▶ EngineEngine Manufacturer Iseki LS Mtron Engine Model E3CG L3C19-T5 Engine Type 3-cylinder liquid-cooled indirect-injection diesel, naturally aspirated 3-cylinder, turbocharged, liquid-cooled diesel No. of Cylinders 3 3 Displacement 100.5 in³ 114.7 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 35.7 hp 35 hp PTO Power PowerShuttle: 27.1 hp; HST: 25.8 hp Gear: 29.7 hp; HST: 28 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Pressurized liquid with recirculating bypass Air Cleaner Dry pleated paper, 2 elements Dual element dry air cleaner (primary and inner safety element) Fuel System Indirect injection High pressure common rail, ECU-controlled timing Alternator Platform: 40 A; Cab: 60 A 70 A, 12 V ▶ HydraulicsPump Type Gear pump, engine timing gear driven Gear Implement Flow 11.6 gpm 8.2 gpm Steering Flow HST: 4.9 gpm; PowerShuttle: 6 gpm Gear: 4.2 gpm; HST: 5.3 gpm Total Hydraulic Flow HST: 16.5 gpm; PowerShuttle: 17.6 gpm Gear: 12.4 gpm; HST: 13.5 gpm Overall Hydraulic Pump Flow Not Published Gear: 12.4 gpm; HST: 13.5 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow 11.6 gpm Not Published No. of Standard Remote Valves 1 0 No. of Optional Remote Valves Up to 3 1 or 2 ▶ Fluid CapacityFuel Tank Capacity Platform: 9.2 gal; Cab: 10.5 gal 7.4 gal Coolant Capacity 6.6 qt 7.5 qt Crankcase Capacity 5.6 qt 5.8 qt Transmission / Hydraulic System Capacity 8.2 gal 8.5 gal Front Axle Fluid Capacity 7.9 qt 6.9 qt ▶ PTO & HitchPTO Type Independent, electro-hydraulic push-button control Independent, electro-hydraulic engagement PTO Rear 540 rpm 540 rpm Mid-PTO Availability Optional, 2000 rpm HST: Standard; Gear: Optional (2,000 rpm) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 2,800 lb 1,808 lb Hitch Lift Capacity (at 24”) 2,535 lb 1,433 lb Lift Control Type Position control with rate of drop control Position control ▶ Transmission & DrivetrainTransmission Type 12x12 PowerShuttle or 3-range hydrostatic with cruise control Gear: 12x12 synchronized shuttle; HST: 3-range hydrostatic, dual pedal No. of Speeds Not Published Gear: 12F/12R; HST: Infinite (3 ranges) Max Travel Speed (Forward) Not Published Gear: 14.2 mph; HST: 14.8 mph Max Travel Speed (Reverse) Not Published Gear: 13.63 mph; HST: 14.96 mph Clutch PowerShuttle: dry single disc engine clutch (9.4 in) with wet multi-disc shuttle clutch Gear: 9.4 in single dry disc; HST: Not applicable Differential Lock & Limited Slip Options Mechanical rear differential lock, pedal engaged Mechanical rear differential lock ▶ Chassis, Steering & ControlsFrame Type Flat isolated platform, folding ROPS, one-piece flip-up hood Not Published Steering Hydrostatic power steering, 3-position tilt wheel Power steering Brakes Wet disc Wet disc Seat Suspension & Adjustability Suspended seat with retractable seat belt Mechanical suspension seat, fore/aft adjustable, tilting Front Axle Type 4WD front axle, mechanical lever engagement, 56 degree steering angle, 1.61 drive ratio 4WD Front Axle Rating 3,968 lb Not Published Drawbar Capacity 880 lb Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 122.0 in 121 in Overall Width 64.5 in 66.5 in Wheelbase 69.7 in 67.5 in Ground Clearance 14.2 in 13 in Min. Turn Radius without Brakes 8.2 ft (with brake applied) 123 in (left turn); 124 in (right turn) Height to Top of ROPS 100.0 in 87.7 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 86.6 in Not Published ▶ WeightTractor Weight (Base) Platform: 3,175 lb; Cab: 3,527 lb 3,067 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Ag: 8-16 front, 12.4-24 rear (13.6-24 optional); turf: 27x8.50-15 front, 41x14.00-20 rear (LSW305 R343 / LSW610 R470 optional); industrial: 10-16.5 front, 14.9-24 rear (also 25x8.5-14 front, 15x19.5 rear) R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front 8-16 7-14 R1 Agricultural - Rear 12.4-24 (13.6-24 optional) 11.2-24 R3 Turf - Front 27x8.50-15 (LSW305 R343 optional) 25x8.50-14 R3 Turf - Rear 41x14.00-20 (LSW610 R470 optional) 41x14.00-20 R4 Industrial - Front 10-16.5 or 25x8.5-14 25x8.50-14 R4 Industrial - Rear 14.9-24 or 15x19.5 43x16-20 ▶ Loader & AttachmentsQuick Attach Loader System DL120: pin type or skid steer type quick attach, pedestal mount 140TL: Quick Mount system, no tools needed; optional skid steer quick attach plates Loader Model DL120 140TL Loader Lift Height DL120: 102 in 140TL: 91.5 in Loader Lift Capacity (Full Height) DL120: 1,900 lb 140TL: 1,500 lb Loader Breakout Force DL120: 2,562 lb 140TL: 2,700 lb ▶ WarrantyWarranty Length & Coverage 2-year/2,000-hour all-inclusive; 3-year/2,000-hour engine and powertrain Boomer Guard6 limited warranty: 2 years or 750 hours full coverage plus powertrain coverage to 6 years or 1,500 hours total
