▶ EngineEngine Manufacturer Doosan FPT Engine Model Not Published F5G Engine Type Turbocharged and intercooled, direct injection diesel Dual Command: 4-cylinder diesel; Electro Command: turbo diesel with high-pressure common rail and electronic fuel delivery control No. of Cylinders 4 4 Displacement 208 in³ 207 in³ Rated Engine Speed 2300 rpm 2200 rpm Engine Power (Gross) 105 hp 107 hp PTO Power 94.1 hp 93 hp Engine Emissions Constraints Tier 4 Tier 4B Final Cooling System Type Liquid-cooled Liquid cooled Air Cleaner Not Published Not Published Fuel System Direct injection Electro Command: high-pressure common-rail, electronic fuel delivery control Alternator 85 A 120 A ▶ HydraulicsPump Type Not Published Fixed displacement, tandem pumps (implement and steering) Implement Flow 15.6 gpm Dual Command: 16.9 gpm; Electro Command: 21.1 gpm Steering Flow 7.1 gpm Dual Command: 9.7 gpm; Electro Command: 11.4 gpm Total Hydraulic Flow Not Published Dual Command: 26.6 gpm (16.9 + 9.7, computed); Electro Command: 32.5 gpm (21.1 + 11.4, computed) Overall Hydraulic Pump Flow Not Published Dual Command: 26.6 gpm (16.9 + 9.7, computed); Electro Command: 32.5 gpm (21.1 + 11.4, computed) Hydraulic System Type Open center, full-live electro-hydraulic, with position and draft control Not Published Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 3 (mFORCE 105P); 2 (mFORCE 105S) Dual Command: 2 or 3; Electro Command: 2 No. of Optional Remote Valves 4 spool optional (mFORCE 105P); 3 spool optional (mFORCE 105S) Electro Command: 3 rear remotes (mechanical, 2 with configurable detents) ▶ Fluid CapacityFuel Tank Capacity 29.1 gal Electro Command: 43.6 gal Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Electro-hydraulic Independent (hydraulic wet disc clutch) PTO Rear 540 at 2220 rpm, 750 at 2208 rpm, 1000 at 2227 rpm (mFORCE 105P); 540 at 2220 rpm, 1000 at 2227 rpm (mFORCE 105S) Dual Command: 540/1000 rpm (optional); Electro Command: 540/1000 rpm (540/540E/1000 optional) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II ball joints with telescopic lower links and adjustable outside stabilizers Category II Hitch Lift Capacity 6,860 lb (measuring point not stated by Mahindra) Not Published Hitch Lift Capacity (at 24”) Not Published Dual Command: 5,620 lb (7,351 lb with optional ram) Lift Control Type Position and draft control Not Published ▶ Transmission & DrivetrainTransmission Type Power shuttle, power shift with synchromesh (mFORCE 105P); power shuttle with synchromesh (mFORCE 105S) Dual Command: 24x24 Hi-Lo with power shuttle (standard); Electro Command: 16x16 semi-powershift (auto-shift or 32x32 creeper optional) No. of Speeds 24F / 24R + 8 creepers (mFORCE 105P); 12F / 12R (mFORCE 105S) Dual Command: 24F/24R; Electro Command: 16F/16R (32F/32R with creeper) Max Travel Speed (Forward) Not Published 25 mph Max Travel Speed (Reverse) Not Published Not Published Clutch Wet multi-plate Not Published Differential Lock & Limited Slip Options Not Published Optional TerraLock automatic 4WD engagement and differential lock system (Electro Command) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power with tiltable column Power steering Brakes Wet disc Hydraulic wet disc Seat Suspension & Adjustability Pneumatic suspension seat Not Published Front Axle Type Not Published Electro Command: 4WD front axle, Class 1.5 HD (TerraGlide suspended 4WD front axle optional) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 84.3 in Dual Command: 75.7 in Wheelbase Not Published Dual Command: 89.9 in; Electro Command: 93.7 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes 11.98 ft Not Published Height to Top of ROPS Not Published Dual Command: 106.5 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 108.1 in Dual Command: 102.1 in; Electro Command: 107 in Overall Length 176 in Dual Command: 160.9 in; Electro Command: 165 in ▶ WeightTractor Weight (Base) 8,666 lb (operating weight) Dual Command (ROPS): 7,672 lb; Dual Command (Cab): 8,157 lb; Electro Command (Cab): 10,031 lb (shipping weight) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published Not Published R1 Agricultural - Front 13.6R 24 14.9R24 R1 Agricultural - Rear 18.4R 34 18.4R34 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Not Published Skid-steer style or Euro (European) style tool carrier Loader Model 105L 810LA (NSL); 815LA (MSL) Loader Lift Height 105L: 141.7 in 825TL: 139.0 in; 835TL: 146.9 in (to pivot pin) Loader Lift Capacity (Full Height) 105L: 4,129 lb (at pivot pins) 825TL NSL: 2,954 lb; 825TL MSL: 3,086 lb; 835TL NSL: 3,638 lb; 835TL MSL: 3,836 lb (to max height, measured 31.5 in forward of pivot pin) Loader Breakout Force 105L: 6,025 lb (at pivot pins) 825TL NSL: 3,109 lb; 825TL MSL: 3,417 lb; 835TL NSL: 3,880 lb; 835TL MSL: 4,277 lb (measured 31.5 in forward of pivot pin) ▶ WarrantyWarranty Length & Coverage 5-year limited powertrain warranty Not Published
