▶ EngineEngine Manufacturer Iseki Kubota Engine Model Not Published F (2WD gear), DT (4WD gear): D1803-CR-E4-LB1; HST (4WD): D1803-CR-E4-LB2 Engine Type 3-cylinder liquid-cooled diesel 3-cylinder, multi-valve, naturally aspirated, common-rail, liquid-cooled diesel No. of Cylinders 3 3 Displacement 91.4 in³ 111.4 in³ Rated Engine Speed 2600 rpm 2700 rpm Engine Power (Gross) 32.6 hp 33 hp PTO Power Gear: 25.6 hp; HST: 24.1 hp F (2WD gear), DT (4WD gear): 27.7 hp; HST (4WD): 26.2 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Liquid-cooled Liquid-cooled, water with pressurized radiator Air Cleaner Dry Dry paper single element Fuel System Not Published Common-rail, direct injection, electronic control Alternator Not Published 40 A, 12 V ▶ HydraulicsPump Type Not Published Open center tandem pump, gear type Implement Flow 9.1 gpm 6.3 gpm Steering Flow SynchroShuttle: 4.9 gpm; HST and PowerShuttle: 6 gpm 3.8 gpm Total Hydraulic Flow SynchroShuttle: 14.0 gpm; HST and PowerShuttle: 15.1 gpm 10.1 gpm Overall Hydraulic Pump Flow Not Published 10.1 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow 9.1 gpm Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves 2 spool optional Up to 3: self-canceling detent valve or float detent valve ▶ Fluid CapacityFuel Tank Capacity 10.6 gal 11.1 gal Coolant Capacity 7.1 qt 6.3 qt Crankcase Capacity 5 qt 7.1 qt Transmission / Hydraulic System Capacity 32.8 qt F (2WD gear): 7.4 gal; DT (4WD gear): 7.5 gal; HST (4WD): 6.2 gal Front Axle Fluid Capacity 7.9 qt 4.8 qt ▶ PTO & HitchPTO Type Independent, electro-hydraulic control F (2WD gear), DT (4WD gear): Transmission driven with overrunning clutch; HST (4WD): Live-continuous running PTO Rear 540 rpm 540 rpm Mid-PTO Availability Optional, 2000 rpm No mid-PTO offered Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 2,800 lb 1,874 lb (at lift points) Hitch Lift Capacity (at 24”) Not Published 1,433 lb Lift Control Type Position control with rate of drop control Position control ▶ Transmission & DrivetrainTransmission Type 8x8 SynchroShuttle (platform only), 12x12 PowerShuttle, or 3-range hydrostatic with cruise (platform only) F (2WD gear), DT (4WD gear): manual transmission with synchronized shuttle; HST (4WD): hydrostatic transmission No. of Speeds Not Published F (2WD gear), DT (4WD gear): 8F/8R; HST (4WD): 3-range Max Travel Speed (Forward) Not Published F (2WD gear), DT (4WD gear): 13.2 mph; HST (4WD): 14.1 mph Max Travel Speed (Reverse) Not Published F (2WD gear), DT (4WD gear): 13.1 mph; HST (4WD): 12.7 mph Clutch Wet multi-disc (PowerShuttle) Dry type single stage Differential Lock & Limited Slip Options Not Published Rear differential lock standard ▶ Chassis, Steering & ControlsFrame Type Semi-flat isolated platform, folding ROPS Two-post foldable ROPS (factory certified) with retractable seat belt Steering Power steering Integral power steering Brakes Wet disc Mechanical wet disc type, pedals can be locked together Seat Suspension & Adjustability Spring-suspension seat with forward/back and weight adjustment, retractable seat belt Not Published Front Axle Type 4WD front axle F (2WD gear): tubular steel, non-adjustable tread spacing; DT (4WD gear), HST (4WD): bevel-gear front axle, non-adjustable tread spacing Front Axle Rating Not Published 2,865 lb (at 41.3 in tread, 2WD and 4WD models) Drawbar Capacity Not Published 730 lb ▶ Dimensions & ManeuverabilityOverall Width 62.0 in 55.1 in Wheelbase 70.0 in 63.3 in Ground Clearance 14.0 in F (2WD gear): 13.6 in; DT (4WD gear), HST (4WD): 13.5 in Min. Turn Radius without Brakes Not Published F (2WD gear): 8.9 ft; DT (4WD gear), HST (4WD): 10.5 ft Height to Top of ROPS 87.4 in 97.1 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 121.0 in F (2WD gear): 119.1 in; DT (4WD gear), HST (4WD): 116.3 in (with 3-point hitch) ▶ WeightTractor Weight (Base) Platform: 3,025 lb; Cab: 3,384 lb (shipping weight) F (2WD gear): 2,557 lb; DT (4WD gear): 2,734 lb; HST (4WD): 2,778 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Ag: 8-16 front, 12.4-24 rear (13.6-24 optional); turf: 27x8.50-15 front, 41x14.00-20 rear (LSW305 R343 / LSW610 R470 optional); industrial: 10-16.5 front, 14.9-24 rear (also 25x8.5-14 front, 15x19.5 rear) R1 Agricultural (standard); R3 Turf; R4 Industrial (4WD) R1 Agricultural - Front 8-16 F (2WD gear): 5-15 (7.5L-15 optional); DT (4WD gear), HST (4WD): 7.2-16 R1 Agricultural - Rear 12.4-24 (13.6-24 optional) 11.2-24 R3 Turf - Front 27x8.50-15 (LSW305 R343 optional) F (2WD gear): 23x8.5-12; DT (4WD gear), HST (4WD): 25x8.5-14 R3 Turf - Rear 41x14.00-20 (LSW610 R470 optional) 13.6-16 R4 Industrial - Front 10-16.5 or 25x8.5-14 27x8.5-15 (4WD) R4 Industrial - Rear 14.9-24 or 15x19.5 15-19.5 (4WD) ▶ Loader & AttachmentsQuick Attach Loader System DL120: pin-type or skid-steer quick attach LA525: 2-lever quick coupler, tool-free attach and detach Loader Model DL120 LA525 Loader Lift Height DL120: 102 in (at pivot pin) LA525: 94.3 in (at pivot pin) Loader Lift Capacity (Full Height) DL120: 1,900 lb (to full height, at pivot pin) LA525: 1,131 lb (at pivot pin, maximum height) Loader Breakout Force Not Published LA525: 2,462 lbf (at bucket pivot pin) ▶ WarrantyWarranty Length & Coverage Basic 2 years or 2,000 hours; powertrain 3 years or 2,000 hours 24 months or 1500 hours (general)
