▶ EngineEngine Manufacturer Shibaura Shibaura Engine Model N3LDI-T N3LDI-T Engine Type 3-cylinder turbocharged intercooled diesel, liquid-cooled 3-cylinder turbocharged intercooled diesel, liquid-cooled No. of Cylinders 3 3 Displacement 101.4 in³ 101.4 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 36.2 hp 36.2 hp PTO Power 27.5 hp 27.5 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dry Dry Fuel System Common rail direct injection Common rail direct injection Alternator Not Published Not Published ▶ HydraulicsPump Type Engine-driven gear-type pump Engine-driven gear-type pump Implement Flow Not Published Not Published Steering Flow Not Published Not Published Total Hydraulic Flow Not Published Not Published Overall Hydraulic Pump Flow 12.6 gpm 12.6 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow 12.1 gpm 12.1 gpm No. of Standard Remote Valves Cab: 1 pair Cab: 1 pair No. of Optional Remote Valves Up to 3 Up to 3 ▶ Fluid CapacityFuel Tank Capacity 10.56 gal 10.56 gal Coolant Capacity 6.34 qt 6.34 qt Crankcase Capacity 4.86 qt 4.86 qt Transmission / Hydraulic System Capacity 12x12 Power Shuttle: 8.18 gal; HST: 7.4 gal 12x12 Power Shuttle: 8.18 gal; HST: 7.4 gal Front Axle Fluid Capacity 7.9 qt 7.9 qt ▶ PTO & HitchPTO Type Independent, with soft-start feature Independent, with soft-start feature PTO Rear 540 rpm (6-spline) 540 rpm (6-spline) Mid-PTO Availability Optional, 2,000 rpm Optional, 2,000 rpm Category, 3-Point Hitch Category I with extendable ball ends Category I with extendable ball ends Hitch Lift Capacity Not Published Not Published Hitch Lift Capacity (at 24”) 2,535 lb 2,535 lb Lift Control Type Draft control optional Draft control optional ▶ Transmission & DrivetrainTransmission Type 12 x 12 power shuttle or 3-range hydrostatic 12 x 12 power shuttle or 3-range hydrostatic No. of Speeds 12x12 Power Shuttle: 12F / 12R; HST: 3-range infinite 12x12 Power Shuttle: 12F / 12R; HST: 3-range infinite Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Single stage dry type Single stage dry type Differential Lock & Limited Slip Options Mechanical engagement via right side heel pedal Mechanical engagement via right side heel pedal ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Power steering Brakes Internal wet disc brakes, independent foot pedals Internal wet disc brakes, independent foot pedals Seat Suspension & Adjustability Suspended seat with armrests and seat belts (vinyl on ROPS, cloth on cab), tilt steering Suspended seat with armrests and seat belts (vinyl on ROPS, cloth on cab), tilt steering Front Axle Type Cast-steel 4WD front axle, center driveline, bevel-gear final drives Cast-steel 4WD front axle, center driveline, bevel-gear final drives Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 64.2 in 64.2 in Wheelbase 69.7 in 69.7 in Ground Clearance 15.4 in 15.4 in Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS 99.2 in 99.2 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 91.3 in 91.3 in Overall Length 122.0 in 122.0 in ▶ WeightTractor Weight (Base) 12x12 Power Shuttle: 3,373 lb; HST: 3,406 lb 12x12 Power Shuttle: 3,373 lb; HST: 3,406 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Agricultural, Turf, Industrial, Snow Agricultural, Turf, Industrial, Snow R1 Agricultural - Front 8-16 8-16 R1 Agricultural - Rear 12.4x24 12.4x24 R3 Turf - Front 27x8.50-15 27x8.50-15 R3 Turf - Rear 41x14.00-20 41x14.00-20 R4 Industrial - Front 10-16.5 10-16.5 R4 Industrial - Rear 17.5L-24 17.5L-24 ▶ Loader & AttachmentsQuick Attach Loader System DL125: Pin-on (skid steer quick attach optional) DL125: Pin-on (skid steer quick attach optional) Loader Model DL125 DL125 Loader Lift Height DL125: 106 in (at pivot pin) DL125: 106 in (at pivot pin) Loader Lift Capacity (Full Height) DL125: 1,660 lb (at pivot pin, full height) DL125: 1,660 lb (at pivot pin, full height) Loader Breakout Force DL125: 3,000 lb (at pivot pin) DL125: 3,000 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage 5-year powertrain warranty 5-year powertrain warranty
