▶ EngineEngine Manufacturer Iseki Kubota Engine Model E3CD D1305-E4-D26-R Engine Type 3-cylinder, liquid-cooled diesel 3-cylinder, indirect injection, liquid-cooled diesel No. of Cylinders 3 3 Displacement 91.4 in³ 77.0 in³ Rated Engine Speed 2600 rpm 2500 rpm Engine Power (Gross) 24.8 hp 24.8 hp PTO Power 20.1 hp 19.5 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid cooled Liquid-cooled, pressurized radiator Air Cleaner Not Published 4.0 in dual paper element Fuel System Not Published Indirect injection Alternator Not Published B2650HSD (ROPS): 14.5 A; B2650HSDC (cab): 40 A, 12 V ▶ HydraulicsPump Type Not Published Dual pump Implement Flow 5.5 gpm 5.3 gpm Steering Flow 3.2 gpm Not Published Total Hydraulic Flow 8.7 gpm 8.7 gpm Overall Hydraulic Pump Flow 8.7 gpm 8.7 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow 5.5 gpm Not Published No. of Standard Remote Valves Not Published 1 (rear outlet) No. of Optional Remote Valves 1 Not Published ▶ Fluid CapacityFuel Tank Capacity 7.1 gal 7.3 gal Coolant Capacity Not Published 4.5 qt Crankcase Capacity Not Published 4.2 qt Transmission / Hydraulic System Capacity Not Published 4.0 gal Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability Independent, 2000 rpm (optional) 2500 rpm Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1,322 lb 2,139 lb Hitch Lift Capacity (at 24”) 992 lb 1,676 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type Hydrostatic Hydrostatic transmission, 3-range No. of Speeds 3 hydrostatic ranges with cruise 3-range Max Travel Speed (Forward) Not Published 11.9 mph Max Travel Speed (Reverse) Not Published 9.5 mph Clutch Not Published Not Published Differential Lock & Limited Slip Options Mechanical rear differential lock Differential lock standard ▶ Chassis, Steering & ControlsFrame Type Not Published Two-post foldable ROPS (cab optional) Steering Power steering Hydraulic power steering Brakes Wet, multiple disc Multi-plate wet disc Seat Suspension & Adjustability Adjustable mechanical suspension Deluxe seat, parallel link with damper seat suspension Front Axle Type Not Published Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 55.1 in 53.7 in Wheelbase 61.4 in 65.6 in Ground Clearance 11.6 in 14.6 in Min. Turn Radius without Brakes Not Published 6.9 ft (with brake applied) Height to Top of ROPS 96.1 in 88.4 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published 84.6 in Overall Length 111 in 101.2 in (without 3-point hitch) ▶ WeightTractor Weight (Base) 2,077 lb 1,786 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial Standard farm: 7-12 front, 12.4-16 rear; turf and industrial optional R1 Agricultural - Front 7-12 7-12 R1 Agricultural - Rear 35x12.00-16.5 or 9.5-16 12.4-16 R3 Turf - Front 25x8.50-14 24x8.50-14 R3 Turf - Rear 36x13.50-15 13.6-16 R4 Industrial - Front 25x8.50-14 23x8.50-14 R4 Industrial - Rear 14-17 12.4-16 ▶ Loader & AttachmentsQuick Attach Loader System Not Published LA534A: 2-lever quick coupler (optional) Loader Model FLx2106 LA534A Loader Lift Height FLx2106: 83 in (at pivot pin) LA534A: 84.6 in (at pivot pin) Loader Lift Capacity (Full Height) FLx2106: 852 lb (to full height, at 19.5 in forward of pivot pin) LA534A: 1,146 lb (at pivot pin) Loader Breakout Force FLx2106: 1,282 lb (at 19.5 in forward of pivot pin) LA534A: 2,321 lbf (at pivot pin) ▶ WarrantyWarranty Length & Coverage Not Published Not Published
