▶ EngineEngine Manufacturer Shibaura Yanmar Engine Model Shibaura N3LDI-T 3TNV88C-NJT Engine Type 3-cylinder turbocharged intercooled diesel, liquid-cooled Diesel, turbocharged No. of Cylinders 3 3 Displacement 101.4 in³ 95.8 in³ Rated Engine Speed 2600 rpm 2500 rpm Engine Power (Gross) 36.2 hp 36.7 hp PTO Power 27.5 hp 30.4 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dry Dual element Fuel System Common rail direct injection Direct injection Alternator Not Published 85 A, 12 V ▶ HydraulicsPump Type Engine-driven gear-type pump Dual gear Implement Flow 11.0 gpm 5.3 gpm Steering Flow Not Published 4 gpm Total Hydraulic Flow Not Published 9.3 gpm Overall Hydraulic Pump Flow 12.6 gpm 9.3 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow 12.1 gpm Not Published No. of Standard Remote Valves 2 Not Published No. of Optional Remote Valves Up to 3 Up to 3 ▶ Fluid CapacityFuel Tank Capacity 10.56 gal 8.5 gal Coolant Capacity 6.34 qt 1.37 gal Crankcase Capacity 4.86 qt 4.7 qt Transmission / Hydraulic System Capacity 12x12 Power Shuttle: 8.18 gal; HST: 7.4 gal 6.2 gal Front Axle Fluid Capacity 7.9 qt 1.0 gal ▶ PTO & HitchPTO Type Independent, with soft-start feature Independent PTO Rear 540 rpm (1-3/8 in 6-spline) 540 rpm Mid-PTO Availability Optional, 2,000 rpm 2000 rpm Category, 3-Point Hitch Category I with extendable ball ends Category 1 Hitch Lift Capacity 2,646 lb 1,356 lb Hitch Lift Capacity (at 24”) 2,535 lb 1356 lb Lift Control Type Position and draft control Position Control ▶ Transmission & DrivetrainTransmission Type 12 x 12 power shuttle or 3-range hydrostatic Hydrostatic No. of Speeds 12x12 Power Shuttle: 12F / 12R; HST: 3-range infinite Infinite (2-range HST) Max Travel Speed (Forward) Not Published 15.3 mph Max Travel Speed (Reverse) Not Published Not Published Clutch Single stage dry type Not Published Differential Lock & Limited Slip Options Mechanical engagement via right side heel pedal Differential lock: Yes; Limited slip: Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Power Brakes Internal wet disc brakes, individual control via independent foot pedals Wet Disc Seat Suspension & Adjustability Deluxe suspended seat with armrests and seatbelts (vinyl seat on ROPS, cloth seat on cab), tilt steering Not Published Front Axle Type Cast steel 4WD front axle with center drive line and bevel-gear final drives 4WD (MFWD) Front Axle Rating Not Published 1940 lb Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 122.0 in 117.7 in Overall Width 64.2 in 53.9 in Wheelbase 69.7 in 67.9 in Ground Clearance 15.4 in Not Published Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS 99.2 in 92.3 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 91.3 in Not Published ▶ WeightTractor Weight (Base) 12x12 Power Shuttle: 3,373 lb; HST: 3,406 lb 2436 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial R1 Ag, R3 Turf, R4 Industrial, R3 Turf Radial R1 Agricultural - Front 8-16 7.00-12 R1 Agricultural - Rear 12.4x24 12.4-16 R3 Turf - Front 27x8.50-15 23x8.50-14 R3 Turf - Rear 41x14.00-20 14-17.5 R4 Industrial - Front 10-16.5 23x8.50-14 R4 Industrial - Rear 17.5L-24 14-17.5 ▶ Loader & AttachmentsQuick Attach Loader System DL125: Pin-on (skid steer quick attach optional) 220R Quik-Park Loader System Loader Model DL125 220R Loader Lift Height DL125: 106 in 85 in (at pivot pin) Loader Lift Capacity (Full Height) DL125: 1,660 lb 1,120 lb (at pivot pin, full height) Loader Breakout Force DL125: 3,000 lb 1,949 lbf (at pivot pin) ▶ WarrantyWarranty Length & Coverage 5-year powertrain warranty 6-year/2,000-hour powertrain; 2-year/2,000-hour basic (full machine)
