▶ EngineEngine Manufacturer Mitsubishi Mitsubishi Engine Model S3L2 Not Published Engine Type Four-stroke, naturally aspirated, indirect injection, water-cooled diesel 3-cylinder, four-cycle, valve in cylinder head, cross-flow porting diesel No. of Cylinders 3 3 Displacement 80.4 in³ 80.43 in³ Rated Engine Speed 2500 rpm 2600 rpm Engine Power (Gross) 25.9 hp 26 hp PTO Power 20.2 hp Shuttle: 23 hp; HST: 21.1 hp Engine Emissions Constraints Not Published Not Published Cooling System Type Water Cooled Liquid-cooled, pressurized, thermostat controlled bypass, impeller pump Air Cleaner Not Published Dry type with double filter Fuel System Indirect Injection Indirect injection; Bosch M-type ND-PFR (Denso) injection pump, throttle-type injectors Alternator 50 A, 12 V 50 A ▶ HydraulicsPump Type Not Published Gear type, front mounted, engine driven Implement Flow 5.8 gpm 7.8 gpm Steering Flow Not Published 3.4 gpm Total Hydraulic Flow 8.5 gpm 11.2 gpm (7.8 + 3.4, computed) Overall Hydraulic Pump Flow 8.5 gpm Not Published Hydraulic System Type Open Center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Not Published 1 ▶ Fluid CapacityFuel Tank Capacity 6.1 gal Not Published Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Live Independent (3016 Gear Drive); Live (3016 Hydrostatic Drive) PTO Rear 540 @ 2376 rpm 540 rpm @ 2376 rpm Mid-PTO Availability Optional; 2000 @ 2526 rpm Optional; 2000 rpm @ 2525 rpm Category, 3-Point Hitch CAT I CAT I Hitch Lift Capacity 2,315 lb Not Published Hitch Lift Capacity (at 24”) Not Published 1,720 lb Lift Control Type Not Published Position control ▶ Transmission & DrivetrainTransmission Type HST - 2 ranges Synchro shuttle, constant-mesh main, two ranges (3016 Gear Drive); hydrostatic, three ranges (3016 Hydrostatic Drive) No. of Speeds Infinite 8F/8R (3016 Gear Drive); infinite, 3 ranges (3016 Hydrostatic Drive) Max Travel Speed (Forward) Not Published 11.9 mph (3016 Gear Drive); 13.8 mph (3016 Hydrostatic Drive) Max Travel Speed (Reverse) Not Published 9.9 mph (3016 Gear Drive); 6.9 mph (3016 Hydrostatic Drive) Clutch Dry - Single Dry single disc, diaphragm type, 8.46 in Differential Lock & Limited Slip Options Not Published Mechanical differential lock, pedal actuated ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power Steering Hydrostatic power steering Brakes Wet disc Wet disc, mechanical Seat Suspension & Adjustability Not Published Not Published Front Axle Type Not Published MFD, spiral bevel gear type differential with bevel gear reductions Front Axle Rating Not Published Not Published Drawbar Capacity Not Published 969 lbf ▶ Dimensions & ManeuverabilityOverall Width 54.3 in 63 in Wheelbase 63.2 in 67.3 in Ground Clearance 11.4 in 11.4 in Min. Turn Radius without Brakes 7.2 ft 94.5 in (with brake applied) Height to Top of ROPS 84.3 in 81.5 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 110 in 121.3 in (to end of lower link) ▶ WeightTractor Weight (Base) 1,973 lb 2,437 lb (3016 Gear Drive); 2,459 lb (3016 Hydrostatic Drive) Weight with ROPS and Loader 2,600 lb (1,973 + 627, computed; MXLT6.9 gal loader shipping weight) Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Ag, Industrial, Turf Not Published R1 Agricultural - Front 7-12 7x16 R1 Agricultural - Rear 9.5-16 11.2x24 R3 Turf - Front 23x8.5-12 25x8.5-14 R3 Turf - Rear 33x12.5-15 13.6x16 R4 Industrial - Front 23x8.50-12 27x8.50-15 R4 Industrial - Rear 12-16.5 15x19.5 ▶ Loader & AttachmentsQuick Attach Loader System Quick-Attach Adapter (included) Not Published Loader Model MXLT26L ML115 Loader Lift Height 82.7 in ML115: 99 in Loader Lift Capacity (Full Height) 1,402 lb (at pivot pin) ML115: 1,650 lb (at pivot pin) Loader Breakout Force 2,690 lb ML115: 2,350 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage Not Published Not Published
