▶ EngineEngine Manufacturer Shibaura Kubota Engine Model N3LDI-T Not Published Engine Type 3-cylinder turbocharged intercooled diesel, liquid-cooled Indirect injection, liquid-cooled diesel No. of Cylinders 3 3 Displacement 101.4 in³ 111.4 in³ Rated Engine Speed 2600 rpm 2700 rpm Engine Power (Gross) 36.2 hp 35.7 hp PTO Power 27.5 hp F (2WD gear), DT (4WD gear): 30 hp; HST (4WD): 28.5 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dry Not Published Fuel System Common rail direct injection Indirect injection Alternator Not Published 40 A, 12 V ▶ HydraulicsPump Type Engine-driven gear-type pump Not Published Implement Flow Not Published 6.3 gpm Steering Flow Not Published 3.8 gpm Total Hydraulic Flow Not Published 10.1 gpm (6.3 + 3.8, computed) Overall Hydraulic Pump Flow 12.6 gpm Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow 12.1 gpm Not Published No. of Standard Remote Valves Cab: 1 pair Not Published No. of Optional Remote Valves Up to 3 Up to 3 ▶ Fluid CapacityFuel Tank Capacity 10.56 gal 9.0 gal Coolant Capacity 6.34 qt Not Published Crankcase Capacity 4.86 qt Not Published Transmission / Hydraulic System Capacity 12x12 Power Shuttle: 8.18 gal; HST: 7.4 gal F (2WD): 7.1 gal; DT (4WD): 7.3 gal; HST (4WD): 6.2 gal Front Axle Fluid Capacity 7.9 qt 4.8 qt ▶ PTO & HitchPTO Type Independent, with soft-start feature F (2WD gear), DT (4WD gear): live-continuous running; HST (4WD): live-continuous with overrunning clutch PTO Rear 540 rpm (6-spline) 540 rpm Mid-PTO Availability Optional, 2,000 rpm Not Published Category, 3-Point Hitch Category I with extendable ball ends Category I Hitch Lift Capacity Not Published 1,998 lb Hitch Lift Capacity (at 24”) 2,535 lb 1,435 lb Lift Control Type Draft control optional Position control ▶ Transmission & DrivetrainTransmission Type 12 x 12 power shuttle or 3-range hydrostatic F (2WD gear), DT (4WD gear): sliding gear and constant mesh, 8F/4R; HST (4WD): hydrostatic transmission, 3-range No. of Speeds 12x12 Power Shuttle: 12F / 12R; HST: 3-range infinite F (2WD gear), DT (4WD gear): 8F/4R; HST (4WD): 3-range Max Travel Speed (Forward) Not Published F (2WD gear), DT (4WD gear): 13.2 mph; HST (4WD): 14.1 mph Max Travel Speed (Reverse) Not Published F (2WD gear), DT (4WD gear): 4.7 mph; HST (4WD): 12.7 mph Clutch Single stage dry type F (2WD gear), DT (4WD gear): dry-type, dual-stage; HST (4WD): dry-type, single-stage Differential Lock & Limited Slip Options Mechanical engagement via right side heel pedal Rear differential lock standard ▶ Chassis, Steering & ControlsFrame Type Not Published Foldable ROPS (standard on all models) Steering Power steering Integral type power steering Brakes Internal wet disc brakes, independent foot pedals Wet disc type Seat Suspension & Adjustability Suspended seat with armrests and seat belts (vinyl on ROPS, cloth on cab), tilt steering Not Published Front Axle Type Cast-steel 4WD front axle, center driveline, bevel-gear final drives 4WD: Bevel gear front axle Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 64.2 in 51.4 in Wheelbase 69.7 in 63.3 in Ground Clearance 15.4 in F (2WD gear): 13.6 in; DT (4WD gear), HST (4WD): 13.4 in Min. Turn Radius without Brakes Not Published F (2WD gear): 7.9 ft; DT (4WD gear), HST (4WD): 8.2 ft (with brake applied) Height to Top of ROPS 99.2 in 85.0 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 91.3 in Not Published Overall Length 122.0 in F (2WD gear): 110.6 in; DT (4WD gear), HST (4WD): 106.5 in (without 3-point hitch) ▶ WeightTractor Weight (Base) 12x12 Power Shuttle: 3,373 lb; HST: 3,406 lb F (2WD gear): 2,403 lb; DT (4WD gear): 2,580 lb; HST (4WD): 2,600 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Agricultural, Turf, Industrial, Snow AG standard; turf and industrial optional R1 Agricultural - Front 8-16 F (2WD gear): 5-15; DT (4WD gear), HST (4WD): 7-16 R1 Agricultural - Rear 12.4x24 11.2-24 R3 Turf - Front 27x8.50-15 25x8.50-14 (4WD) R3 Turf - Rear 41x14.00-20 13.6-16 R4 Industrial - Front 10-16.5 27x8.50-15 (4WD) R4 Industrial - Rear 17.5L-24 15-19.5 R4 (4WD) ▶ Loader & AttachmentsQuick Attach Loader System DL125: Pin-on (skid steer quick attach optional) LA463: quick attach/detach loader (mounting pins and hose couplers from the seat); skid steer-type quick coupler optional Loader Model DL125 LA463 Loader Lift Height DL125: 106 in (at pivot pin) LA463: 95.3 in (at pivot pin) Loader Lift Capacity (Full Height) DL125: 1,660 lb (at pivot pin, full height) LA463: 1,142 lb (at pivot pin) Loader Breakout Force DL125: 3,000 lb (at pivot pin) Not Published ▶ WarrantyWarranty Length & Coverage 5-year powertrain warranty Not Published
