▶ EngineEngine Manufacturer Mahindra John Deere Engine Model NE 479 TCI PowerTech 4045 PWL Engine Type Four Stroke, Turbo Charged, Intercooled, Direct Injection, Water Cooled Diesel Engine Diesel, turbocharged, air-to-air aftercooled No. of Cylinders 4 4 Displacement 203.2 in³ 276 in³ Rated Engine Speed 2300 rpm 2200 rpm Engine Power (Gross) 83 hp 89.2 hp PTO Power 70 hp 75 hp @ 100 rpm Engine Emissions Constraints Tier 3 Tier 4 Cooling System Type Not Published Liquid-cooled (Cool-Gard II coolant) Air Cleaner Dry type with safety cartridge & dust unloader valve Dry air cleaner, primary and secondary elements Fuel System Rotary FIP with KSB Unit MICO (BOSCH) High Pressure Common Rail (HPCR) electronic fuel injection Alternator 55 A, 12 V OOS: 90 A; Cab: 120 A; Field-installed option: 200 A, 12 V ▶ HydraulicsPump Type Independent fully 'live' hydraulic pump Tandem gear pump Implement Flow 17 gpm 18.4 gpm Steering Flow 5.3 gpm 6.3 gpm Total Hydraulic Flow 22.3 gpm 24.7 gpm Overall Hydraulic Pump Flow Not Published 24.7 gpm Hydraulic System Type Independent fully live hydraulic pump with Vary-Touch draft and position controls Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 2 (rear, Dual SCV) No. of Optional Remote Valves Not Published Up to 1 additional rear (3 total, Deluxe Triple SCV); mid SCVs up to 3 (XI, XII, XIII) for loader functions ▶ Fluid CapacityFuel Tank Capacity 19.28 gal OOS: 29.6 gal; OOS (High Capacity): 37.2 gal; Cab: 37 gal; Cab (High Capacity): 44.9 gal Coolant Capacity 2.58 gal OOS: 5.2 gal; Cab: 5.8 gal Crankcase Capacity 9.48 qt 3.4 gal Transmission / Hydraulic System Capacity 8.59 gal 10.4 gal Front Axle Fluid Capacity 1.79 gal Differential housing (MFWD): 1.3 gal; Wheel hub (each): 0.2 gal ▶ PTO & HitchPTO Type Rear independent PTO shaft Independent rear PTO (electro-hydraulic wet disc clutch): 540/540E standard; 540/540E/1000 optional PTO Rear Not Published 540/540E rpm standard; 1000 rpm optional Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II ball joints with adjustable outside lateral stabilizer Category II (convertible to I) Hitch Lift Capacity 5500 lb 5,305 lb standard; 6,114 lb optional Hitch Lift Capacity (at 24”) 3850 lb 5,159 lb standard; 5,954 lb optional Lift Control Type Position and draft control Mechanical or electrohydraulic (draft control) ▶ Transmission & DrivetrainTransmission Type Not Published PowrReverser 16F/16R (base); optional 32F/16R PowrReverser Hi-Lo or 12F/4R SyncShuttle Plus No. of Speeds 12F / 12R 16F/16R (standard PowrReverser); 12F/4R (optional SyncShuttle Plus); 32F/16R (optional PowrReverser Hi-Lo) Max Travel Speed (Forward) Not Published 16F/16R PowrReverser, top gear (D-4): 30K config: 18.6 mph; 40K config: 21.7 mph Max Travel Speed (Reverse) Not Published 16F/16R PowrReverser, top gear (D-4): 30K config: 20.5 mph; 40K config: 23.9 mph Clutch Dry Dual Clutch (normally disengaged PTO clutch) Wet Differential Lock & Limited Slip Options Not Published Electro-hydraulic rear differential lock, engage on the go ▶ Chassis, Steering & ControlsFrame Type Not Published Cast iron mid-frame Steering Hydrostatic (Power Steering) Not Published Brakes Oil immersed, foot operated, independent with interlock for simultaneous operation; hand brake for parking Not Published Seat Suspension & Adjustability Not Published OOS: isolated mechanical seat standard (fore/aft, weight, lumbar adjust) or air suspension seat optional; Cab: mechanical seat standard or air suspension seat optional; adjustable weight range 88-330 lb Front Axle Type Not Published MFWD Front Axle Rating Not Published 6,613 lb (MFWD, max permissible front axle load) Drawbar Capacity Not Published Standard drawbar: 2,756 lb; 2,425 lb; 2,205 lb. Heavy-duty drawbar: 3,197 lb; 2,646 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 162.04 in 149.5 in Overall Width 77.3 in Cab, with fender extension: 85.6 in; Cab, without fender extension: 74.0 in; OOS, with fender extension: 69.1 in; OOS, without fender extension: 51.7 in Wheelbase 2WD: 85.31 in; 4WD: 85.8 in 92.5 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes 2WD: 157 in; 4WD: 180 in Not Published Height to Top of ROPS 2WD: 89.5 in; 4WD: 94.5 in 102.1 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published 102.9 in ▶ WeightTractor Weight (Base) 2WD: 6878 lb; 4WD: 7297 lb 2WD, OOS: 8,140 lb; 2WD, Cab: 8,580 lb; MFWD, OOS: 8,765 lb; MFWD, Cab: 9,185 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published Not Published R1 Agricultural - Front Not Published 12.4R24 (320/85R24) R1W Radial R1 Agricultural - Rear Not Published 18.4R30 (460/85R30) R1W Radial R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Not Published Not Published Loader Model Not Published 540M NSL; 540M SL; 540R NSL; 540R SL; H310 NSL (MFWD required for H310) Loader Lift Height Not Published 540M NSL: 138 in; 540M SL: 138 in; 540R NSL: 141 in; 540R SL: 141 in; H310 NSL: 149 in Loader Lift Capacity (Full Height) Not Published 540M NSL: 3,674 lb; 540M SL: 3,058 lb; 540R NSL: 4,246 lb; 540R SL: 3,395 lb; H310 NSL: 4,644 lb (measured at pivot) Loader Breakout Force Not Published 540M NSL: 6,686 lbf; 540M SL: 5,513 lbf; 540R NSL: 4,945 lbf; 540R SL: 5,291 lbf; H310 NSL: 6,767 lbf (measured at pivot) ▶ WarrantyWarranty Length & Coverage Not Published 24 Months or 2000 Hours, Whichever Comes First (whole-machine, standard Agricultural Equipment tractor term)
