▶ EngineEngine Manufacturer Mitsubishi Kubota Engine Model K38 Not Published Engine Type 3-cylinder turbocharged and intercooled diesel Vertical, liquid-cooled, 4-cycle diesel, indirect injection (E-TVCS) No. of Cylinders 3 3 Displacement 101 in³ 111.4 in³ Rated Engine Speed 2500 rpm 2700 rpm Engine Power (Gross) 36.2 hp 35.7 hp PTO Power Gear: 27.5 hp; HST: 26.3 hp F (2WD gear), DT (4WD gear): 30 hp; HST (4WD): 28.5 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Not Published Not Published Fuel System Common rail direct injection with electronic engine management Indirect injection (E-TVCS) Alternator Not Published 40 A, 12 V ▶ HydraulicsPump Type Engine-driven gear-type pump Not Published Implement Flow 11.6 gpm 6.3 gpm Steering Flow 6.8 gpm 3.8 gpm Total Hydraulic Flow Not Published 10.1 gpm (6.3 + 3.8, computed) Overall Hydraulic Pump Flow Not Published Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow 11.6 gpm Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Not Published Up to 3 ▶ Fluid CapacityFuel Tank Capacity 10.6 gal 9.0 gal Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published 7.3 gal Front Axle Fluid Capacity Not Published 4.8 qt ▶ PTO & HitchPTO Type Independent, electro-hydraulically engaged F (2WD gear), DT (4WD gear): Live-continuous running; HST (4WD): Live-continuous with overrunning clutch PTO Rear 540 rpm (1-3/8 in 6-spline) 540 rpm Mid-PTO Availability Optional, 2000 rpm Not Published Category, 3-Point Hitch Category I Category I Hitch Lift Capacity Not Published 1998 lb Hitch Lift Capacity (at 24”) 2,535 lb 1435 lb Lift Control Type Position control; draft control optional Position control ▶ Transmission & DrivetrainTransmission Type 12x12 power shuttle (4 gears, 3 ranges) or 3-range electronic Servo-HST F (2WD gear), DT (4WD gear): Sliding gear and constant mesh, 8F/4R; HST (4WD): Hydrostatic transmission, 3-range No. of Speeds Power shuttle: 12F / 12R; Servo-HST: 3-range infinite F (2WD gear), DT (4WD gear): 8F/4R; HST (4WD): 3-range Max Travel Speed (Forward) Not Published F (2WD gear), DT (4WD gear): 13.2 mph; HST (4WD): 14.1 mph Max Travel Speed (Reverse) Not Published F (2WD gear), DT (4WD gear): 4.7 mph; HST (4WD): 12.7 mph Clutch Wet multi-disc (power shuttle) F (2WD gear), DT (4WD gear): Dry-type dual stage; HST (4WD): Dry-type single stage Differential Lock & Limited Slip Options Mechanical rear differential lock, right side heel pedal Rear differential lock standard ▶ Chassis, Steering & ControlsFrame Type Drop-axle rear with bull gear final drives Foldable ROPS (standard on all models) Steering Power steering, tilt steering wheel Integral type power steering Brakes Internal wet disc brakes, individual control via independent foot pedals Wet disc type Seat Suspension & Adjustability Deluxe suspended seat with armrests and seat belt (vinyl on ROPS, cloth on cab) Not Published Front Axle Type Cast steel 4WD front axle with center drive line and bevel-gear final drives 4WD: Bevel gear front axle Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 122.0 in F (2WD gear): 110.6 in; DT (4WD gear), HST (4WD): 106.5 in (w/o 3P) (without 3-point hitch) Overall Width 64.2 in 51.4 in Wheelbase 69.7 in 63.3 in Ground Clearance Not Published F (2WD gear): 13.6 in; DT (4WD gear), HST (4WD): 13.4 in Min. Turn Radius without Brakes Not Published F (2WD gear): 7.9 ft; DT (4WD gear), HST (4WD): 8.2 ft (w/brake) (with brake applied) Height to Top of ROPS Not Published 85.0 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 91.3 in Not Published ▶ WeightTractor Weight (Base) ROPS: 3,362 lb; Cab: 3,803 lb F (2WD gear): 2403 lb; DT (4WD gear): 2580 lb; HST (4WD): 2600 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Ag: 8-16 front, 12.4-24 rear (13.6-24 optional); turf: 27x8.50-15 front, 41x14.00-20 rear; industrial: 10-16.5 front, 17.5L-24 rear (also 250/75R16 front, 400/80R24 rear) AG standard; turf and industrial optional R1 Agricultural - Front 8-16 F (2WD gear): 5-15; DT (4WD gear), HST (4WD): 7-16 R1 Agricultural - Rear 12.4-24 (13.6-24 optional) 11.2-24 R3 Turf - Front 27x8.50-15 25x8.50-14 (4WD) R3 Turf - Rear 41x14.00-20 13.6-16 R4 Industrial - Front 10-16.5 or 250/75R16 27x8.50-15 (4WD) R4 Industrial - Rear 17.5L-24 or 400/80R24 15-19.5 R4 (4WD) ▶ Loader & AttachmentsQuick Attach Loader System DL125: universal skid steer or compact quick-attach tool carrier LA463: quick attach/detach loader (mounting pins and hose couplers from the seat); skid steer-type quick coupler optional Loader Model DL125 LA463 Loader Lift Height DL125: 102.4 in LA463: 95.3 in Loader Lift Capacity (Full Height) DL125: 1,840 lb LA463: 1142 lb Loader Breakout Force DL125: 2,190 lb Not Published ▶ WarrantyWarranty Length & Coverage 5-year powertrain warranty Not Published
