▶ EngineEngine Manufacturer Shibaura Shibaura Engine Model Shibaura N3LDI-T Not Published Engine Type 3-cylinder turbocharged intercooled diesel, liquid-cooled 3-cylinder turbocharged diesel, liquid-cooled No. of Cylinders 3 3 Displacement 101.4 in³ 91.3 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 36.2 hp 34.1 hp PTO Power 27.5 hp 29 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dry Dry Fuel System Common rail direct injection Indirect injection Alternator Not Published Not Published ▶ HydraulicsPump Type Engine-driven gear-type pump Dual engine-driven gear pumps Implement Flow 11.0 gpm Not Published Steering Flow Not Published Not Published Total Hydraulic Flow Not Published 9.7 gpm Overall Hydraulic Pump Flow 12.6 gpm Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow 12.1 gpm Not Published No. of Standard Remote Valves 2 Not Published No. of Optional Remote Valves Up to 3 2 ▶ Fluid CapacityFuel Tank Capacity 10.56 gal Not Published Coolant Capacity 6.34 qt Not Published Crankcase Capacity 4.86 qt Not Published Transmission / Hydraulic System Capacity 12x12 Power Shuttle: 8.18 gal; HST: 7.4 gal Not Published Front Axle Fluid Capacity 7.9 qt Not Published ▶ PTO & HitchPTO Type Independent, with soft-start feature 8x8 Synchro Shuttle: independent; HST: transmission driven PTO Rear 540 rpm (1-3/8 in 6-spline) 540 rpm (1-3/8 in 6-spline) Mid-PTO Availability Optional, 2,000 rpm Not Published Category, 3-Point Hitch Category I with extendable ball ends Category I Hitch Lift Capacity 2,646 lb Not Published Hitch Lift Capacity (at 24”) 2,535 lb 1,598 lb Lift Control Type Position and draft control Position control ▶ Transmission & DrivetrainTransmission Type 12 x 12 power shuttle or 3-range hydrostatic 8 x 8 synchro shuttle or 3-range hydrostatic No. of Speeds 12x12 Power Shuttle: 12F / 12R; HST: 3-range infinite 8x8 Synchro Shuttle: 8F / 8R; HST: 3-range infinite Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Single stage dry type Not Published Differential Lock & Limited Slip Options Mechanical engagement via right side heel pedal Mechanical rear differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Power steering Brakes Internal wet disc brakes, individual control via independent foot pedals Wet disc Seat Suspension & Adjustability Deluxe suspended seat with armrests and seatbelts (vinyl seat on ROPS, cloth seat on cab), tilt steering Not Published Front Axle Type Cast steel 4WD front axle with center drive line and bevel-gear final drives Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 122.0 in Not Published Overall Width 64.2 in Not Published Wheelbase 69.7 in Not Published Ground Clearance 15.4 in Not Published Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS 99.2 in Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 91.3 in Not Published ▶ WeightTractor Weight (Base) 12x12 Power Shuttle: 3,373 lb; HST: 3,406 lb Not Published Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural, R4 Industrial R1 Agricultural - Front 8-16 7-16 R1 Agricultural - Rear 12.4x24 11.2-24 R3 Turf - Front 27x8.50-15 Not Published R3 Turf - Rear 41x14.00-20 Not Published R4 Industrial - Front 10-16.5 27x8.50-15 R4 Industrial - Rear 17.5L-24 15-19.5 ▶ Loader & AttachmentsQuick Attach Loader System DL125: Pin-on (skid steer quick attach optional) FLx2407: pin-on (skid steer quick attach optional) Loader Model DL125 FLx2407 Loader Lift Height DL125: 106 in FLx2407: 94.3 in Loader Lift Capacity (Full Height) DL125: 1,660 lb FLx2407: 1,450 lb Loader Breakout Force DL125: 3,000 lb FLx2407: 2,288 lb ▶ WarrantyWarranty Length & Coverage 5-year powertrain warranty 5-year powertrain warranty
