▶ EngineEngine Manufacturer Mitsubishi TYM Engine Model S3L2 A1100N2 Engine Type Four-stroke, indirect injection, water-cooled diesel 3 cylinder, water-cooled diesel, natural aspiration, swirl chamber No. of Cylinders 3 3 Displacement 80.4 in³ 71.7 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 25.6 hp 25 hp PTO Power HST: 20 hp; Shuttle: 21.5 hp 18 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Water-cooled Water-cooled Air Cleaner Not Published Dry element Fuel System Indirect injection Indirect injection (swirl chamber) Alternator 50 A, 12 V 50 A, 12 V ▶ HydraulicsPump Type Not Published Gear type pump with primary and secondary pumps Implement Flow 5.8 gpm 4.3 gpm Steering Flow 2.7 gpm 3.1 gpm Total Hydraulic Flow 8.5 gpm (5.8 + 2.7, computed) 7.4 gpm Overall Hydraulic Pump Flow 8.5 gpm (5.8 + 2.7, computed) 7.7 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published 0 No. of Optional Remote Valves 1 1 ▶ Fluid CapacityFuel Tank Capacity 6.1 gal 6.08 gal Coolant Capacity Not Published 1.21 gal Crankcase Capacity Not Published 0.79 gal Transmission / Hydraulic System Capacity Not Published 2.90 gal Front Axle Fluid Capacity Not Published 0.79 gal ▶ PTO & HitchPTO Type Live (HST); Trans (Shuttle) Live PTO (6 spline shaft) PTO Rear 540 rpm @ 2376 rpm 540 / 960 rpm Mid-PTO Availability Optional; 2000 rpm @ 2526 rpm Optional, 2,500 rpm Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 2,205 lb 1,433 lb Hitch Lift Capacity (at 24”) Not Published 974 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type HST: HST, 2 ranges; Shuttle: synchro-mesh F/R shuttle, constant-mesh gear Hydrostatic (HST) No. of Speeds Infinite (HST); 8F / 8R (Shuttle) 3 range (L/M/H) Max Travel Speed (Forward) 10.0 mph (HST); 11.2 mph (Shuttle) 14.8 mph Max Travel Speed (Reverse) 5.1 mph (HST); 9.4 mph (Shuttle) 14.8 mph Clutch Single plate, dry Dry, single plate Differential Lock & Limited Slip Options Not Published Mechanical rear differential lock ▶ Chassis, Steering & ControlsFrame Type Full-length tractor frame Steel frame with cast iron axles Steering Hydrostatic power steering Hydrostatic power steering Brakes Wet disc Wet disc Seat Suspension & Adjustability Not Published Adjustable seat, flips up and back for rear backhoe operation Front Axle Type Not Published Selectable 4WD Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 109.3 in 110 in Overall Width 54.3 in 53.8 in Wheelbase Not Published 65.7 in Ground Clearance Not Published 16.4 in Min. Turn Radius without Brakes 6.6 ft Not Published Height to Top of ROPS 84.3 in 91.4 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 1,863 lb (HST); 1,819 lb (Shuttle) 2,106 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Ag, Industrial, Turf R4 Industrial (25x8.50-14 front / 14x17.5 rear) R1 Agricultural - Front 7x12 7-16 6PR R1 Agricultural - Rear 9.5x16 11.2-20 R3 Turf - Front 23x8.5-12 Not Published R3 Turf - Rear 33x12.5-16.5 Not Published R4 Industrial - Front 23x8.5-12 25x8.50-14 R4 Industrial - Rear 12x16.5 14x17.5 ▶ Loader & AttachmentsQuick Attach Loader System Not Published Quick attach front loader Loader Model Max 26L BBL300 Loader Lift Height Max 26L: 82.7 in 86 in Loader Lift Capacity (Full Height) Max 26L: 1,402 lb 1,314 lb Loader Breakout Force Max 26L: 2,690 lb 1,960 lbf ▶ WarrantyWarranty Length & Coverage 5-year powertrain warranty Basic 24 months or 1,000 hours; powertrain 72 months or 2,000 hours; loader and backhoe 24 months from shipment, 12 months from sale, or 500 hours ▶ ITC Company AccessoriesAccessories that fit None tagged yet
