▶ EngineEngine Manufacturer Mahindra FPT Industrial Engine Model NE 479 TCI F5G Engine Type Turbocharged and intercooled, direct injection, liquid-cooled diesel 4-cylinder diesel No. of Cylinders 4 4 Displacement 203.2 in³ 207 in³ Rated Engine Speed 2300 rpm 2300 rpm Engine Power (Gross) 81.9 hp 86 hp PTO Power 69 hp 73 hp Engine Emissions Constraints Tier 3 Tier 4B Cooling System Type Not Published Liquid-cooled Air Cleaner Dry type with safety cartridge & dust unloader valve Not Published Fuel System Rotary FIP with KSB Unit MICO (BOSCH) Electronic high-pressure common rail fuel injection Alternator 55 A, 12 V Not Published ▶ HydraulicsPump Type Independent fully 'live' hydraulic pump Open-center tandem gear pumps: implement pump plus steering and services pump Implement Flow 17 gpm 16.9 gpm Steering Flow 5.3 gpm 9.7 gpm Total Hydraulic Flow 22.3 gpm 26.6 gpm Overall Hydraulic Pump Flow Not Published 26.6 gpm Hydraulic System Type Independent, fully live hydraulic pump with draft and position control Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 2 or 3 (base) No. of Optional Remote Valves Not Published Third rear remote (dealer-installed) ▶ Fluid CapacityFuel Tank Capacity 19.28 gal 30.3 gal Coolant Capacity 2.58 gal Not Published Crankcase Capacity 9.48 qt Not Published Transmission / Hydraulic System Capacity 8.59 gal Not Published Front Axle Fluid Capacity 1.79 gal Not Published ▶ PTO & HitchPTO Type Rear independent PTO shaft Hydraulic PTO with power shuttle transmissions; lever-engaged PTO with mechanical shuttle PTO Rear Not Published 540 (12x12 base); 540/540E or 540/1000 (12x12 optional); 540/540E (24x24 Dual Command base); 540/1000 (24x24 Dual Command optional) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II ball joints with adjustable outside lateral stabilizer Category II (flexible link ends) Hitch Lift Capacity 5,500 lb Not Published Hitch Lift Capacity (at 24”) 3,850 lb 5,620 lb (7,351 lb with optional auxiliary lift ram) Lift Control Type Position and draft control 12x12: rear hitch control levers; Dual Command cab: Electronic Draft Control (EDC) mouse and fender switches; single-lever Lift-O-Matic Plus (optional on 12x12, standard on Dual Command ROPS) ▶ Transmission & DrivetrainTransmission Type Not Published 12x12 mechanical shuttle (standard); 12x12 power shuttle, 20x20 power shuttle with creeper, 24x24 Dual Command Hi-Lo powershift with electrohydraulic power shuttle, or 40x40 Dual Command with creeper (optional) No. of Speeds 12F / 12R 12F/12R (standard); 20F/20R, 24F/24R or 40F/40R (optional) Max Travel Speed (Forward) Not Published 20 mph (12x12 and 20x20 creeper, standard; 25 mph transport option); 25 mph (24x24 and 40x40 Dual Command) Max Travel Speed (Reverse) Not Published Not Published Clutch Dry Dual Clutch (normally disengaged PTO clutch) Not Published Differential Lock & Limited Slip Options Not Published Mechanical rear differential lock, pedal (12x12 models); electrohydraulic rear differential lock, rocker switch (Dual Command models) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic (Power Steering) Power steering Brakes Oil-immersed, independent foot pedals that lock together; hand brake for parking Wet disc Seat Suspension & Adjustability Not Published Cab: fabric mechanical-suspension seat or fabric air-suspension seat with swivel; full-size instructor seat available. ROPS: vinyl mechanical-suspension seat with armrests Front Axle Type Not Published Standard-duty, electronically engaged 4WD front axle (standard); optional: mechanically engaged standard-duty 4WD, electronically engaged heavy-duty 4WD, or heavy-duty 2WD front axle Front Axle Rating Not Published 9,479 lb (standard-duty 4WD, in-action capacity at 4 mph); 10,361 lb (heavy-duty 4WD, in-action capacity at 4 mph) Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 77.3 in 75.7 in Wheelbase 2WD: 85.31 in; 4WD: 85.8 in 92.2 in (2WD); 89.9 in (4WD) Ground Clearance Not Published Not Published Min. Turn Radius without Brakes 2WD: 157 in; 4WD: 180 in 134 in (2WD heavy-duty front axle) Height to Top of ROPS Not Published 106.5 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published 102.1 in Overall Length 162.04 in 163.1 in (2WD); 160.9 in (4WD) ▶ WeightTractor Weight (Base) 2WD: 6,878 lb (operating weight); 4WD: 7,297 lb (operating weight) 6,988 lb (2WD ROPS); 7,672 lb (4WD ROPS) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published Ag: 11.2-24 front, 16.9-30 rear; 13.6-24 front, 16.9-34 rear; 12.4-24 front, 18.4-30 rear; 14.9-24 front, 18.4-34 rear; Turf: 13.6-16.1 front, 16.9-24 rear; Industrial: 12.5/80-18 front, 19.5L24 rear R1 Agricultural - Front Not Published 4WD: 11.2-24, 13.6-24, 12.4-24 or 14.9-24 (paired with 16.9-30, 16.9-34, 18.4-30 or 18.4-34 rears) R1 Agricultural - Rear Not Published 16.9-30, 16.9-34, 18.4-30 or 18.4-34 R3 Turf - Front Not Published 13.6-16.1 R3 Turf - Rear Not Published 16.9-24 R4 Industrial - Front Not Published 12.5/80-18 R4 Industrial - Rear Not Published 19.5L24 ▶ Loader & AttachmentsQuick Attach Loader System Not Published Skid-steer-style or Euro-style quick attach faceplate Loader Model Not Published Factory-fit: 655TL (NSL or MSL), 665TL (NSL or MSL); field-fit: 632TL (NSL), 637TL (MSL) Loader Lift Height Not Published 655TL NSL: 126 in; 655TL MSL: 125 in; 665TL NSL: 134 in; 665TL MSL: 135 in; 632TL: 134 in; 637TL: 134 in Loader Lift Capacity (Full Height) Not Published 655TL NSL: 2,478 lb; 655TL MSL: 3,179 lb; 665TL NSL: 2,632 lb; 665TL MSL: 3,428 lb (at 31.5 in from pivot point); 632TL: 2,028 lb; 637TL: 3,175 lb (to max height, 31.5 in from pivot point) Loader Breakout Force Not Published 655TL NSL: 3,739 lb; 655TL MSL: 3,860 lb; 665TL NSL: 4,455 lb; 665TL MSL: 5,661 lb (at 31.5 in from bucket pivot point); 632TL: 3,351 lb; 637TL: 3,461 lb ▶ WarrantyWarranty Length & Coverage Not Published Not Published
