▶ EngineEngine Manufacturer Shibaura TYM Engine Model Not Published A1100N2 Engine Type 3-cylinder diesel, liquid-cooled 3 cylinder, water-cooled diesel, swirl chamber, natural aspiration No. of Cylinders 3 3 Displacement 91.5 in³ 70.7 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 24 hp 24 hp PTO Power Gear: 20.4 hp; HST: 19.2 hp 18 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Water-cooled Air Cleaner Not Published Dry element Fuel System Indirect low-pressure injection Indirect injection (swirl chamber) Alternator Not Published 50 A, 12 V ▶ HydraulicsPump Type Gear-type pump Gear type pump with primary and secondary pumps Implement Flow Not Published 4.3 gpm Steering Flow 3.8 gpm 3.1 gpm Total Hydraulic Flow 10.5 gpm 7.4 gpm Overall Hydraulic Pump Flow Not Published 7.7 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow 6.7 gpm Not Published No. of Standard Remote Valves Not Published 0 No. of Optional Remote Valves Up to 2 1 ▶ Fluid CapacityFuel Tank Capacity 10.0 gal 6.08 gal Coolant Capacity 1.32 gal 1.21 gal Crankcase Capacity 1.22 gal 0.79 gal Transmission / Hydraulic System Capacity 10.04 gal 2.90 gal Front Axle Fluid Capacity 1.48 gal 0.79 gal ▶ PTO & HitchPTO Type Transmission driven Live PTO (6 spline shaft) PTO Rear 540 rpm (1-3/8 in 6-spline) 540 / 960 rpm Mid-PTO Availability Not Published Optional, 2,500 rpm Category, 3-Point Hitch Category I Category 1 Hitch Lift Capacity 2,205 lb 1,433 lb Hitch Lift Capacity (at 24”) 1,600 lb 974 lb Lift Control Type Not Published Position control ▶ Transmission & DrivetrainTransmission Type 9 x 3 mechanical shift constant mesh gears or 3-range hydrostatic Hydrostatic (HST) No. of Speeds Gear: 9F / 3R; HST: 3-range infinite 3 range (L/M/H) Max Travel Speed (Forward) Not Published 14.8 mph Max Travel Speed (Reverse) Not Published 14.8 mph Clutch Gear: dry single disc Dry, single plate Differential Lock & Limited Slip Options Mechanical engagement via heel pedal Mechanical rear differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Steel frame with cast iron axles Steering Power steering Hydrostatic power steering Brakes Internal wet brakes, single brake pedal on HST, two brake pedals on gear models Wet disc Seat Suspension & Adjustability Suspended vinyl seat with retractable seatbelt, fixed steering wheel Adjustable seat, flips up and back for rear backhoe operation Front Axle Type Cast steel 4WD front axle with center drive line and bevel-gear final drives Selectable 4WD Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 116.0 in (w/o 3-point linkage) (without 3-point hitch) 110 in Overall Width 52.4 in 53.9 in Wheelbase 65.9 in 65.7 in Ground Clearance Not Published 16.4 in Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS 97.6 in 91.4 in Height to Top of ROPS (folded) 63.8 in Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) Gear: 2,600 lb; HST: 2,657 lb 2,107 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published R1 Agricultural (11.2-20 rear standard), R4 Industrial (25x8.50-14 / 14-17.5) R1 Agricultural - Front Not Published 7-16 6PR R1 Agricultural - Rear Not Published 11.2-20 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published 25x8.50-14 R4 Industrial - Rear Not Published 14-17.5 ▶ Loader & AttachmentsQuick Attach Loader System L105E: skid steer or pin-type implement attachments Quick attach front loader Loader Model L105E BBL300 Loader Lift Height L105E: 95.7 in 87.5 in Loader Lift Capacity (Full Height) L105E: 1,210 lb 1,314 lb Loader Breakout Force L105E: 1,460 lb 1,960 lbf ▶ WarrantyWarranty Length & Coverage 5-year powertrain warranty Engine and powertrain: 72 months or 2,000 hours; other tractor parts: 24 months or 1,000 hours; loader and backhoe: 24 months from shipment, 12 months from sale, or 500 hours ▶ ITC Company AccessoriesAccessories that fit None tagged yet
