▶ EngineEngine Manufacturer Iseki Kubota Engine Model E3CD D1703-M-DI-E4 Engine Type 3-cylinder, liquid-cooled diesel Direct injection, vertical, water-cooled, 4-cycle diesel No. of Cylinders 3 3 Displacement 91.4 in³ 100.47 in³ Rated Engine Speed 2600 rpm 2200 rpm Engine Power (Gross) 24.8 hp 24.8 hp PTO Power 20.1 hp 19 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid cooled Water-cooled Air Cleaner Not Published Dry paper single element (dual optional) Fuel System Not Published Direct injection Alternator Not Published 40 A, 12 V ▶ HydraulicsPump Type Not Published Open center tandem pump, gear type Implement Flow 5.5 gpm 5.15 gpm Steering Flow 3.2 gpm 3.11 gpm Total Hydraulic Flow 8.7 gpm 8.26 gpm Overall Hydraulic Pump Flow 8.7 gpm 8.26 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow 5.5 gpm Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves 1 Up to 3: self-canceling detent valve or float detent valve ▶ Fluid CapacityFuel Tank Capacity 7.1 gal 10.0 gal Coolant Capacity Not Published 6.3 qt Crankcase Capacity Not Published 6.0 qt Transmission / Hydraulic System Capacity Not Published HST (4WD): 6.2 gal; DT (2WD): 7.1 gal; DT (4WD): 7.3 gal Front Axle Fluid Capacity Not Published 6.9 qt ▶ PTO & HitchPTO Type Independent F (2WD), DT (4WD): Transmission driven with overrunning clutch; HST (4WD): Live-continuous running PTO Rear 540 rpm 540 rpm Mid-PTO Availability Independent, 2000 rpm (optional) No mid-PTO offered Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1,322 lb 1,918 lb Hitch Lift Capacity (at 24”) 992 lb 1,389 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type Hydrostatic Hydrostatic transmission (3-range) No. of Speeds 3 hydrostatic ranges with cruise 3-range Max Travel Speed (Forward) Not Published 11.5 mph Max Travel Speed (Reverse) Not Published 10.3 mph Clutch Not Published Not Published Differential Lock & Limited Slip Options Mechanical rear differential lock Rear differential lock standard ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Integral type power steering Brakes Wet, multiple disc Wet disc type Seat Suspension & Adjustability Adjustable mechanical suspension Suspension seat with fore/aft travel adjustment and suspension tension adjustment Front Axle Type Not Published Bevel gear front axle, non-adjustable tread spacing Front Axle Rating Not Published 2,865 lb (4WD, at 43.1 in tread) Drawbar Capacity Not Published 730 lb ▶ Dimensions & ManeuverabilityOverall Width 55.1 in 55.1 in Wheelbase 61.4 in 63.3 in Ground Clearance 11.6 in 13.4 in Min. Turn Radius without Brakes Not Published 8.2 ft (with brake applied) Height to Top of ROPS 96.1 in 91.7 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 111 in 106.3 in (without 3-point hitch) ▶ WeightTractor Weight (Base) 2,077 lb 2,623 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural; R4 Industrial R1 Agricultural - Front 7-12 7.2-16 R1 Agricultural - Rear 35x12.00-16.5 or 9.5-16 11.2-24 R3 Turf - Front 25x8.50-14 Not Published R3 Turf - Rear 36x13.50-15 Not Published R4 Industrial - Front 25x8.50-14 27X8.50-15 R4 Industrial - Rear 14-17 15-19.5 ▶ Loader & AttachmentsQuick Attach Loader System Not Published Front Loader (LA525 - 2 Lever Quick Coupler) Loader Model FLx2106 LA525 Loader Lift Height FLx2106: 83 in (at pivot pin) 94.3 in (at pivot pin) Loader Lift Capacity (Full Height) FLx2106: 852 lb (to full height, at 19.5 in forward of pivot pin) 1,082 lb (at pivot pin) Loader Breakout Force FLx2106: 1,282 lb (at 19.5 in forward of pivot pin) 2,373 lbf (at pivot pin) ▶ WarrantyWarranty Length & Coverage Not Published Residential: basic 24 months or 1,500 hours, powertrain 72 months or 2,000 hours; commercial: basic 24 months or 1,500 hours, powertrain 36 months or 2,000 hours ▶ ITC Company AccessoriesAccessories that fit None tagged yet
