▶ EngineEngine Manufacturer Iseki Yanmar Engine Model Not Published 3TNE84 Engine Type 3-cylinder liquid-cooled diesel 3-cylinder liquid-cooled diesel, direct injection No. of Cylinders 3 3 Displacement 91.4 in³ 91.3 in³ Rated Engine Speed 2600 rpm 2700 rpm Engine Power (Gross) 32.6 hp 32.2 hp PTO Power Gear: 25.6 hp; HST: 24.1 hp 27 hp Engine Emissions Constraints Not Published Not Published Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dry Dry type with safety element Fuel System Not Published Direct injection, self-bleeding in-line fuel pump, electric shutoff Alternator Not Published 40 A ▶ HydraulicsPump Type Not Published Dual gear pump Implement Flow 9.1 gpm 8.3 gpm Steering Flow SynchroShuttle: 4.9 gpm; HST and PowerShuttle: 6 gpm 5.0 gpm Total Hydraulic Flow SynchroShuttle: 14.0 gpm; HST and PowerShuttle: 15.1 gpm 13.3 gpm Overall Hydraulic Pump Flow Not Published 13.3 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow 9.1 gpm Not Published No. of Standard Remote Valves Not Published 2 No. of Optional Remote Valves 2 spool optional Not Published ▶ Fluid CapacityFuel Tank Capacity 10.6 gal 10.0 gal Coolant Capacity 7.1 qt 6.1 qt Crankcase Capacity 5 qt 4.5 qt Transmission / Hydraulic System Capacity 32.8 qt 6.3 gal (gear); 6.9 gal (hydrostatic) Front Axle Fluid Capacity 7.9 qt 4.7 qt ▶ PTO & HitchPTO Type Independent, electro-hydraulic control Independent, wet disk clutch and brake PTO Rear 540 rpm 540 rpm Mid-PTO Availability Optional, 2000 rpm Available, 2100 rpm Category, 3-Point Hitch Category I Category 1 Hitch Lift Capacity 2,800 lb Not Published Hitch Lift Capacity (at 24”) Not Published 2,200 lb Lift Control Type Position control with rate of drop control Not Published ▶ Transmission & DrivetrainTransmission Type 8x8 SynchroShuttle (platform only), 12x12 PowerShuttle, or 3-range hydrostatic with cruise (platform only) SyncShift 9F/3R gear (2WD and 4WD); SyncReverser 12F/12R (4WD only); hydrostatic 3-range (2WD and 4WD) No. of Speeds Not Published 9 forward, 3 reverse (SyncShift); 12 forward, 12 reverse (SyncReverser); infinite forward and reverse, 3 ranges (hydrostatic) Max Travel Speed (Forward) Not Published 15.6 mph (SyncShift); 15.6 mph (SyncReverser); 15.5 mph (hydrostatic) Max Travel Speed (Reverse) Not Published 7.7 mph (SyncShift); 15.5 mph (hydrostatic) Clutch Wet multi-disc (PowerShuttle) 1 multi-disk wet clutch, 4.88 in (SyncShift); 2 multi-disk wet clutches, 4.88 in (SyncReverser) Differential Lock & Limited Slip Options Not Published Mechanical rear differential lock ▶ Chassis, Steering & ControlsFrame Type Semi-flat isolated platform, folding ROPS Standard ROPS or folding ROPS; 2WD or MFWD Steering Power steering Power steering, cylinder-assisted Brakes Wet disc Wet disk Seat Suspension & Adjustability Spring-suspension seat with forward/back and weight adjustment, retractable seat belt Not Published Front Axle Type 4WD front axle 2WD standard; MFWD optional, all ranges Front Axle Rating Not Published 1,588 to 3,197 lb Drawbar Capacity Not Published 562 lb ▶ Dimensions & ManeuverabilityOverall Width 62.0 in 50.0 in (minimum); 66.7 in (maximum) Wheelbase 70.0 in 68.0 in Ground Clearance 14.0 in 13.4 in (rear axle) Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS 87.4 in 84.0 in (standard ROPS); 90.0 in (folding ROPS) Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 121.0 in 117 in (with 3-point hitch) ▶ WeightTractor Weight (Base) Platform: 3,025 lb; Cab: 3,384 lb (shipping weight) 2,600 lb (2WD); 2,900 lb (MFWD) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Ag: 8-16 front, 12.4-24 rear (13.6-24 optional); turf: 27x8.50-15 front, 41x14.00-20 rear (LSW305 R343 / LSW610 R470 optional); industrial: 10-16.5 front, 14.9-24 rear (also 25x8.5-14 front, 15x19.5 rear) Front: 5.00-15 F2 (2WD), 7.00-14 or 7.00-16 R1, 25x8.50-14 R4, 27x8.50-15 R3, 25-10.50LLx15 golf; rear: 11.2-24 or 12.4-24 R1, 11.2-24 or 41x14.00-20 R3, 15.00-19.5 R4, 41LLx18.00-16 golf R1 Agricultural - Front 8-16 5.00-15 (2WD, F2); 7.00-14 or 7.00-16 (MFWD) R1 Agricultural - Rear 12.4-24 (13.6-24 optional) 11.2-24 or 12.4-24 R3 Turf - Front 27x8.50-15 (LSW305 R343 optional) 27x8.50-15 (2WD); 7.00-14 (MFWD) R3 Turf - Rear 41x14.00-20 (LSW610 R470 optional) 41x14.00-20 or 11.2-24 R4 Industrial - Front 10-16.5 or 25x8.5-14 25x8.50-14 R4 Industrial - Rear 14.9-24 or 15x19.5 15.00-19.5 ▶ Loader & AttachmentsQuick Attach Loader System DL120: pin-type or skid-steer quick attach Not Published Loader Model DL120 420; 430 Loader Lift Height DL120: 102 in (at pivot pin) 420: 87.6 in; 430: 101.4 in Loader Lift Capacity (Full Height) DL120: 1,900 lb (to full height, at pivot pin) 420: 1,195 lb; 430: 1,258 lb (to max height at pivot point) Loader Breakout Force Not Published 420: 2,693 lbf; 430: 3,299 lbf (at pivot point) ▶ WarrantyWarranty Length & Coverage Basic 2 years or 2,000 hours; powertrain 3 years or 2,000 hours Not Published
