▶ EngineEngine Manufacturer Shibaura Mitsubishi Engine Model Not Published Not Published Engine Type 3-cylinder turbocharged diesel, liquid-cooled 3-cylinder, overhead valve, cross-flow porting No. of Cylinders 3 3 Displacement 91.3 in³ 101.4 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 34.1 hp 34.5 hp PTO Power 29 hp Gear: 31 hp; Hydro: 29 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dry Dry Type Air Cleaning System with Double Filter Fuel System Indirect injection Injection pump: BOSCH-PFR; injectors: throttle type, BOSCH Alternator Not Published 55 A, 12 V ▶ HydraulicsPump Type Dual engine-driven gear pumps Front Mounted, Engine Driven, Pressure Loading Gear Type Implement Flow Not Published 7.7 gpm at 2600 rpm Steering Flow Not Published 3.4 gpm at 2600 rpm Total Hydraulic Flow 9.7 gpm Not Published Overall Hydraulic Pump Flow Not Published Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves 2 1 (optional) ▶ Fluid CapacityFuel Tank Capacity Not Published 7.1 gal Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type 8x8 Synchro Shuttle: independent; HST: transmission driven Gear Drive: independent; Hydrostatic Drive: live, with internal overrunning clutch PTO Rear 540 rpm (6-spline) 540 rpm @ 2376 rpm Mid-PTO Availability Not Published Optional, 2000 rpm @ 2525 rpm Category, 3-Point Hitch Category I Category I Hitch Lift Capacity Not Published 2,646 lb Hitch Lift Capacity (at 24”) 1,598 lb 1,720 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type 8 x 8 synchro shuttle or 3-range hydrostatic Gear Drive: synchromesh shuttle and constant-mesh main gear shift, two ranges of selective sliding gears; Hydrostatic Drive: HST, three ranges of selective sliding gears No. of Speeds 8x8 Synchro Shuttle: 8F / 8R; HST: 3-range infinite Not Published Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Not Published Dry, Single Disc, Diaphragm Type, 8.46 in Differential Lock & Limited Slip Options Mechanical rear differential lock Pedal-controlled, mechanically actuated (gear drive: RH step; hydrostatic drive: LH step) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Hydrostatic Brakes Wet disc Wet Disk Plate Type Seat Suspension & Adjustability Not Published Not Published Front Axle Type Not Published 4WD (MFD) with spiral bevel gear type differential and bevel gear reductions Front Axle Rating Not Published Not Published Drawbar Capacity Not Published 969 lbf ▶ Dimensions & ManeuverabilityOverall Width Not Published 3616 (43x16.00-20): 62 in Wheelbase Not Published 68.9 in Ground Clearance Not Published 3616 (28x8.50-15): 12.5 in Min. Turn Radius without Brakes Not Published 3616: 98.4 in (with brake applied) Height to Top of ROPS Not Published 3616 (43x16.00-20): 84.4 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published 3616 CABIN (43x16.00-20): 83 in Overall Length Not Published 121.3 in (to end of lower link) ▶ WeightTractor Weight (Base) Not Published Gear Drive: 2,560 lb; Hydrostatic Drive: 2,566 lb; Gear Drive Cabin: 3,065 lb; Hydrostatic Drive Cabin: 3,087 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Agricultural, Industrial Not Published R1 Agricultural - Front 7-16 7x16 R1 Agricultural - Rear 11.2-24 11.2x24 R3 Turf - Front Not Published 27x10.5-15 R3 Turf - Rear Not Published 41x14-20 R4 Industrial - Front 27x8.50-15 28x8.5-15 R4 Industrial - Rear 15-19.5 43x16-20 ▶ Loader & AttachmentsQuick Attach Loader System FLx2407: pin-on (skid steer quick attach optional) Not Published Loader Model FLx2407 ML115 SKC (3616 Shuttle, 3616 HST); ML116 (3616 Shuttle Cab, 3616 HST Cab) Loader Lift Height FLx2407: 94.3 in (at pivot pin) ML115 SKC: 99 in; ML116: 99 in Loader Lift Capacity (Full Height) FLx2407: 1,450 lb (at pivot pin, full height) ML115 SKC: 1,650 lb; ML116: 1,650 lb Loader Breakout Force FLx2407: 2,288 lb (at pivot pin) ML115 SKC: 2,350 lb; ML116: 2,650 lb ▶ WarrantyWarranty Length & Coverage 5-year powertrain warranty Not Published
