▶ EngineEngine Manufacturer Iseki Kubota Engine Model E3CG Not Published Engine Type 3-cylinder liquid-cooled indirect-injection diesel, naturally aspirated Vertical, liquid-cooled, 4-cycle diesel, indirect injection (E-TVCS) No. of Cylinders 3 3 Displacement 100.5 in³ 111.4 in³ Rated Engine Speed 2600 rpm 2700 rpm Engine Power (Gross) 35.7 hp 35.7 hp PTO Power PowerShuttle: 27.1 hp; HST: 25.8 hp F (2WD gear), DT (4WD gear): 30 hp; HST (4WD): 28.5 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dry pleated paper, 2 elements Not Published Fuel System Indirect injection Indirect injection (E-TVCS) Alternator Platform: 40 A; Cab: 60 A 40 A, 12 V ▶ HydraulicsPump Type Gear pump, engine timing gear driven Not Published Implement Flow 11.6 gpm 6.3 gpm Steering Flow HST: 4.9 gpm; PowerShuttle: 6 gpm 3.8 gpm Total Hydraulic Flow HST: 16.5 gpm; PowerShuttle: 17.6 gpm 10.1 gpm (6.3 + 3.8, computed) Overall Hydraulic Pump Flow Not Published Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow 11.6 gpm Not Published No. of Standard Remote Valves 1 Not Published No. of Optional Remote Valves Up to 3 Up to 3 ▶ Fluid CapacityFuel Tank Capacity Platform: 9.2 gal; Cab: 10.5 gal 9.0 gal Coolant Capacity 6.6 qt Not Published Crankcase Capacity 5.6 qt Not Published Transmission / Hydraulic System Capacity 8.2 gal 7.3 gal Front Axle Fluid Capacity 7.9 qt 4.8 qt ▶ PTO & HitchPTO Type Independent, electro-hydraulic push-button control F (2WD gear), DT (4WD gear): Live-continuous running; HST (4WD): Live-continuous with overrunning clutch PTO Rear 540 rpm 540 rpm Mid-PTO Availability Optional, 2000 rpm Not Published Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 2,800 lb 1998 lb Hitch Lift Capacity (at 24”) 2,535 lb 1435 lb Lift Control Type Position control with rate of drop control Position control ▶ Transmission & DrivetrainTransmission Type 12x12 PowerShuttle or 3-range hydrostatic with cruise control F (2WD gear), DT (4WD gear): Sliding gear and constant mesh, 8F/4R; HST (4WD): Hydrostatic transmission, 3-range No. of Speeds Not Published F (2WD gear), DT (4WD gear): 8F/4R; HST (4WD): 3-range Max Travel Speed (Forward) Not Published F (2WD gear), DT (4WD gear): 13.2 mph; HST (4WD): 14.1 mph Max Travel Speed (Reverse) Not Published F (2WD gear), DT (4WD gear): 4.7 mph; HST (4WD): 12.7 mph Clutch PowerShuttle: dry single disc engine clutch (9.4 in) with wet multi-disc shuttle clutch F (2WD gear), DT (4WD gear): Dry-type dual stage; HST (4WD): Dry-type single stage Differential Lock & Limited Slip Options Mechanical rear differential lock, pedal engaged Rear differential lock standard ▶ Chassis, Steering & ControlsFrame Type Flat isolated platform, folding ROPS, one-piece flip-up hood Foldable ROPS (standard on all models) Steering Hydrostatic power steering, 3-position tilt wheel Integral type power steering Brakes Wet disc Wet disc type Seat Suspension & Adjustability Suspended seat with retractable seat belt Not Published Front Axle Type 4WD front axle, mechanical lever engagement, 56 degree steering angle, 1.61 drive ratio 4WD: Bevel gear front axle Front Axle Rating 3,968 lb Not Published Drawbar Capacity 880 lb Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 122.0 in F (2WD gear): 110.6 in; DT (4WD gear), HST (4WD): 106.5 in (w/o 3P) (without 3-point hitch) Overall Width 64.5 in 51.4 in Wheelbase 69.7 in 63.3 in Ground Clearance 14.2 in F (2WD gear): 13.6 in; DT (4WD gear), HST (4WD): 13.4 in Min. Turn Radius without Brakes 8.2 ft (with brake applied) F (2WD gear): 7.9 ft; DT (4WD gear), HST (4WD): 8.2 ft (w/brake) (with brake applied) Height to Top of ROPS 100.0 in 85.0 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 86.6 in Not Published ▶ WeightTractor Weight (Base) Platform: 3,175 lb; Cab: 3,527 lb F (2WD gear): 2403 lb; DT (4WD gear): 2580 lb; HST (4WD): 2600 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Ag: 8-16 front, 12.4-24 rear (13.6-24 optional); turf: 27x8.50-15 front, 41x14.00-20 rear (LSW305 R343 / LSW610 R470 optional); industrial: 10-16.5 front, 14.9-24 rear (also 25x8.5-14 front, 15x19.5 rear) AG standard; turf and industrial optional R1 Agricultural - Front 8-16 F (2WD gear): 5-15; DT (4WD gear), HST (4WD): 7-16 R1 Agricultural - Rear 12.4-24 (13.6-24 optional) 11.2-24 R3 Turf - Front 27x8.50-15 (LSW305 R343 optional) 25x8.50-14 (4WD) R3 Turf - Rear 41x14.00-20 (LSW610 R470 optional) 13.6-16 R4 Industrial - Front 10-16.5 or 25x8.5-14 27x8.50-15 (4WD) R4 Industrial - Rear 14.9-24 or 15x19.5 15-19.5 R4 (4WD) ▶ Loader & AttachmentsQuick Attach Loader System DL120: pin type or skid steer type quick attach, pedestal mount LA463: quick attach/detach loader (mounting pins and hose couplers from the seat); skid steer-type quick coupler optional Loader Model DL120 LA463 Loader Lift Height DL120: 102 in LA463: 95.3 in Loader Lift Capacity (Full Height) DL120: 1,900 lb LA463: 1142 lb Loader Breakout Force DL120: 2,562 lb Not Published ▶ WarrantyWarranty Length & Coverage 2-year/2,000-hour all-inclusive; 3-year/2,000-hour engine and powertrain Not Published
