▶ EngineEngine Manufacturer Mahindra Mahindra Engine Model NE 479 TCI Not Published Engine Type Four Stroke, Turbo Charged, Intercooled, Direct Injection, Water Cooled Diesel Engine Four stroke, direct injection, turbo-charged and intercooled diesel No. of Cylinders 4 3 Displacement 203.2 in³ 161.5 in³ Rated Engine Speed 2300 rpm 2300 rpm Engine Power (Gross) 83 hp 65 hp PTO Power 70 hp 50 hp Engine Emissions Constraints Tier 3 Tier 4 Cooling System Type Not Published Liquid-cooled Air Cleaner Dry type with safety cartridge & dust unloader valve Not Published Fuel System Rotary FIP with KSB Unit MICO (BOSCH) Direct injection, turbocharged and intercooled (mCRD common rail) Alternator 55 A, 12 V 90 A, 12 V ▶ HydraulicsPump Type Independent fully 'live' hydraulic pump Not Published Implement Flow 17 gpm 11 gpm Steering Flow 5.3 gpm 5.4 gpm Total Hydraulic Flow 22.3 gpm 16.4 gpm (11 + 5.4, computed) Overall Hydraulic Pump Flow Not Published Not Published Hydraulic System Type Independent fully live hydraulic pump with Vary-Touch draft and position controls Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 1 No. of Optional Remote Valves Not Published Not Published ▶ Fluid CapacityFuel Tank Capacity 19.28 gal 16 gal Coolant Capacity 2.58 gal Not Published Crankcase Capacity 9.48 qt Not Published Transmission / Hydraulic System Capacity 8.59 gal Not Published Front Axle Fluid Capacity 1.79 gal Not Published ▶ PTO & HitchPTO Type Rear independent PTO shaft Independent PTO Rear Not Published 540 rpm @ 2300 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II ball joints with adjustable outside lateral stabilizer CAT II with telescoping stabilizers and flex link ends Hitch Lift Capacity 5500 lb 3527 lb Hitch Lift Capacity (at 24”) 3850 lb Not Published Lift Control Type Position and draft control Position and draft control ▶ Transmission & DrivetrainTransmission Type Not Published Synchro shuttle with partial synchromesh No. of Speeds 12F / 12R 12F/12R Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Dry Dual Clutch (normally disengaged PTO clutch) Single plate, dry Differential Lock & Limited Slip Options Not Published Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic (Power Steering) Hydrostatic power steering, tilt Brakes Oil immersed, foot operated, independent with interlock for simultaneous operation; hand brake for parking Wet disc Seat Suspension & Adjustability Not Published Adjustable suspension seat Front Axle Type Not Published Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 162.04 in 142 in Overall Width 77.3 in 71.5 in Wheelbase 2WD: 85.31 in; 4WD: 85.8 in Not Published Ground Clearance Not Published Not Published Min. Turn Radius without Brakes 2WD: 157 in; 4WD: 180 in 12.5 ft Height to Top of ROPS 2WD: 89.5 in; 4WD: 94.5 in Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published 99.2 in ▶ WeightTractor Weight (Base) 2WD: 6878 lb; 4WD: 7297 lb 5070 lb (2565 Shuttle Cab) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published Ag, Industrial, Turf R1 Agricultural - Front Not Published 9.5x20 R1 Agricultural - Rear Not Published 14.9x28 R3 Turf - Front Not Published LSW305-521 R3 Turf - Rear Not Published LSW570-648 R4 Industrial - Front Not Published 10.5/80x18 R4 Industrial - Rear Not Published 18.4x24 ▶ Loader & AttachmentsQuick Attach Loader System Not Published Not Published Loader Model Not Published 2565CL Loader Lift Height Not Published 2565CL: 115.4 in Loader Lift Capacity (Full Height) Not Published 2565CL: 3,122 lb Loader Breakout Force Not Published 2565CL: 5,225 lb ▶ WarrantyWarranty Length & Coverage Not Published 5-year powertrain warranty
