▶ EngineEngine Manufacturer Iseki Kubota Engine Model E3112 D1005-E-D16 Engine Type 3-cylinder liquid-cooled inline indirect-injection diesel Diesel, 3-cylinder, liquid-cooled No. of Cylinders 3 3 Displacement 68.5 in³ 61.1 in³ Rated Engine Speed 2500 rpm 2600 rpm Engine Power (Gross) 21 hp 21 hp PTO Power Gear: 17.5 hp; Hydro: 16 hp Gear: 17 hp; Hydro: 16 hp Engine Emissions Constraints Not Published Not Published Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dry Dual paper element Fuel System Indirect injection, glow plug pre-heating Not Published Alternator 40 A Not Published ▶ HydraulicsPump Type Not Published Not Published Implement Flow 5.2 gpm Not Published Steering Flow 2.5 gpm Not Published Total Hydraulic Flow 7.7 gpm 7 gpm Overall Hydraulic Pump Flow Not Published Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves 1 or 2 Not Published ▶ Fluid CapacityFuel Tank Capacity 4.75 gal 5 gal Coolant Capacity 5.4 qt 4 qt Crankcase Capacity 3.3 qt 3.2 qt Transmission / Hydraulic System Capacity 2.64 gal Not Published Front Axle Fluid Capacity Not Published 3.4 qt ▶ PTO & HitchPTO Type Live, two-stage dry disc clutch Gear: transmission-driven; Hydro: independent PTO Rear 540 rpm (1.375 in) at 2327 engine rpm 540 rpm Mid-PTO Availability Live, 2000 rpm at 2500 engine rpm Mid-PTO, 2500 rpm Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1,210 lb 1356 lb Hitch Lift Capacity (at 24”) Not Published 1058 lb Lift Control Type Position control Directional control ▶ Transmission & DrivetrainTransmission Type 6-speed gear, hydrostatic, or 9-speed gear with optional creeper range 6-speed gear; hydrostatic No. of Speeds Gear: 6F / 2R (9F / 3R with creeper); hydrostatic: infinite forward and reverse, 2 ranges Gear: 6 forward, 2 reverse; Hydro: infinite (2-range) Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch 8.5 in dry disc (gear) Dry disc (gear) Differential Lock & Limited Slip Options Mechanical rear differential lock Mechanical rear differential lock ▶ Chassis, Steering & ControlsFrame Type Two-post folding ROPS Two-post ROPS Steering 2WD: power steering standard; 4WD: manual, power assist optional Power steering Brakes Mechanical wet disc Wet disc Seat Suspension & Adjustability Not Published Not Published Front Axle Type 2WD or 4WD; spur gear final drives Spur gear final drives Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 108.3 in 90.4 in Overall Width 42.2 in 42.4 in Wheelbase 59.4 in 59 in Ground Clearance 11 in 12 in Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS 77 in 76.4 in Height to Top of ROPS (folded) 60.5 in Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 1,477 lb (2WD gear); 1,500 lb (2WD hydro); 1,654 lb (4WD gear); 1,676 lb (4WD hydro) Gear: 1323 lb; Hydro: 1367 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Ag: 5.00-12 front (2WD) or 6-12 front (4WD), 9.5-16 rear; turf: 24x8.50-12 front, 315x75D-15 rear Standard farm 6-12 front, 9.5-16 rear R1 Agricultural - Front 5.00-12 (2WD); 6-12 (4WD) 6-12 R1 Agricultural - Rear 9.5-16 9.5-16 R3 Turf - Front 24x8.50-12 Not Published R3 Turf - Rear 315x75D-15 Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Not Published LA272 and LA302 loaders offered Loader Model 1242 LA272; LA302 Loader Lift Height 1242: 73.5 in LA272: 69.7 in; LA302: 69.5 in Loader Lift Capacity (Full Height) 1242: 565 lb LA272: 685 lb; LA302: 770 lb Loader Breakout Force 1242: 955 lb LA272: 1003 lbf; LA302: 1120 lbf ▶ WarrantyWarranty Length & Coverage Not Published Not Published
