▶ EngineEngine Manufacturer Iseki LS Mtron Engine Model E3CG L3C19-T5 Engine Type 3-cylinder liquid-cooled indirect-injection diesel, naturally aspirated Diesel, 3-cylinder, turbocharged No. of Cylinders 3 3 Displacement 100.5 in³ 116 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 35.7 hp 35 hp PTO Power PowerShuttle: 27.1 hp; HST: 25.8 hp 28 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Not Published Air Cleaner Dry pleated paper, 2 elements Replaceable dry element Fuel System Indirect injection Common rail direct injection Alternator Platform: 40 A; Cab: 60 A 70 A ▶ HydraulicsPump Type Gear pump, engine timing gear driven Not Published Implement Flow 11.6 gpm 8.2 gpm Steering Flow HST: 4.9 gpm; PowerShuttle: 6 gpm 5.3 gpm Total Hydraulic Flow HST: 16.5 gpm; PowerShuttle: 17.6 gpm Not Published Overall Hydraulic Pump Flow Not Published Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow 11.6 gpm Not Published No. of Standard Remote Valves 1 1 No. of Optional Remote Valves Up to 3 2 ▶ Fluid CapacityFuel Tank Capacity Platform: 9.2 gal; Cab: 10.5 gal 10.5 gal Coolant Capacity 6.6 qt Not Published Crankcase Capacity 5.6 qt Not Published Transmission / Hydraulic System Capacity 8.2 gal Not Published Front Axle Fluid Capacity 7.9 qt Not Published ▶ PTO & HitchPTO Type Independent, electro-hydraulic push-button control Independent rear PTO, electro-hydraulic engagement PTO Rear 540 rpm 540 rpm Mid-PTO Availability Optional, 2000 rpm Optional, 2000 rpm Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 2,800 lb 1,808 lb Hitch Lift Capacity (at 24”) 2,535 lb 1,433 lb Lift Control Type Position control with rate of drop control Mechanical draft control (MDC) ▶ Transmission & DrivetrainTransmission Type 12x12 PowerShuttle or 3-range hydrostatic with cruise control 3-range hydrostatic (HST) No. of Speeds Not Published infinitely variable, 3 ranges Max Travel Speed (Forward) Not Published 14.8 mph Max Travel Speed (Reverse) Not Published Not Published Clutch PowerShuttle: dry single disc engine clutch (9.4 in) with wet multi-disc shuttle clutch Not Applicable Differential Lock & Limited Slip Options Mechanical rear differential lock, pedal engaged Mechanical rear differential lock ▶ Chassis, Steering & ControlsFrame Type Flat isolated platform, folding ROPS, one-piece flip-up hood Not Published Steering Hydrostatic power steering, 3-position tilt wheel Power steering Brakes Wet disc Wet multi-disc Seat Suspension & Adjustability Suspended seat with retractable seat belt Adjustable suspension seat Front Axle Type 4WD front axle, mechanical lever engagement, 56 degree steering angle, 1.61 drive ratio Mechanical Front Drive (MFD) Front Axle Rating 3,968 lb Not Published Drawbar Capacity 880 lb Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 122.0 in 122.5 in Overall Width 64.5 in 66.4 in Wheelbase 69.7 in 66 in Ground Clearance 14.2 in Not Published Min. Turn Radius without Brakes 8.2 ft (with brake applied) Not Published Height to Top of ROPS 100.0 in 93.5 in Height to Top of ROPS (folded) Not Published 74.1 in Height to Top of Cab Model 86.6 in Not Published ▶ WeightTractor Weight (Base) Platform: 3,175 lb; Cab: 3,527 lb 3,175 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Ag: 8-16 front, 12.4-24 rear (13.6-24 optional); turf: 27x8.50-15 front, 41x14.00-20 rear (LSW305 R343 / LSW610 R470 optional); industrial: 10-16.5 front, 14.9-24 rear (also 25x8.5-14 front, 15x19.5 rear) R1 Agricultural; R3 Turf; R4 Industrial R1 Agricultural - Front 8-16 7-14 R1 Agricultural - Rear 12.4-24 (13.6-24 optional) 11.2-24 R3 Turf - Front 27x8.50-15 (LSW305 R343 optional) 25x8.50-14 R3 Turf - Rear 41x14.00-20 (LSW610 R470 optional) 41x14.00-20 R4 Industrial - Front 10-16.5 or 25x8.5-14 25x8.50-14 R4 Industrial - Rear 14.9-24 or 15x19.5 43x16.00-20 ▶ Loader & AttachmentsQuick Attach Loader System DL120: pin type or skid steer type quick attach, pedestal mount Quick-Attach faceplate; quick-connect loader mounting (L350A) Loader Model DL120 L350A Loader Lift Height DL120: 102 in 105 in Loader Lift Capacity (Full Height) DL120: 1,900 lb 2,000 lb Loader Breakout Force DL120: 2,562 lb 2,640 lbf ▶ WarrantyWarranty Length & Coverage 2-year/2,000-hour all-inclusive; 3-year/2,000-hour engine and powertrain 6-year (72-month) extended warranty: 2-year bumper-to-bumper plus 4 additional years powertrain
