▶ EngineEngine Manufacturer Iseki Iseki Engine Model E3CG Not Published Engine Type 3-cylinder liquid-cooled indirect-injection diesel, naturally aspirated 3-cylinder turbocharged diesel, liquid-cooled No. of Cylinders 3 3 Displacement 100.5 in³ 111.4 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 35.7 hp 34.5 hp PTO Power PowerShuttle: 27.1 hp; HST: 25.8 hp 29.2 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dry pleated paper, 2 elements Not Published Fuel System Indirect injection Not Published Alternator Platform: 40 A; Cab: 60 A Not Published ▶ HydraulicsPump Type Gear pump, engine timing gear driven Two gear-type pumps, one for steering and one for 3-point and remotes Implement Flow 11.6 gpm 7.6 gpm Steering Flow HST: 4.9 gpm; PowerShuttle: 6 gpm 3.8 gpm Total Hydraulic Flow HST: 16.5 gpm; PowerShuttle: 17.6 gpm 11.4 gpm Overall Hydraulic Pump Flow Not Published Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow 11.6 gpm Not Published No. of Standard Remote Valves 1 Not Published No. of Optional Remote Valves Up to 3 Not Published ▶ Fluid CapacityFuel Tank Capacity Platform: 9.2 gal; Cab: 10.5 gal 10.0 gal Coolant Capacity 6.6 qt 7.61 qt Crankcase Capacity 5.6 qt 5.47 qt Transmission / Hydraulic System Capacity 8.2 gal Not Published Front Axle Fluid Capacity 7.9 qt 6.0 qt ▶ PTO & HitchPTO Type Independent, electro-hydraulic push-button control 8x8 Synchro Shuttle: independent; HST: transmission driven PTO Rear 540 rpm 540 rpm (1-3/8 in 6-spline) Mid-PTO Availability Optional, 2000 rpm Not Published Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 2,800 lb 2,205 lb Hitch Lift Capacity (at 24”) 2,535 lb 1,598 lb Lift Control Type Position control with rate of drop control Not Published ▶ Transmission & DrivetrainTransmission Type 12x12 PowerShuttle or 3-range hydrostatic with cruise control 8 x 8 synchro shuttle or 3-range hydrostatic No. of Speeds Not Published 8x8 Synchro Shuttle: 8F / 8R; HST: 3-range infinite Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch PowerShuttle: dry single disc engine clutch (9.4 in) with wet multi-disc shuttle clutch Not Published Differential Lock & Limited Slip Options Mechanical rear differential lock, pedal engaged Mechanical rear differential lock ▶ Chassis, Steering & ControlsFrame Type Flat isolated platform, folding ROPS, one-piece flip-up hood Not Published Steering Hydrostatic power steering, 3-position tilt wheel Power steering Brakes Wet disc Wet disc Seat Suspension & Adjustability Suspended seat with retractable seat belt Not Published Front Axle Type 4WD front axle, mechanical lever engagement, 56 degree steering angle, 1.61 drive ratio Not Published Front Axle Rating 3,968 lb Not Published Drawbar Capacity 880 lb Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 122.0 in 116.5 in Overall Width 64.5 in 52.4 in Wheelbase 69.7 in Not Published Ground Clearance 14.2 in 11.0 in Min. Turn Radius without Brakes 8.2 ft (with brake applied) Not Published Height to Top of ROPS 100.0 in 97.6 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 86.6 in Not Published ▶ WeightTractor Weight (Base) Platform: 3,175 lb; Cab: 3,527 lb 2,877 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Ag: 8-16 front, 12.4-24 rear (13.6-24 optional); turf: 27x8.50-15 front, 41x14.00-20 rear (LSW305 R343 / LSW610 R470 optional); industrial: 10-16.5 front, 14.9-24 rear (also 25x8.5-14 front, 15x19.5 rear) Not Published R1 Agricultural - Front 8-16 Not Published R1 Agricultural - Rear 12.4-24 (13.6-24 optional) Not Published R3 Turf - Front 27x8.50-15 (LSW305 R343 optional) Not Published R3 Turf - Rear 41x14.00-20 (LSW610 R470 optional) Not Published R4 Industrial - Front 10-16.5 or 25x8.5-14 Not Published R4 Industrial - Rear 14.9-24 or 15x19.5 Not Published ▶ Loader & AttachmentsQuick Attach Loader System DL120: pin type or skid steer type quick attach, pedestal mount FLx2407: skid steer quick attach Loader Model DL120 FLx2407 Loader Lift Height DL120: 102 in FLx2407: 94.3 in Loader Lift Capacity (Full Height) DL120: 1,900 lb FLx2407: 1,450 lb Loader Breakout Force DL120: 2,562 lb FLx2407: 2,288 lb ▶ WarrantyWarranty Length & Coverage 2-year/2,000-hour all-inclusive; 3-year/2,000-hour engine and powertrain 5-year powertrain warranty
