▶ EngineEngine Manufacturer Shibaura Iseki Engine Model N843T-F Not Published Engine Type 3-cylinder diesel, liquid-cooled, turbocharged 3-cylinder liquid-cooled diesel No. of Cylinders 3 3 Displacement 91.5 in³ 91.4 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 34 hp 32.6 hp PTO Power Gear: 29 hp; HST: 27.2 hp Gear: 25.6 hp; HST: 24.1 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Not Published Dry Fuel System Turbocharged, indirect low-pressure injection Not Published Alternator Not Published Not Published ▶ HydraulicsPump Type Gear-type pump Not Published Implement Flow Not Published 9.1 gpm Steering Flow 3.8 gpm SynchroShuttle: 4.9 gpm; HST and PowerShuttle: 6 gpm Total Hydraulic Flow 10.5 gpm SynchroShuttle: 14.0 gpm; HST and PowerShuttle: 15.1 gpm Overall Hydraulic Pump Flow Not Published Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow 6.7 gpm 9.1 gpm No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Up to 2 2 spool optional ▶ Fluid CapacityFuel Tank Capacity 10.04 gal 10.6 gal Coolant Capacity 1.32 gal 7.1 qt Crankcase Capacity 1.22 gal 5 qt Transmission / Hydraulic System Capacity 10.04 gal 32.8 qt Front Axle Fluid Capacity 1.48 gal 7.9 qt ▶ PTO & HitchPTO Type Not Published Independent, electro-hydraulic control PTO Rear 540 rpm (1-3/8 in 6-spline) 540 rpm Mid-PTO Availability Not Published Optional, 2000 rpm Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 2,205 lb 2,800 lb Hitch Lift Capacity (at 24”) 1,600 lb Not Published Lift Control Type Not Published Position control with rate of drop control ▶ Transmission & DrivetrainTransmission Type 9 x 3 mechanical shift constant mesh gears or 3-range hydrostatic 8x8 SynchroShuttle (platform only), 12x12 PowerShuttle, or 3-range hydrostatic with cruise (platform only) No. of Speeds Gear: 9F / 3R; HST: 3-range infinite Not Published Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Gear: dry single disc Wet multi-disc (PowerShuttle) Differential Lock & Limited Slip Options Mechanical engagement via heel pedal Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Semi-flat isolated platform, folding ROPS Steering Power steering Power steering Brakes Internal wet brakes, single brake pedal on HST, two brake pedals on gear models Wet disc Seat Suspension & Adjustability Suspended vinyl seat with retractable seatbelt, fixed steering wheel Spring-suspension seat with forward/back and weight adjustment, retractable seat belt Front Axle Type Cast-steel 4WD front axle, center driveline, bevel-gear final drives 4WD front axle Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 52.4 in 62.0 in Wheelbase 65.9 in 70.0 in Ground Clearance Not Published 14.0 in Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS 97.6 in 87.4 in Height to Top of ROPS (folded) 63.8 in Not Published Height to Top of Cab Model Not Published Not Published Overall Length 116 in (without 3-point hitch) 121.0 in ▶ WeightTractor Weight (Base) Gear: 2,734 lb; HST: 2,767 lb Platform: 3,025 lb; Cab: 3,384 lb (shipping weight) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R3 Turf, R4 Industrial Ag: 8-16 front, 12.4-24 rear (13.6-24 optional); turf: 27x8.50-15 front, 41x14.00-20 rear (LSW305 R343 / LSW610 R470 optional); industrial: 10-16.5 front, 14.9-24 rear (also 25x8.5-14 front, 15x19.5 rear) R1 Agricultural - Front Not Published 8-16 R1 Agricultural - Rear Not Published 12.4-24 (13.6-24 optional) R3 Turf - Front 27x8.50-15 27x8.50-15 (LSW305 R343 optional) R3 Turf - Rear 38x14.00-20 41x14.00-20 (LSW610 R470 optional) R4 Industrial - Front 27x8.50-15 10-16.5 or 25x8.5-14 R4 Industrial - Rear 15x19.5 14.9-24 or 15x19.5 ▶ Loader & AttachmentsQuick Attach Loader System FLx2407: skid steer or pin-type implement attachments DL120: pin-type or skid-steer quick attach Loader Model FLx2407 DL120 Loader Lift Height FLx2407: 94.3 in (at pivot pin) DL120: 102 in (at pivot pin) Loader Lift Capacity (Full Height) FLx2407: 1,450 lb (at pivot pin, full height) DL120: 1,900 lb (to full height, at pivot pin) Loader Breakout Force FLx2407: 2,288 lb (at pivot pin) Not Published ▶ WarrantyWarranty Length & Coverage 5-year powertrain warranty Basic 2 years or 2,000 hours; powertrain 3 years or 2,000 hours
