▶ EngineEngine Manufacturer Shibaura KIOTI (Daedong) Engine Model N843T-F 3A165LXE Engine Type 3-cylinder diesel, liquid-cooled, turbocharged Not Published No. of Cylinders 3 3 Displacement 91.5 in³ 100.5 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 34 hp 34 hp PTO Power Gear: 29 hp; HST: 27.2 hp 28.3 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Liquid-cooled Not Published Air Cleaner Not Published Dual stage air filter cartridge Fuel System Turbocharged, indirect low-pressure injection Not Published Alternator Not Published Not Published ▶ HydraulicsPump Type Gear-type pump Not Published Implement Flow Not Published 7.8 gpm Steering Flow 3.8 gpm 4.7 gpm Total Hydraulic Flow 10.5 gpm 12.5 gpm Overall Hydraulic Pump Flow Not Published 12.5 gpm Hydraulic System Type Open center Not Published Rear Remote Hydraulic Flow 6.7 gpm Not Published No. of Standard Remote Valves Not Published 1 No. of Optional Remote Valves Up to 2 1 ▶ Fluid CapacityFuel Tank Capacity 10.04 gal 11.5 gal Coolant Capacity 1.32 gal Not Published Crankcase Capacity 1.22 gal Not Published Transmission / Hydraulic System Capacity 10.04 gal Not Published Front Axle Fluid Capacity 1.48 gal Not Published ▶ PTO & HitchPTO Type Not Published Hydraulic independent PTO Rear 540 rpm (1-3/8 in 6-spline) 540 rpm Mid-PTO Availability Not Published Optional (2,000 rpm) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 2,205 lb 2,270 lb Hitch Lift Capacity (at 24”) 1,600 lb Not Published Lift Control Type Not Published Position, Draft and Mixed control ▶ Transmission & DrivetrainTransmission Type 9 x 3 mechanical shift constant mesh gears or 3-range hydrostatic Synchronized shuttle No. of Speeds Gear: 9F / 3R; HST: 3-range infinite 8F/8R (16F/16R with optional creeper gear) Max Travel Speed (Forward) Not Published 13.93 mph Max Travel Speed (Reverse) Not Published Not Published Clutch Gear: dry single disc Dry single plate Differential Lock & Limited Slip Options Mechanical engagement via heel pedal Rear differential lock (mechanical) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Hydraulic power steering Brakes Internal wet brakes, single brake pedal on HST, two brake pedals on gear models Wet disc Seat Suspension & Adjustability Suspended vinyl seat with retractable seatbelt, fixed steering wheel Adjustable seat Front Axle Type Cast-steel 4WD front axle, center driveline, bevel-gear final drives 4WD (MFWD) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 52.4 in 57.1 in Wheelbase 65.9 in 65.7 in Ground Clearance Not Published 11.4 in Min. Turn Radius without Brakes Not Published 125.9 in Height to Top of ROPS 97.6 in 92.5 in Height to Top of ROPS (folded) 63.8 in Not Published Height to Top of Cab Model Not Published Not Published Overall Length 116 in (without 3-point hitch) 126.3 in (with 3-point hitch) ▶ WeightTractor Weight (Base) Gear: 2,734 lb; HST: 2,767 lb 3,475 lb (with ag tires) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R3 Turf, R4 Industrial R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front Not Published 7-16 R1 Agricultural - Rear Not Published 12.4-24 R3 Turf - Front 27x8.50-15 27x8.5-15 R3 Turf - Rear 38x14.00-20 41x14-20 R4 Industrial - Front 27x8.50-15 27x10.5-15 R4 Industrial - Rear 15x19.5 43x16-20 ▶ Loader & AttachmentsQuick Attach Loader System FLx2407: skid steer or pin-type implement attachments Not Published Loader Model FLx2407 KL1450 Loader Lift Height FLx2407: 94.3 in (at pivot pin) KL1450: 103.5 in Loader Lift Capacity (Full Height) FLx2407: 1,450 lb (at pivot pin, full height) KL1450: 1,350 lb (at pivot pin) Loader Breakout Force FLx2407: 2,288 lb (at pivot pin) KL1450: 2,100 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage 5-year powertrain warranty Not Published ▶ ITC Company AccessoriesAccessories that fit None tagged yet
