▶ EngineEngine Manufacturer Mahindra AGCO Power Engine Model NE 479 TCI 33 AWIC Engine Type Turbocharged and intercooled, direct injection, liquid-cooled diesel 3-cylinder, intercooled turbocharged diesel No. of Cylinders 4 3 Displacement 203.2 in³ 201.4 in³ Rated Engine Speed 2300 rpm 2200 rpm Engine Power (Gross) 81.9 hp 75 hp PTO Power 69 hp 60 hp Engine Emissions Constraints Tier 3 Tier 4 Cooling System Type Not Published Liquid cooled Air Cleaner Dry type with safety cartridge & dust unloader valve Dual element (primary and secondary) Fuel System Rotary FIP with KSB Unit MICO (BOSCH) High-pressure common rail direct fuel injection Alternator 55 A, 12 V 80 A ▶ HydraulicsPump Type Independent fully 'live' hydraulic pump Two-stage pump Implement Flow 17 gpm Not Published Steering Flow 5.3 gpm Not Published Total Hydraulic Flow 22.3 gpm Not Published Overall Hydraulic Pump Flow Not Published Not Published Hydraulic System Type Independent, fully live hydraulic pump with draft and position control Open center Rear Remote Hydraulic Flow Not Published 17.2 gpm No. of Standard Remote Valves 2 2 No. of Optional Remote Valves Not Published 1 ▶ Fluid CapacityFuel Tank Capacity 19.28 gal 33 gal Coolant Capacity 2.58 gal 4.2 gal Crankcase Capacity 9.48 qt 3.3 gal Transmission / Hydraulic System Capacity 8.59 gal Power Shuttle: 10.6 to 11.4 gal; Mechanical: 8.5 to 9.2 gal Front Axle Fluid Capacity 1.79 gal Dana: 1.45 gal beam plus 0.24 gal per final drive; Carraro: 1.3 gal beam plus 0.21 gal per final drive ▶ PTO & HitchPTO Type Rear independent PTO shaft Independent, electrohydraulic engagement PTO Rear Not Published 540/540E standard; 540/1000 optional Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II ball joints with adjustable outside lateral stabilizer Category II Hitch Lift Capacity 5,500 lb Not Published Hitch Lift Capacity (at 24”) 3,850 lb 4,850 lb Lift Control Type Position and draft control Not Published ▶ Transmission & DrivetrainTransmission Type Not Published 12x12 fully synchronized power shuttle, 6 gears x 2 ranges, electrohydraulic shuttle lever; optional Dyna-2 24x24 powershift No. of Speeds 12F / 12R 12 forward and 12 reverse; 24 forward and 24 reverse with optional Dyna-2 Max Travel Speed (Forward) Not Published 2WD: 18 mph; 4WD: 25 mph Max Travel Speed (Reverse) Not Published Not Published Clutch Dry Dual Clutch (normally disengaged PTO clutch) Wet clutch with easy shift knob and electrohydraulic power shuttle lever Differential Lock & Limited Slip Options Not Published Hydraulic, electronically controlled; rear axle engaged via electrohydraulic rocker switch; 4WD front axle: hydraulic differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic (Power Steering) Cab: tilt and telescopic steering column; Platform: tilt steering column Brakes Oil-immersed, independent foot pedals that lock together; hand brake for parking Hydraulic multidisc brakes with mechanical parking brake, independently controlled via foot pedals Seat Suspension & Adjustability Not Published Cab: mechanical swiveling seat with armrests, air-suspension swivel seat optional; Platform: mechanical spring-suspension seat with armrests Front Axle Type Not Published Heavy-duty 2WD or 4WD front axle Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 77.3 in 60.3 in (minimum, with std. 420/85R30 rear tires) Wheelbase 2WD: 85.31 in; 4WD: 85.8 in 88.5 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes 2WD: 157 in; 4WD: 180 in Not Published Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 162.04 in Not Published ▶ WeightTractor Weight (Base) 2WD: 6,878 lb (operating weight); 4WD: 7,297 lb (operating weight) 2WD ROPS: 7,478 lb; 2WD Cab: 8,294 lb; 4WD ROPS: 7,734 lb; 4WD Cab: 8,644 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published Rear: 420/85R30 standard R1 Agricultural - Front Not Published 2WD: 9.5L-15; 4WD: 320/85R24 R1 Agricultural - Rear Not Published 420/85R30 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Not Published 931X and 936X: universal skid steer type quick release Loader Model Not Published FL.3522, FL.3615, 931X, 936X Loader Lift Height Not Published FL.3522: 140 in; FL.3615: 140 in; 931X: 136 in; 936X: 136 in (at pivot pin) Loader Lift Capacity (Full Height) Not Published FL.3522: 2,760 lb; FL.3615: 3,420 lb; 931X: 2,140 lb; 936X: 3,340 lb (to full height, at 31.5 in forward of pivot pin) Loader Breakout Force Not Published Not Published ▶ WarrantyWarranty Length & Coverage Not Published Not Published
