▶ EngineEngine Manufacturer Kukje Yanmar Engine Model A1100N3 3TNM74F Engine Type Four-stroke, naturally aspirated, indirect injection, water-cooled diesel 3 cylinder, water-cooled diesel, natural aspiration No. of Cylinders 3 3 Displacement 71.7 in³ 60.6 in³ Rated Engine Speed 2600 rpm 3200 rpm Engine Power (Gross) 22 hp 21.5 hp PTO Power 14.9 hp 15.4 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Water-cooled Water-cooled Air Cleaner Not Published Single dry element Fuel System Indirect Injection Indirect injection Alternator 50 A, 12 V 40 A, 12 V ▶ HydraulicsPump Type Not Published Single gear pump with flow divider Implement Flow 4.5 gpm 4.17 gpm Steering Flow Not Published 2.11 gpm Total Hydraulic Flow 7.1 gpm 6.3 gpm Overall Hydraulic Pump Flow 7.1 gpm 6.97 gpm Hydraulic System Type Open Center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Not Published 1 ▶ Fluid CapacityFuel Tank Capacity 5.8 gal 6.6 gal Coolant Capacity 3.7 qt 3.7 qt Crankcase Capacity 2.3 qt 2.1 qt Transmission / Hydraulic System Capacity Not Published 3.6 gal Front Axle Fluid Capacity Not Published 2.6 qt ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 @ 2550 rpm 540 rpm Mid-PTO Availability Available; 2000 @ 2550 rpm Optional, 2,500 rpm Category, 3-Point Hitch CAT I with Check Chains Category I (limited) Hitch Lift Capacity 1,323 lb 1,100 lb Hitch Lift Capacity (at 24”) Not Published 679 lb Lift Control Type Not Published Position control ▶ Transmission & DrivetrainTransmission Type HST - 2 range Hydrostatic (HST) No. of Speeds Infinite 2 range Max Travel Speed (Forward) Not Published 7.8 mph Max Travel Speed (Reverse) Not Published Not Published Clutch Dry-Single Dry single plate Differential Lock & Limited Slip Options Mechanical rear differential lock Mechanical rear differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Sub-compact tractor Steering Power steering Hydrostatic power steering Brakes Wet Disc Wet disc Seat Suspension & Adjustability Not Published Not Published Front Axle Type Not Published Selectable 4WD Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 45.8 in 44.5 in Wheelbase 57.5 in 53.1 in Ground Clearance 9.4 in 8.3 in Min. Turn Radius without Brakes 7.2 ft 86.6 in Height to Top of ROPS 91.3 in 86.6 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Applicable Not Published Overall Length 100.5 in 94.2 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 1,638 lb 1,433 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front 6x12 16x7.50-9 R1 Agricultural - Rear 9.5x16 24x12.00-12 R3 Turf - Front 20x8-10 16x7.50-8 R3 Turf - Rear 29x12.5-15 26x12.00-12 R4 Industrial - Front 20x8-10 18x8.5-10 R4 Industrial - Rear 27x12.5-15 26x12-12 ▶ Loader & AttachmentsQuick Attach Loader System 25LSK: Skid steer style quick coupler, standard Quick attach front loader Loader Model 25LSK BBL100 Loader Lift Height 25LSK: 75.3 in 78.5 in (at pivot pin) Loader Lift Capacity (Full Height) 25LSK: 900 lb 617 lb (at pivot pin) Loader Breakout Force 25LSK: 2,000 lb 1,253 lbf ▶ WarrantyWarranty Length & Coverage Not Published Basic 24 months or 1,000 hours; powertrain 84 months or 2,000 hours; loader and backhoe 24 months from shipment, 12 months from sale, or 500 hours
