▶ EngineEngine Manufacturer Mitsubishi Kubota Engine Model S3L2 D1305-E3-D22 Engine Type Four stroke, indirect injection water-cooled, diesel E-TVCS, liquid-cooled, 3-cylinder diesel No. of Cylinders 3 3 Displacement 80.4 in³ 77.0 in³ Rated Engine Speed 2600 rpm 2800 rpm Engine Power (Gross) 28 hp 29 hp PTO Power Shuttle: 23.5 hp; HST: 22 hp 21 hp Engine Emissions Constraints Not Published Not Published Cooling System Type Not Published Liquid-cooled, pressurized radiator Air Cleaner Not Published Not Published Fuel System Direct injection Indirect injection (E-TVCS) Alternator 50 A, 12 V 14.5 A, 12 V ▶ HydraulicsPump Type Not Published Dual pump (3-point + power steering) Implement Flow 4.6 gpm 4.7 gpm Steering Flow 2.7 gpm 3.6 gpm Total Hydraulic Flow Not Published 8.3 gpm (4.7 + 3.6, computed) Overall Hydraulic Pump Flow Not Published Not Published Hydraulic System Type Open center, full live hydraulic with position control Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published 1 or 2 No. of Optional Remote Valves 1 spool optional Not Published ▶ Fluid CapacityFuel Tank Capacity 6.1 gal 6.9 gal (6.9 U.S. gal, all models) Coolant Capacity Not Published 4.1 qt Crankcase Capacity Not Published 3.7 qt Transmission / Hydraulic System Capacity Not Published 4.0 gal Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Trans Live PTO Rear 540 rpm @ 2376 rpm 540/960 rpm Mid-PTO Availability Optional, 2000 rpm @ 2526 rpm Optional mid-PTO, 2500 rpm (USA No. 5, Kubota 10-tooth) Category, 3-Point Hitch Category 1, with check chains Category I Hitch Lift Capacity 2205 lb 1356 lb Hitch Lift Capacity (at 24”) Not Published 1058 lb Lift Control Type Position control Position control valve, quarter inching valve ▶ Transmission & DrivetrainTransmission Type Constant mesh on gear shift and synchro mesh on F/R shuttle Main-hydrostatic transmission, 3-range No. of Speeds Infinite 3-range (3 forward, 3 reverse) Max Travel Speed (Forward) Not Published 12.6 mph Max Travel Speed (Reverse) Not Published 10.0 mph Clutch Single plate, dry Not Published Differential Lock & Limited Slip Options Not Published Rear differential lock standard ▶ Chassis, Steering & ControlsFrame Type Not Published Two-post foldable ROPS (sunshade optional) Steering Hydrostatic Power Integral type power steering Brakes Wet disc Wet disk type Seat Suspension & Adjustability Not Published Not Published Front Axle Type Not Published Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 109.3 in 95.1 in (w/o 3P) (without 3-point hitch) Overall Width 54.3 in 49.0 in Wheelbase Not Published 61.5 in Ground Clearance Not Published 12.8 in Min. Turn Radius without Brakes 6.6 ft 6.9 ft (w/brake) (with brake applied) Height to Top of ROPS Not Published 85.0 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) Shuttle: 1819 lb; HST: 1863 lb 1554 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published Standard farm 7-12 front, 11.2-16 rear R1 Agricultural - Front 7x12 7-12 R1 Agricultural - Rear 9.5x16 11.2-16 R3 Turf - Front 23x8.5-12 Not Published R3 Turf - Rear 33x12.5-16.5 Not Published R4 Industrial - Front 23x8.5-12 23x8.50-12 R4 Industrial - Rear 12x16.5 12-16.5 ▶ Loader & AttachmentsQuick Attach Loader System Skid-steer style loader couplers Not Published Loader Model ML205 (named by both Mahindra spec sheets; a US listing calls the same loader the ML202) LA364 Loader Lift Height ML205: 82.7 in LA364: 78.6 in Loader Lift Capacity (Full Height) ML205: 1402 lb LA364: 952 lb Loader Breakout Force ML205: 2690 lb LA364: 2144 lbf ▶ WarrantyWarranty Length & Coverage Not Published Not Published
