▶ EngineEngine Manufacturer Shibaura TYM Engine Model Not Published T1700N6 Engine Type 3-cylinder diesel, liquid-cooled 3-cylinder, naturally aspirated diesel No. of Cylinders 3 3 Displacement 91.5 in³ 104.5 in³ Rated Engine Speed 2600 rpm 2100 rpm Engine Power (Gross) 24 hp 24 hp PTO Power Gear: 20.4 hp; HST: 19.2 hp 21 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Not Published Air Cleaner Not Published Dry element Fuel System Indirect low-pressure injection IDI Alternator Not Published 50 A, 12 V ▶ HydraulicsPump Type Gear-type pump Dual gear pump Implement Flow Not Published 7.7 gpm Steering Flow 3.8 gpm 4.2 gpm Total Hydraulic Flow 10.5 gpm 11.9 gpm Overall Hydraulic Pump Flow Not Published 11.9 gpm Hydraulic System Type Open center Dual gear pump Rear Remote Hydraulic Flow 6.7 gpm Not Published No. of Standard Remote Valves Not Published Loader: 2 / Rear: 0 No. of Optional Remote Valves Up to 2 Up to 4 ▶ Fluid CapacityFuel Tank Capacity 10.04 gal 7.1 gal Coolant Capacity 1.32 gal 5.3 qt Crankcase Capacity 1.22 gal 4.5 qt Transmission / Hydraulic System Capacity 10.04 gal 2515R: 9 gal; 2515H: 9.8 gal Front Axle Fluid Capacity 1.48 gal 6.8 qt ▶ PTO & HitchPTO Type Transmission driven Independent PTO Rear 540 rpm (1-3/8 in 6-spline) 540 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 2,205 lb 3,306 lb Hitch Lift Capacity (at 24”) 1,600 lb 2,425 lb Lift Control Type Not Published Position control ▶ Transmission & DrivetrainTransmission Type 9 x 3 mechanical shift constant mesh gears or 3-range hydrostatic 2515R: Synchromesh; 2515H: HST No. of Speeds Gear: 9F / 3R; HST: 3-range 2515R: F12 x R12; 2515H: 3-Range Max Travel Speed (Forward) Not Published 2515R: 11.7 mph; 2515H: 15.2 mph Max Travel Speed (Reverse) Not Published 2515R: 11.6 mph; 2515H: 15.2 mph Clutch Gear: dry single disc 2515R: Dry single plate; 2515H: None (HST) Differential Lock & Limited Slip Options Mechanical engagement via heel pedal Differential lock (standard) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Hydrostatic power steering Brakes Internal wet brakes, single brake pedal on HST, two brake pedals on gear models Wet, multi-disc Seat Suspension & Adjustability Suspended vinyl seat with retractable seatbelt, fixed steering wheel Suspension seat Front Axle Type Cast-steel 4WD front axle, center driveline, bevel-gear final drives Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 52.4 in 56.3 in Wheelbase 65.9 in 65.7 in Ground Clearance Not Published 14.4 in Min. Turn Radius without Brakes Not Published L: 124.8 in; R: 121.3 in Height to Top of ROPS 97.6 in 97.3 in Height to Top of ROPS (folded) 63.8 in Not Published Height to Top of Cab Model Not Published Not Published Overall Length 116 in (without 3-point hitch) 120.9 in (with 3-point hitch) ▶ WeightTractor Weight (Base) Gear: 2,600 lb; HST: 2,657 lb (ROPS base weight without ballast) 2515R: 2,989 lb; 2515H: 2,969 lb Weight with ROPS and Loader Not Published 2515R: 3,997 lb (2,989 + 1,008, computed); 2515H: 3,977 lb (2,969 + 1,008, computed) Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published R1 Agricultural 8-16 / 12.4-24; R3 Turf 27x8.5-15 6PR / 41x14.00 4PR; R4 Industrial 10-16.5 6PR / 420/70-24 6PR R1 Agricultural - Front Not Published 8-16 R1 Agricultural - Rear Not Published 12.4-24 R3 Turf - Front Not Published 27x8.5-15, 6PR R3 Turf - Rear Not Published 41x14.00, 4PR R4 Industrial - Front Not Published 10-16.5, 6PR R4 Industrial - Rear Not Published 420/70-24, 6PR ▶ Loader & AttachmentsQuick Attach Loader System FLx2407: skid steer or pin-type implement attachments BL150: Quick attach mechanism Loader Model FLx2407 BL150 Loader Lift Height FLx2407: 94.3 in (at pivot pin) BL150: 104.9 in Loader Lift Capacity (Full Height) FLx2407: 1,450 lb (at pivot pin, full height) BL150: 2,200 lb (at pivot pin) Loader Breakout Force FLx2407: 2,288 lb (at pivot pin) BL150: 3,422 lb (at pivot pin, ground level) ▶ WarrantyWarranty Length & Coverage Five-year powertrain warranty Basic 24 months or 2,000 hours, parts and labor; non-commercial, 20 to 70 engine hp: powertrain 72 months or 3,000 hours; loaders, backhoes and mid-mount mowers 12 months ▶ ITC Company AccessoriesAccessories that fit None tagged yet
