▶ EngineEngine Manufacturer Shibaura Yanmar Engine Model Not Published 3TNV88C-KJPT Engine Type 3-cylinder turbocharged diesel, liquid-cooled 4-cycle, inline, water-cooled diesel, naturally aspirated No. of Cylinders 3 3 Displacement 91.3 in³ 100.2 in³ Rated Engine Speed 2600 rpm 2800 rpm Engine Power (Gross) 34.1 hp 34.2 hp PTO Power 29 hp 30.4 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid Air Cleaner Dry Dry Fuel System Indirect injection Direct injection Alternator Not Published 55 A, 12 V ▶ HydraulicsPump Type Dual engine-driven gear pumps 2 single-section external gear pumps, 1 on each side of the engine timing-gear cover Implement Flow Not Published 5.9 gpm Steering Flow Not Published 4.4 gpm Total Hydraulic Flow 9.7 gpm 10.3 gpm Overall Hydraulic Pump Flow Not Published 10.3 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published None No. of Optional Remote Valves 2 Up to two (optional) ▶ Fluid CapacityFuel Tank Capacity Not Published 9.7 gal Coolant Capacity Not Published 1.2 gal Crankcase Capacity Not Published 1.1 gal Transmission / Hydraulic System Capacity Not Published 9.2 gal Front Axle Fluid Capacity Not Published 1.0 gal ▶ PTO & HitchPTO Type 8x8 Synchro Shuttle: independent; HST: transmission driven Mechanical control; transmission clutch; wet disk brake (mid/rear PTO) PTO Rear 540 rpm (6-spline) 540 rpm at 2800 rpm engine (rated) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category I Category I Hitch Lift Capacity Not Published Not Published Hitch Lift Capacity (at 24”) 1,598 lb 1,670 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type 8 x 8 synchro shuttle or 3-range hydrostatic 8F/8R synchromesh shuttle shift gear transmission No. of Speeds 8x8 Synchro Shuttle: 8F / 8R; HST: 3-range infinite 8F/8R Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Not Published Single dry traction clutch Differential Lock & Limited Slip Options Mechanical rear differential lock Differential lock: Yes ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Power steering Brakes Wet disc Wet disk Seat Suspension & Adjustability Not Published Not Published Front Axle Type Not Published MFWD (4WD) Front Axle Rating Not Published 1,940 lb Drawbar Capacity Not Published 1,102 lb (static vertical load) ▶ Dimensions & ManeuverabilityOverall Width Not Published 57.3 in Wheelbase Not Published 62 in Ground Clearance Not Published 14 in Min. Turn Radius without Brakes Not Published 6.9 ft (with brake applied) Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length Not Published 111.2 in ▶ WeightTractor Weight (Base) Not Published 2,800 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Agricultural, Industrial R1 Bar, R3 Turf, R4 Industrial R1 Agricultural - Front 7-16 7-14 R1 Agricultural - Rear 11.2-24 11.2-24 R3 Turf - Front Not Published 27X8.5-15 R3 Turf - Rear Not Published 41X14-20 R4 Industrial - Front 27x8.50-15 25X8.5-14 R4 Industrial - Rear 15-19.5 15-19.5 ▶ Loader & AttachmentsQuick Attach Loader System FLx2407: pin-on (skid steer quick attach optional) Quick-change attachment carrier Loader Model FLx2407 300E Loader Lift Height FLx2407: 94.3 in (at pivot pin) 84 in (at pivot pin) Loader Lift Capacity (Full Height) FLx2407: 1,450 lb (at pivot pin, full height) 1,186 lb (at pivot pin) Loader Breakout Force FLx2407: 2,288 lb (at pivot pin) 1,704 lbf (at pivot pin) ▶ WarrantyWarranty Length & Coverage 5-year powertrain warranty Basic 2 years or 2,000 hours; powertrain 6 years or 2,000 hours
