▶ EngineEngine Manufacturer Iseki Yanmar Engine Model E3112 3TNV76F Engine Type 3-cylinder liquid-cooled inline indirect-injection diesel 3-cylinder, indirect injection (swirl chamber), water-cooled No. of Cylinders 3 3 Displacement 68.5 in³ 68.0 in³ Rated Engine Speed 2500 rpm 3000 rpm Engine Power (Gross) 21 hp 21.5 hp PTO Power Gear: 17.5 hp; Hydro: 16 hp 15 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Liquid-cooled Water-cooled Air Cleaner Dry Dry Fuel System Indirect injection, glow plug pre-heating In-line injection pump Alternator 40 A 40 A, 12 V ▶ HydraulicsPump Type Not Published Gear pump, transmission driven Implement Flow 5.2 gpm 4.6 gpm Steering Flow 2.5 gpm 2.1 gpm Total Hydraulic Flow 7.7 gpm 6.7 gpm Overall Hydraulic Pump Flow Not Published 6.7 gpm Hydraulic System Type Open center Open center system, position control Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published 0 No. of Optional Remote Valves 1 or 2 1 pair (2 quick couplers) ▶ Fluid CapacityFuel Tank Capacity 4.75 gal 6.6 gal Coolant Capacity 5.4 qt 0.9 gal Crankcase Capacity 3.3 qt 0.8 gal Transmission / Hydraulic System Capacity 2.64 gal 3.0 gal (3.4 gal with front-end loader; 4.7 gal with front-end loader and backhoe) Front Axle Fluid Capacity Not Published 0.5 gal ▶ PTO & HitchPTO Type Live, two-stage dry disc clutch Independent (electro-hydraulic) PTO Rear 540 rpm (1.375 in) at 2327 engine rpm Standard (540 rpm) Mid-PTO Availability Live, 2000 rpm at 2500 engine rpm Standard (2,500 rpm) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1,210 lb 970 lb Hitch Lift Capacity (at 24”) Not Published 728 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type 6-speed gear, hydrostatic, or 9-speed gear with optional creeper range Hydrostatic Drive No. of Speeds Gear: 6F / 2R (9F / 3R with creeper); hydrostatic: infinite forward and reverse, 2 ranges 2 ranges Max Travel Speed (Forward) Not Published 8.70 mph Max Travel Speed (Reverse) Not Published 5.22 mph Clutch 8.5 in dry disc (gear) Not Published Differential Lock & Limited Slip Options Mechanical rear differential lock Mechanical pedal type ▶ Chassis, Steering & ControlsFrame Type Two-post folding ROPS Not Published Steering 2WD: power steering standard; 4WD: manual, power assist optional Hydrostatic power steering Brakes Mechanical wet disc Wet, multi-disc Seat Suspension & Adjustability Not Published High-Back Seat with Foldable Armrest and Retractable Seatbelt; fore/aft adjustable Front Axle Type 2WD or 4WD; spur gear final drives Front wheel mechanical assist (4WD) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Hitch: 882 lb vertical, 3,527 lb horizontal; drawbar with clevis: 772 lb vertical, 3,527 lb horizontal ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 108.3 in 97 in Overall Width 42.2 in 47 in Wheelbase 59.4 in 56 in Ground Clearance 11 in Not Published Min. Turn Radius without Brakes Not Published 7.87 ft Height to Top of ROPS 77 in 87 in Height to Top of ROPS (folded) 60.5 in Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 1,477 lb (2WD gear); 1,500 lb (2WD hydro); 1,654 lb (4WD gear); 1,676 lb (4WD hydro) 1,433 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Ag: 5.00-12 front (2WD) or 6-12 front (4WD), 9.5-16 rear; turf: 24x8.50-12 front, 315x75D-15 rear Front 18x8.50-10, rear 26x12.0-12; offered in industrial or turf R1 Agricultural - Front 5.00-12 (2WD); 6-12 (4WD) Not Published R1 Agricultural - Rear 9.5-16 Not Published R3 Turf - Front 24x8.50-12 18x8.50-10 R3 Turf - Rear 315x75D-15 26x12.0-12 R4 Industrial - Front Not Published 18x8.50-10 R4 Industrial - Rear Not Published 26x12.0-12 ▶ Loader & AttachmentsQuick Attach Loader System Not Published LL1101: Pin-Type Bucket (standard); Quick Attach Assembly (Optional) - Compact Type (dual-lever LH/RH); LL1700: Quick Attach Implement System Loader Model 1242 LL1101; LL1100 Loader Lift Height 1242: 73.5 in LL1101: 72.0 in; LL1100: 72.0 in (at pivot pin) Loader Lift Capacity (Full Height) 1242: 565 lb LL1101: 966 lb; LL1100: 1,005 lb (at pivot pin, maximum height) Loader Breakout Force 1242: 955 lb LL1101: 1,960 lb; LL1100: 2,083 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage Not Published 6-year limited warranty
