▶ EngineEngine Manufacturer Mitsubishi Mitsubishi Engine Model S3L2 Not Published Engine Type Four-stroke, indirect injection, water-cooled diesel 3-cylinder, overhead valve, cross-flow porting diesel No. of Cylinders 3 3 Displacement 80.4 in³ 80.43 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 25.6 hp 26 hp PTO Power HST: 20 hp; Shuttle: 21.5 hp Shuttle: 23 hp; HST: 21.1 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Water-cooled Liquid-cooled, pressurized, thermostat controlled bypass, impeller pump Air Cleaner Not Published Dry type with double filter Fuel System Indirect injection Indirect injection; Bosch M-type ND-PFR (Denso) injection pump, throttle-type injectors Alternator 50 A, 12 V 50 A ▶ HydraulicsPump Type Not Published Gear type, front mounted, engine driven Implement Flow 5.8 gpm 7.8 gpm Steering Flow 2.7 gpm 3.4 gpm Total Hydraulic Flow 8.5 gpm (5.8 + 2.7, computed) 11.2 gpm (7.8 + 3.4, computed) Overall Hydraulic Pump Flow 8.5 gpm (5.8 + 2.7, computed) Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves 1 1 ▶ Fluid CapacityFuel Tank Capacity 6.1 gal Not Published Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Live (HST); Trans (Shuttle) Independent (3016 Gear Drive); Live (3016 Hydrostatic Drive) PTO Rear 540 rpm @ 2376 rpm 540 rpm @ 2376 rpm Mid-PTO Availability Optional; 2000 rpm @ 2526 rpm Optional; 2000 rpm @ 2525 rpm Category, 3-Point Hitch Category I CAT I Hitch Lift Capacity 2,205 lb Not Published Hitch Lift Capacity (at 24”) Not Published 1,720 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type HST: HST, 2 ranges; Shuttle: synchro-mesh F/R shuttle, constant-mesh gear Synchro shuttle, constant-mesh main, 2 ranges (3016 Gear Drive); hydrostatic, 3 ranges (3016 Hydrostatic Drive) No. of Speeds Infinite (HST); 8F / 8R (Shuttle) 8F/8R (3016 Gear Drive); infinite, 3 ranges (3016 Hydrostatic Drive) Max Travel Speed (Forward) 10.0 mph (HST); 11.2 mph (Shuttle) 11.9 mph (3016 Gear Drive); 13.8 mph (3016 Hydrostatic Drive) Max Travel Speed (Reverse) 5.1 mph (HST); 9.4 mph (Shuttle) 9.9 mph (3016 Gear Drive); 6.9 mph (3016 Hydrostatic Drive) Clutch Single plate, dry Dry single disc, diaphragm type, 8.46 in Differential Lock & Limited Slip Options Not Published Mechanical differential lock, pedal actuated ▶ Chassis, Steering & ControlsFrame Type Full-length tractor frame Not Published Steering Hydrostatic power steering Hydrostatic power steering Brakes Wet disc Wet disc, mechanical Seat Suspension & Adjustability Not Published Not Published Front Axle Type Not Published MFD, spiral bevel differential, bevel gear final drives Front Axle Rating Not Published Not Published Drawbar Capacity Not Published 969 lbf ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 109.3 in 121.3 in Overall Width 54.3 in 63 in Wheelbase Not Published 67.3 in Ground Clearance Not Published 11.4 in Min. Turn Radius without Brakes 6.6 ft 7.9 ft (with brake applied) Height to Top of ROPS 84.3 in 81.5 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 1,863 lb (HST); 1,819 lb (Shuttle) 2,437 lb (3016 Gear Drive); 2,459 lb (3016 Hydrostatic Drive) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Ag, Industrial, Turf Not Published R1 Agricultural - Front 7x12 7x16 R1 Agricultural - Rear 9.5x16 11.2x24 R3 Turf - Front 23x8.5-12 25x8.5-14 R3 Turf - Rear 33x12.5-16.5 13.6x16 R4 Industrial - Front 23x8.5-12 27x8.50-15 R4 Industrial - Rear 12x16.5 15x19.5 ▶ Loader & AttachmentsQuick Attach Loader System Not Published Not Published Loader Model Max 26L ML115 Loader Lift Height Max 26L: 82.7 in ML115: 99 in Loader Lift Capacity (Full Height) Max 26L: 1,402 lb ML115: 1,650 lb Loader Breakout Force Max 26L: 2,690 lb ML115: 2,350 lb ▶ WarrantyWarranty Length & Coverage 5-year powertrain warranty Not Published
