▶ EngineEngine Manufacturer Doosan Kubota Engine Model Not Published V3800CR-TIEF4 Engine Type Turbocharged and intercooled, direct injection diesel 4-cylinder, turbocharged and intercooled, common-rail diesel, DPF, DOC and SCR No. of Cylinders 4 4 Displacement 208 in³ 230 in³ Rated Engine Speed 2300 rpm 2400 rpm Engine Power (Gross) 105 hp 105.6 hp PTO Power 94.1 hp 89 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Not Published Dry paper, dual element, 8 in diameter, with pre-cleaner Fuel System Direct injection Common rail direct injection Alternator 85 A 60 A ▶ HydraulicsPump Type Not Published Gear pump Implement Flow 15.6 gpm 15.7 gpm Steering Flow 7.1 gpm 5.4 gpm Total Hydraulic Flow Not Published 21.3 gpm Overall Hydraulic Pump Flow Not Published 21.3 gpm Hydraulic System Type Open center, full-live electro-hydraulic, with position and draft control Open center Rear Remote Hydraulic Flow Not Published 15.7 gpm No. of Standard Remote Valves 3 (mFORCE 105P); 2 (mFORCE 105S) 2 (max 3) No. of Optional Remote Valves 4 spool optional (mFORCE 105P); 3 spool optional (mFORCE 105S) 1 (3 maximum) ▶ Fluid CapacityFuel Tank Capacity 29.1 gal 27.7 gal Coolant Capacity Not Published 11 qt Crankcase Capacity Not Published 11.3 qt Transmission / Hydraulic System Capacity Not Published 63.4 qt Front Axle Fluid Capacity Not Published 6.3 qt (differential) plus 3.7 qt (each bevel gear case) ▶ PTO & HitchPTO Type Electro-hydraulic Live-independent PTO, electro-hydraulic clutch with brake PTO Rear 540 at 2220 rpm, 750 at 2208 rpm, 1000 at 2227 rpm (mFORCE 105P); 540 at 2220 rpm, 1000 at 2227 rpm (mFORCE 105S) 540 rpm (540/540E optional) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II ball joints with telescopic lower links and adjustable outside stabilizers Category II Hitch Lift Capacity 6,860 lb (measuring point not stated by Mahindra) 7,055 lb (8,600 lb optional) Hitch Lift Capacity (at 24”) Not Published 5,181 lb Lift Control Type Position and draft control Position, draft (top link sensing) and mixed control ▶ Transmission & DrivetrainTransmission Type Power shuttle, power shift with synchromesh (mFORCE 105P); power shuttle with synchromesh (mFORCE 105S) Fully synchronized main gear shift with electro-hydraulic shuttle No. of Speeds 24F / 24R + 8 creepers (mFORCE 105P); 12F / 12R (mFORCE 105S) 8 forward, 8 reverse Max Travel Speed (Forward) Not Published 18.6 mph Max Travel Speed (Reverse) Not Published 18.4 mph Clutch Wet multi-plate Multiple wet disc Differential Lock & Limited Slip Options Not Published Front: limited-slip differential; Rear: mechanical differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power with tiltable column Hydrostatic power steering Brakes Wet disc Hydraulic wet disc Seat Suspension & Adjustability Pneumatic suspension seat Suspension seat with fore and aft travel adjustment, suspension tension knob, backrest tilt adjustment and arm rest Front Axle Type Not Published Bevel gear type with 55 degree turning angle (4WD) Front Axle Rating Not Published 5,730 lb Drawbar Capacity Not Published 3,300 lb ▶ Dimensions & ManeuverabilityOverall Width 84.3 in 79.1 in Wheelbase Not Published 88.6 in Ground Clearance Not Published 17.7 in (drawbar bracket) Min. Turn Radius without Brakes 11.98 ft 13.8 ft Height to Top of ROPS Not Published 99.8 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 108.1 in Not Applicable Overall Length 176 in 155.9 in ▶ WeightTractor Weight (Base) 8,666 lb (operating weight) 6,283 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published Front: 7.50-18, 9.5L-15, 9.5-22, 10.00-16, 11.2-24, 12.4-24; Rear: 16.9-30, 16.9-34, 18.4-30 R1 Agricultural - Front 13.6R 24 12.4-24 R1 Agricultural - Rear 18.4R 34 18.4-30 R3 Turf - Front Not Published 9.5L-15 F2 or 27x9.50-15 HF-1 (rib fronts paired with the R3 rears) R3 Turf - Rear Not Published 18.4-26 R3 or 19.5L-24 R3 R4 Industrial - Front Not Published 9.5L-15 F2 (rib front paired with the R4 rear) R4 Industrial - Rear Not Published 19.5L-24 R4 ▶ Loader & AttachmentsQuick Attach Loader System Not Published Quick coupler, standard; Euro-type quick coupler, optional; tool-free attach and detach; single-lever hydraulic hose coupler, optional Loader Model 105L LA1854 Loader Lift Height 105L: 141.7 in 145.7 in (height position); 131.9 in (power position) Loader Lift Capacity (Full Height) 105L: 4,129 lb (at pivot pins) 3,990 lb (height position); 4,144 lb (power position) Loader Breakout Force 105L: 6,025 lb (at pivot pins) LA1854: 5,501 lbf (height position); 6,470 lbf (power position) ▶ WarrantyWarranty Length & Coverage 5-year limited powertrain warranty Basic 24 months or 2,000 hours, powertrain 36 months or 3,000 hours
