▶ EngineEngine Manufacturer Mitsubishi TYM Engine Model S3L2 T1100N2 Engine Type Four-stroke, naturally aspirated, indirect injection, water-cooled diesel 3-cylinder, naturally aspirated diesel No. of Cylinders 3 3 Displacement 80.4 in³ 71.7 in³ Rated Engine Speed 2500 rpm 2850 rpm Engine Power (Gross) 24 hp 24 hp PTO Power 20 hp 21 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Water Cooled Not Published Air Cleaner Not Published Dry element Fuel System Indirect Injection IDI Alternator 50 A, 12 V 60 A, 12 V ▶ HydraulicsPump Type Not Published Dual gear pump Implement Flow 4.6 gpm 4.7 gpm Steering Flow Not Published 3.3 gpm Total Hydraulic Flow 7.3 gpm 7.9 gpm Overall Hydraulic Pump Flow 7.3 gpm 7.9 gpm Hydraulic System Type Open Center Dual gear pump Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published None No. of Optional Remote Valves Not Published 2 ▶ Fluid CapacityFuel Tank Capacity 6.1 gal 6.0 gal Coolant Capacity Not Published 5.3 qt Crankcase Capacity Not Published 2.9 qt Transmission / Hydraulic System Capacity Not Published 3.7 gal Front Axle Fluid Capacity Not Published 3.5 qt ▶ PTO & HitchPTO Type Live Live PTO Rear 540 @ 2376 rpm 540/1000 rpm Mid-PTO Availability Standard; 2000 @ 2556 rpm Available Category, 3-Point Hitch CAT I Category I Hitch Lift Capacity 1,354 lb 1,499 lb Hitch Lift Capacity (at 24”) Not Published 974 lb Lift Control Type Not Published Position control ▶ Transmission & DrivetrainTransmission Type HST - 2 ranges 2400R: Constant Mesh; 2400H: HST No. of Speeds Infinite 2400R: F6 x R2; 2400H: 2-Range Max Travel Speed (Forward) Not Published 2400R: 9.9 mph; 2400H: 12.1 mph Max Travel Speed (Reverse) Not Published 2400R: 3.9 mph; 2400H: 12.1 mph Clutch Dry - Single Dry single plate Differential Lock & Limited Slip Options Not Published Differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Not Published Hydrostatic Brakes Wet disc Wet, Multi disc Seat Suspension & Adjustability Not Published Comfortable suspension seat Front Axle Type Not Published 4WD Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 50.7 in 44.2 in Wheelbase 58.2 in 59.1 in Ground Clearance 7.2 in 12.1 in Min. Turn Radius without Brakes 7.2 ft (L) 9.6 ft; (R) 9.5 ft Height to Top of ROPS 81.5 in 87.3 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 106.1 in 120.3 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 1,715 lb 2400R: 1,792 lb; 2400H: 1,829 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front 6x12 6-12 R1 Agricultural - Rear 9.5x16 9.5-16 R3 Turf - Front 20x8-10 23x8.50-12 R3 Turf - Rear 29x12.5-15 33x12.50-16.5 R4 Industrial - Front 20x8-10 23x8.50-12 R4 Industrial - Rear 27x12.5-15 12-16.5 ▶ Loader & AttachmentsQuick Attach Loader System Not Published BL100S: Quick attach mechanism Loader Model MXL25L BL100S Loader Lift Height 75 in BL100S: 88.3 in Loader Lift Capacity (Full Height) 900 lb (at pivot pin) BL100S: 1,314 lb (at pivot pin) Loader Breakout Force 2,000 lb BL100S: 1,960 lb (at pivot pin, ground level) ▶ WarrantyWarranty Length & Coverage Not Published Basic 2 years or 2,000 hours; powertrain 3,000 hours maximum, parts and labor; loaders and backhoes 12 months ▶ ITC Company AccessoriesAccessories that fit
