▶ EngineEngine Manufacturer Iseki KIOTI Engine Model E3112 3C100LWH-U3 Engine Type 3-cylinder liquid-cooled inline indirect-injection diesel In-Line Vertical, Water-Cooled 4-Cycle Diesel (3-cylinder) No. of Cylinders 3 3 Displacement 68.5 in³ 61.5 in³ Rated Engine Speed 2500 rpm 3200 rpm Engine Power (Gross) 21 hp 21 hp PTO Power Gear: 17.5 hp; Hydro: 16 hp 16.3 hp Engine Emissions Constraints Not Published Not Published Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dry Not Published Fuel System Indirect injection, glow plug pre-heating Not Published Alternator 40 A Not Published ▶ HydraulicsPump Type Not Published Gear Implement Flow 5.2 gpm Not Published Steering Flow 2.5 gpm Not Published Total Hydraulic Flow 7.7 gpm 6.5 gpm Overall Hydraulic Pump Flow Not Published 6.5 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves 1 or 2 Not Published ▶ Fluid CapacityFuel Tank Capacity 4.75 gal 6.7 gal Coolant Capacity 5.4 qt Not Published Crankcase Capacity 3.3 qt Not Published Transmission / Hydraulic System Capacity 2.64 gal 3.4 gal Front Axle Fluid Capacity Not Published 0.5 gal ▶ PTO & HitchPTO Type Live, two-stage dry disc clutch Independent PTO Rear 540 rpm (1.375 in) at 2327 engine rpm 540 rpm Mid-PTO Availability Live, 2000 rpm at 2500 engine rpm Available (2,200 rpm) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1,210 lb 1,580 lb Hitch Lift Capacity (at 24”) Not Published 700 lb Lift Control Type Position control Position ▶ Transmission & DrivetrainTransmission Type 6-speed gear, hydrostatic, or 9-speed gear with optional creeper range HST (hydrostatic) No. of Speeds Gear: 6F / 2R (9F / 3R with creeper); hydrostatic: infinite forward and reverse, 2 ranges Infinite, 2 range (High/Low) Max Travel Speed (Forward) Not Published 10.3 mph Max Travel Speed (Reverse) Not Published 7.0 mph Clutch 8.5 in dry disc (gear) None (hydrostatic transmission) Differential Lock & Limited Slip Options Mechanical rear differential lock Rear differential lock (standard) ▶ Chassis, Steering & ControlsFrame Type Two-post folding ROPS Not Published Steering 2WD: power steering standard; 4WD: manual, power assist optional Hydrostatic power steering Brakes Mechanical wet disc Wet disk type Seat Suspension & Adjustability Not Published Not Published Front Axle Type 2WD or 4WD; spur gear final drives Mechanical 4WD Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 108.3 in 99.3 in Overall Width 42.2 in 46.7 in Wheelbase 59.4 in 55.1 in Ground Clearance 11 in 6.4 in Min. Turn Radius without Brakes Not Published 8.33 ft (with brake applied) Height to Top of ROPS 77 in 87.6 in Height to Top of ROPS (folded) 60.5 in Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 1,477 lb (2WD gear); 1,500 lb (2WD hydro); 1,654 lb (4WD gear); 1,676 lb (4WD hydro) 1,485 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Ag: 5.00-12 front (2WD) or 6-12 front (4WD), 9.5-16 rear; turf: 24x8.50-12 front, 315x75D-15 rear R1 Agricultural, R3 Turf and R4 Industrial: 18x8.5-10 front, 26x12.00-12 rear R1 Agricultural - Front 5.00-12 (2WD); 6-12 (4WD) 18x8.5-10 R1 Agricultural - Rear 9.5-16 26x12.00-12 R3 Turf - Front 24x8.50-12 18x8.5-10 R3 Turf - Rear 315x75D-15 26x12.00-12 R4 Industrial - Front Not Published 18x8.5-10 R4 Industrial - Rear Not Published 26x12.00-12 ▶ Loader & AttachmentsQuick Attach Loader System Not Published Quick attach (QA) bucket, 48 in Loader Model 1242 SL2410 Loader Lift Height 1242: 73.5 in SL2410: 70.9 in Loader Lift Capacity (Full Height) 1242: 565 lb SL2410: 683.4 lb Loader Breakout Force 1242: 955 lb SL2410: 1,435.2 lb ▶ WarrantyWarranty Length & Coverage Not Published Tractors (Non-Commercial Application): 24 months, unlimited hours, parts & labor; Non-commercial powertrain (engine and driveline) on qualifying tractors: 72 months, unlimited hours, parts & labor ▶ ITC Company AccessoriesAccessories that fit None tagged yet
