▶ EngineEngine Manufacturer Iseki Iseki Engine Model E3112 Not Published Engine Type 3-cylinder liquid-cooled inline indirect-injection diesel 3-cylinder, liquid-cooled diesel No. of Cylinders 3 3 Displacement 68.5 in³ 68.5 in³ Rated Engine Speed 2500 rpm 2600 rpm Engine Power (Gross) 21 hp 22.5 hp PTO Power Gear: 17.5 hp; Hydro: 16 hp 18.7 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dry Not Published Fuel System Indirect injection, glow plug pre-heating Not Published Alternator 40 A Not Published ▶ HydraulicsPump Type Not Published Not Published Implement Flow 5.2 gpm 4.3 gpm Steering Flow 2.5 gpm 2 gpm Total Hydraulic Flow 7.7 gpm 6.3 gpm Overall Hydraulic Pump Flow Not Published Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves 1 or 2 Not Published ▶ Fluid CapacityFuel Tank Capacity 4.75 gal 6.6 gal Coolant Capacity 5.4 qt Not Published Crankcase Capacity 3.3 qt Not Published Transmission / Hydraulic System Capacity 2.64 gal Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Live, two-stage dry disc clutch Independent PTO Rear 540 rpm (1.375 in) at 2327 engine rpm 540 rpm Mid-PTO Availability Live, 2000 rpm at 2500 engine rpm Independent, 2000 rpm Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1,210 lb 1,190 lb Hitch Lift Capacity (at 24”) Not Published Not Published Lift Control Type Position control Rate of drop control (standard) ▶ Transmission & DrivetrainTransmission Type 6-speed gear, hydrostatic, or 9-speed gear with optional creeper range 2-range hydrostatic with side-by-side foot pedals and cruise control No. of Speeds Gear: 6F / 2R (9F / 3R with creeper); hydrostatic: infinite forward and reverse, 2 ranges Infinite forward and reverse (2-range hydrostatic) Max Travel Speed (Forward) Not Published 9.1 mph (with R1 tires) Max Travel Speed (Reverse) Not Published Not Published Clutch 8.5 in dry disc (gear) Not Published Differential Lock & Limited Slip Options Mechanical rear differential lock Mechanical rear differential lock ▶ Chassis, Steering & ControlsFrame Type Two-post folding ROPS Not Published Steering 2WD: power steering standard; 4WD: manual, power assist optional Power steering Brakes Mechanical wet disc Wet disc Seat Suspension & Adjustability Not Published Coil spring seat; retractable seat belt Front Axle Type 2WD or 4WD; spur gear final drives 4WD front axle Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 108.3 in 97.6 in Overall Width 42.2 in 47.25 in Wheelbase 59.4 in 57.1 in Ground Clearance 11 in 6.7 in Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS 77 in 72.8 in Height to Top of ROPS (folded) 60.5 in Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 1,477 lb (2WD gear); 1,500 lb (2WD hydro); 1,654 lb (4WD gear); 1,676 lb (4WD hydro) 1,433 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Ag: 5.00-12 front (2WD) or 6-12 front (4WD), 9.5-16 rear; turf: 24x8.50-12 front, 315x75D-15 rear Ag, turf or industrial: front 18x8.50-10, rear 26x12.00-12 R1 Agricultural - Front 5.00-12 (2WD); 6-12 (4WD) 18x8.50-10 R1 Agricultural - Rear 9.5-16 26x12.00-12 R3 Turf - Front 24x8.50-12 18x8.50-10 R3 Turf - Rear 315x75D-15 26x12.00-12 R4 Industrial - Front Not Published 18x8.50-10 R4 Industrial - Rear Not Published 26x12.00-12 ▶ Loader & AttachmentsQuick Attach Loader System Not Published DL95: pin-on (factory or dealer installation) Loader Model 1242 DL95 Loader Lift Height 1242: 73.5 in DL95: 72.8 in Loader Lift Capacity (Full Height) 1242: 565 lb DL95: 870 lb Loader Breakout Force 1242: 955 lb DL95: 920 lb ▶ WarrantyWarranty Length & Coverage Not Published 5-year powertrain warranty
