▶ EngineEngine Manufacturer Kukje Kubota Engine Model A1100N3 D902 Engine Type Four-stroke, naturally aspirated, indirect injection, water-cooled diesel Liquid-cooled, 4-cycle diesel No. of Cylinders 3 3 Displacement 71.7 in³ 54.8 in³ Rated Engine Speed 2600 rpm 3200 rpm Engine Power (Gross) 22 hp 21.6 hp PTO Power 14.9 hp 17.7 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Water-cooled Liquid-cooled Air Cleaner Not Published Dry element Fuel System Indirect Injection Direct injection Alternator 50 A, 12 V 40 A, 12 V ▶ HydraulicsPump Type Not Published Open center tandem pump gear type Implement Flow 4.5 gpm 5.2 gpm Steering Flow Not Published 1.0 gpm Total Hydraulic Flow 7.1 gpm 6.2 gpm Overall Hydraulic Pump Flow 7.1 gpm 6.2 gpm Hydraulic System Type Open Center Open center tandem pump gear type Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published None (2-valve rear remote coupler optional) No. of Optional Remote Valves Not Published 2 (optional; ISO 7241-1 series A or B) ▶ Fluid CapacityFuel Tank Capacity 5.8 gal 6.6 gal Coolant Capacity 3.7 qt 3.3 qt Crankcase Capacity 2.3 qt 3.4 qt Transmission / Hydraulic System Capacity Not Published 2.98 gal Front Axle Fluid Capacity Not Published 3.8 qt ▶ PTO & HitchPTO Type Independent Live independent PTO (with hydraulic clutch) PTO Rear 540 @ 2550 rpm STD 540 rpm Mid-PTO Availability Available; 2000 @ 2550 rpm USA No.5 (KUBOTA 10-tooth) involute spline, 2500 rpm Category, 3-Point Hitch CAT I with Check Chains SAE Category I (optional) Hitch Lift Capacity 1,323 lb 1,213 lb Hitch Lift Capacity (at 24”) Not Published 680 lb Lift Control Type Not Published Quarter-inching valve ▶ Transmission & DrivetrainTransmission Type HST - 2 range Hydrostatic transmission, high-low gear shift (2 forward, 2 reverse) No. of Speeds Infinite 2 Range (Low-High) Max Travel Speed (Forward) Not Published 0 mph to 8.4 mph Max Travel Speed (Reverse) Not Published 0 mph to 6.5 mph Clutch Dry-Single Dry type single plate - Main clutch 9.45" Differential Lock & Limited Slip Options Mechanical rear differential lock Rear differential lock standard ▶ Chassis, Steering & ControlsFrame Type Not Published Two-post foldable ROPS Steering Power steering Hydrostatic Power Steering Brakes Wet Disc Mechanical, wet disc type Seat Suspension & Adjustability Not Published High-back reversible seat (rotates for backhoe operation); fore/aft slide and backrest tilt adjustment Front Axle Type Not Published 4WD: Bevel gear front axle, non-adjustable tread spacing Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Maximum tongue weight 550 lb ▶ Dimensions & ManeuverabilityOverall Width 45.8 in 45.1 in Wheelbase 57.5 in 55.1 in Ground Clearance 9.4 in 6.5 in (front axle) Min. Turn Radius without Brakes 7.2 ft 7.5 ft Height to Top of ROPS 91.3 in 86.2 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Applicable Not Published Overall Length 100.5 in 99.0 in (with 3-point hitch, with front guard) ▶ WeightTractor Weight (Base) 1,638 lb 1,600 lb (with ROPS, front guard and control valve assembly) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published Front Turf/Industrial: 18×8.5-10; Rear Turf/Industrial: 26×12-12; Bar tire N/A R1 Agricultural - Front 6x12 Not Published R1 Agricultural - Rear 9.5x16 Not Published R3 Turf - Front 20x8-10 18×8.5-10 R3 Turf - Rear 29x12.5-15 26×12-12 R4 Industrial - Front 20x8-10 18×8.5-10 R4 Industrial - Rear 27x12.5-15 26×12-12 ▶ Loader & AttachmentsQuick Attach Loader System 25LSK: Skid steer style quick coupler, standard Kubota Swift-Tach (Quick attach) Loader Model 25LSK LA340S (standard, quick attach); LA340 (pin-on option) Loader Lift Height 25LSK: 75.3 in 71.0 in (at pivot pin) Loader Lift Capacity (Full Height) 25LSK: 900 lb 739 lb (LA340 pin-on); 613 lb (LA340S quick attach) Loader Breakout Force 25LSK: 2,000 lb 1,407 lbf (LA340 pin-on); 1,286 lbf (LA340S quick attach) ▶ WarrantyWarranty Length & Coverage Not Published Residential: basic 24 months or 1,500 hours, powertrain 72 months or 2,000 hours; commercial: basic 24 months or 1,500 hours ▶ ITC Company AccessoriesAccessories that fit None tagged yet
