▶ EngineEngine Manufacturer Doosan FPT Engine Model Not Published Not Published Engine Type Turbocharged and intercooled, direct injection diesel 4-cylinder diesel, electronic high-pressure common rail No. of Cylinders 4 4 Displacement 208 in³ 207 in³ Rated Engine Speed 2300 rpm 2300 rpm Engine Power (Gross) 105 hp 105 hp PTO Power 94.1 hp 91 hp Engine Emissions Constraints Tier 4 Tier 4A Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Not Published Not Published Fuel System Direct injection Electronic high-pressure common rail Alternator 85 A 120 A ▶ HydraulicsPump Type Not Published Not Published Implement Flow 15.6 gpm 17.2 gpm (22.2 gpm optional) Steering Flow 7.1 gpm 10 gpm (11.4 gpm optional) Total Hydraulic Flow Not Published 27.2 gpm (17.2 + 10, computed) Overall Hydraulic Pump Flow Not Published 27.2 gpm (17.2 + 10, computed) Hydraulic System Type Open center, full-live electro-hydraulic, with position and draft control Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 3 (mFORCE 105P); 2 (mFORCE 105S) 2 No. of Optional Remote Valves 4 spool optional (mFORCE 105P); 3 spool optional (mFORCE 105S) 3 ▶ Fluid CapacityFuel Tank Capacity 29.1 gal 37 gal Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Electro-hydraulic Independent PTO Rear 540 at 2220 rpm, 750 at 2208 rpm, 1000 at 2227 rpm (mFORCE 105P); 540 at 2220 rpm, 1000 at 2227 rpm (mFORCE 105S) Not Published Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II ball joints with telescopic lower links and adjustable outside stabilizers Category II Hitch Lift Capacity 6,860 lb (measuring point not stated by Mahindra) Not Published Hitch Lift Capacity (at 24”) Not Published 6,393 lb Lift Control Type Position and draft control Electronic draft control (EDC) with rear fender switch ▶ Transmission & DrivetrainTransmission Type Power shuttle, power shift with synchromesh (mFORCE 105P); power shuttle with synchromesh (mFORCE 105S) Not Published No. of Speeds 24F / 24R + 8 creepers (mFORCE 105P); 12F / 12R (mFORCE 105S) 12F/12R (20F/20R or 24F/24R optional) Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Wet multi-plate Electro-hydraulic power-shuttle clutch Differential Lock & Limited Slip Options Not Published Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power with tiltable column Power steering Brakes Wet disc Hydraulic wet disc Seat Suspension & Adjustability Pneumatic suspension seat Heated air suspension seat with 15-degree swivel (optional) Front Axle Type Not Published MFD (four-wheel drive) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 84.3 in 75 in (minimum) Wheelbase Not Published 92.5 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes 11.98 ft Not Published Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 108.1 in 103 in (16.9R-34 rear tires) Overall Length 176 in 164 in (16.9R-34 rear tires) ▶ WeightTractor Weight (Base) 8,666 lb (operating weight) 9,370 lb (minimum weight, with 16.9R-34 rear tires) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published 16.9R-34 rear tires (dimension reference); 38-inch tires available R1 Agricultural - Front 13.6R 24 14.9R24 R1 Agricultural - Rear 18.4R 34 Not Published R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Not Published Quick-Latch loader mounting with Quick-Attach faceplate Loader Model 105L L735 (NSL or MSL); L745 (NSL or MSL) Loader Lift Height 105L: 141.7 in L735: 11 ft 3 in; L745: 12 ft 2.75 in (maximum lift height at pivot pins) Loader Lift Capacity (Full Height) 105L: 4,129 lb (at pivot pins) L735: 2,844 lb (NSL) / 2,954 lb (MSL); L745: 3,616 lb (NSL) / 3,814 lb (MSL) (maximum height @ 31.5 in) Loader Breakout Force 105L: 6,025 lb (at pivot pins) L735: 2,976 lb (NSL) / 3,285 lb (MSL); L745: 3,858 lb (NSL) / 4,254 lb (MSL) (boom breakout at 31.5 in) ▶ WarrantyWarranty Length & Coverage 5-year limited powertrain warranty Not Published
