▶ EngineEngine Manufacturer Mitsubishi Mitsubishi Engine Model S3L2 Not Published Engine Type Four stroke, indirect injection water-cooled, diesel Three cylinder, four cycle, valve in cylinder head, cross flow porting diesel No. of Cylinders 3 3 Displacement 80.4 in³ 80.43 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 28 hp 26 hp PTO Power Shuttle: 23.5 hp; HST: 22 hp 23 hp Engine Emissions Constraints Not Published Not Published Cooling System Type Not Published Liquid-cooled, pressurized, thermostat controlled bypass, impeller pump Air Cleaner Not Published Dry type with double filter Fuel System Direct injection Indirect injection; Bosch M type ND-PFR (Denso) injection pump, throttle type injectors Alternator 50 A, 12 V 50 A ▶ HydraulicsPump Type Not Published Gear type, front mounted, engine driven Implement Flow 4.6 gpm 7.8 gpm Steering Flow 2.7 gpm 3.4 gpm Total Hydraulic Flow Not Published 11.2 gpm (7.8 + 3.4, computed) Overall Hydraulic Pump Flow Not Published Not Published Hydraulic System Type Open center, full live hydraulic with position control Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves 1 spool optional 1 ▶ Fluid CapacityFuel Tank Capacity 6.1 gal Not Published Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Trans Independent (3016 Gear Drive); Live (3016 Hydrostatic Drive) PTO Rear 540 rpm @ 2376 rpm 540 rpm @ 2376 rpm Mid-PTO Availability Optional, 2000 rpm @ 2526 rpm Optional; 2000 rpm @ 2525 rpm Category, 3-Point Hitch Category 1, with check chains CAT I Hitch Lift Capacity 2205 lb Not Published Hitch Lift Capacity (at 24”) Not Published 1720 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type Constant mesh on gear shift and synchro mesh on F/R shuttle Synchro shuttle, constant mesh main with 2 ranges (3016 Gear Drive); Hydrostatic, 3 ranges (3016 Hydrostatic Drive) No. of Speeds Infinite 8F/8R (3016 Gear Drive); Infinite, 3 ranges (3016 Hydrostatic Drive) Max Travel Speed (Forward) Not Published 11.9 mph (3016 Gear Drive); 13.8 mph (3016 Hydrostatic Drive) Max Travel Speed (Reverse) Not Published 9.9 mph (3016 Gear Drive); 6.9 mph (3016 Hydrostatic Drive) Clutch Single plate, dry Dry single disc, diaphragm type, 8.46 in Differential Lock & Limited Slip Options Not Published Mechanical differential lock, pedal actuated ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic Power Hydrostatic power steering Brakes Wet disc Wet disc, mechanical Seat Suspension & Adjustability Not Published Not Published Front Axle Type Not Published Mechanical front drive (MFD), spiral bevel gear differential with bevel gear reductions Front Axle Rating Not Published Not Published Drawbar Capacity Not Published 969 lbf ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 109.3 in 121.3 in Overall Width 54.3 in 63 in Wheelbase Not Published 67.3 in Ground Clearance Not Published 11.4 in Min. Turn Radius without Brakes 6.6 ft 7.9 ft (with brake applied) Height to Top of ROPS Not Published 81.5 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) Shuttle: 1819 lb; HST: 1863 lb 2437 lb (3016 Gear Drive); 2459 lb (3016 Hydrostatic Drive) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published Not Published R1 Agricultural - Front 7x12 7x16 R1 Agricultural - Rear 9.5x16 11.2x24 R3 Turf - Front 23x8.5-12 25x8.5-14 R3 Turf - Rear 33x12.5-16.5 13.6x16 R4 Industrial - Front 23x8.5-12 27x8.50-15 R4 Industrial - Rear 12x16.5 15x19.5 ▶ Loader & AttachmentsQuick Attach Loader System Skid-steer style loader couplers Not Published Loader Model ML205 (named by both Mahindra spec sheets; a US listing calls the same loader the ML202) ML115 Loader Lift Height ML205: 82.7 in ML115: 99 in Loader Lift Capacity (Full Height) ML205: 1402 lb ML115: 1,650 lb Loader Breakout Force ML205: 2690 lb ML115: 2,650 lb ▶ WarrantyWarranty Length & Coverage Not Published Not Published
