▶ EngineEngine Manufacturer Mahindra John Deere Engine Model Not Published PowerTech 4045 EWL Engine Type 4-cylinder, liquid-cooled inline diesel Diesel, turbocharged with intercooler, 4-valve HPCR No. of Cylinders 4 4 Displacement 215.6 in³ 276 in³ Rated Engine Speed 2300 rpm 2200 rpm Engine Power (Gross) 125 hp 128.5 hp PTO Power 106 hp 113.3 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Not Published Air Cleaner Not Published Dry type air cleaner with safety element Fuel System Common Rail Diesel Technology (mCRD) High-pressure common rail (HPCR), 4-valve Alternator Not Published 120 A, 12 V ▶ HydraulicsPump Type Not Published Tandem gear pump Implement Flow 21.2 gpm 18.4 gpm Steering Flow 9.25 gpm 6.3 gpm Total Hydraulic Flow Not Published 25.6 gpm Overall Hydraulic Pump Flow Not Published 25.6 gpm Hydraulic System Type Open center, position and draft control, telescoping stabilizers and flex links Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 (9125 S); 3 (9125 P) 2 (rear); 2 (mid) No. of Optional Remote Valves One (3rd outlet on S models; 4th outlet on P model) Up to 3 total (rear); up to 3 total (mid) ▶ Fluid CapacityFuel Tank Capacity Not Published 43.7 gal (Standard Cab) Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Independent Independent rear PTO, electro-hydraulic clutch PTO Rear 540 @ 2220 rpm, 1000 @ 2227 rpm (9125 S); 540 @ 2220 rpm, 750 @ 2208 rpm, 1000 @ 2227 rpm (9125 P) 540/540E standard; 540/540E/1000 optional Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II with telescopic link ends Category II (convertible to I) Hitch Lift Capacity Not Published Not Published Hitch Lift Capacity (at 24”) 5,787 lb (9125 S); 7,628 lb (9125 P) 6,975 lb standard; 7,868 lb optional Lift Control Type Electronic draft control with fender switches Electrohydraulic ▶ Transmission & DrivetrainTransmission Type Power shuttle with synchromesh PowrQuad PLUS 16F/16R or Powr8 32F/16R (cab only) No. of Speeds 12F / 12R (9125 S); 24F / 24R + 8 creepers (9125 P) 16F/16R (PowrQuad PLUS); 32F/16R (Powr8) Max Travel Speed (Forward) Not Published 24 mph Max Travel Speed (Reverse) Not Published Not Published Clutch Not Published Wet Differential Lock & Limited Slip Options Not Published Electro-hydraulic rear differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Cast iron mid-frame design Steering Power steering Power steering Brakes Wet disc Hydraulic wet disc brakes, self-equalizing and self-adjusting Seat Suspension & Adjustability Seat with adjustable air-suspension, folding adjustable armrest, recline and adjustable headrest Mechanical-suspension seat, standard; air-suspension seat, optional; heated low-frequency air-suspension seat, optional Front Axle Type Not Published MFWD Front Axle Rating Not Published Not Published Drawbar Capacity Not Published 3,197 lb ▶ Dimensions & ManeuverabilityOverall Width 91.3 in Not Published Wheelbase Not Published 92.5 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes Not Published 13.1 ft Height to Top of ROPS Not Published Not Applicable Height to Top of ROPS (folded) Not Published Not Applicable Height to Top of Cab Model 107 in Not Published Overall Length 169.3 in Not Published ▶ WeightTractor Weight (Base) 9,385 lb 9,185 lb Weight with ROPS and Loader Not Published Not Applicable Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published R1 Agricultural R1 Agricultural - Front Not Published 12.4R24 R1 Agricultural - Rear Not Published 18.4R30 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published 12.5/80-18 in, 12PR R4 Bias R4 Industrial - Rear Not Published 19.5L-24 in, 10PR R4 Bias ▶ Loader & AttachmentsQuick Attach Loader System Skid steer style quick attach couplers Not Published Loader Model 9125L 520M (4WD only); 540M (NSL and MSL); 540R (NSL and MSL); 600M (NSL only) Loader Lift Height 162 in 520M: NSL/MSL 130-132 in; 540M: NSL 137-141 in, MSL 138-141 in; 540R: 141.85 in; 600M: NSL 148.8-152.8 in Loader Lift Capacity (Full Height) 5,415 lb (at pivot pin) 520M (4WD): NSL 3,335-3,612 lb, MSL 2,460-2,661 lb; 540M: NSL 2,394-2,666 lb, MSL 3,117-3,309 lb; 540R: 3,406 lb; 600M: NSL 3,104-3,236 lb Loader Breakout Force 6,874 lb (at pivot pin) Not Published ▶ WarrantyWarranty Length & Coverage Not Published Basic 24 months or 2,000 hours, whole-machine standard agricultural equipment term
