12.4 x 24 11.2-24 R1 Agricultural - Rear 18.4 x 30 18.4-30 R3 Turf - Front Not Published 9.5L-15 F2 or 27x9.50-15 HF-1 (rib fronts paired with the R3 rears) R3 Turf - Rear Not Published 18.4-26 R3 or 19.5L-24 R3 R4 Industrial - Front Not Published 9.5L-15 F2 (rib front paired with the R4 rear) R4 Industrial - Rear Not Published 19.5L-24 R4 ▶ Loader & AttachmentsQuick Attach Loader System Skid steer style quick attach Quick coupler, standard; Euro-type quick coupler, optional; tool-free attach and detach; single-lever hydraulic hose coupler, optional Loader Model 8100CL LA1854 Loader Lift Height 8100CL: 139 in 145.7 in (height position); 131.9 in (power position) Loader Lift Capacity (Full Height) 8100CL: 4,200 lb (at pivot pin) 3,990 lb (height position); 4,144 lb (power position) Loader Breakout Force 8100CL: 6,050 lb LA1854: 5,501 lb at bucket pivot pin (height position); 6,470 lb at bucket pivot pin (power position) ▶ WarrantyWarranty Length & Coverage Not Published Basic 24 months or 2,000 hours, powertrain 36 months or 3,000 hours
