▶ EngineEngine Manufacturer Shibaura Mahindra Engine Model N843T-F CE-38 Engine Type 3-cylinder diesel, liquid-cooled, turbocharged Naturally aspirated, direct injection, water-cooled diesel No. of Cylinders 3 4 Displacement 91.5 in³ 166.7 in³ Rated Engine Speed 2800 rpm 2400 rpm Engine Power (Gross) 38.5 hp 38.7 hp PTO Power Gear: 32.7 hp; HST: 30.9 hp 27.7 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Water-cooled Air Cleaner Not Published Not Published Fuel System Turbocharged, indirect low-pressure injection Direct injection Alternator Not Published 90 A, 12 V ▶ HydraulicsPump Type Gear-type pump Not Published Implement Flow Not Published 7.7 gpm Steering Flow 4.1 gpm 3.4 gpm Total Hydraulic Flow 11.3 gpm 11.1 gpm Overall Hydraulic Pump Flow Not Published 11.1 gpm Hydraulic System Type Open center Open Center Rear Remote Hydraulic Flow 7.2 gpm Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Up to 2 Optional, single valve ▶ Fluid CapacityFuel Tank Capacity 10.04 gal 7.7 gal Coolant Capacity 1.32 gal Not Published Crankcase Capacity 1.22 gal Not Published Transmission / Hydraulic System Capacity 10.04 gal Not Published Front Axle Fluid Capacity 1.48 gal Not Published ▶ PTO & HitchPTO Type Gear: independent; HST: transmission-driven with overrunning clutch Live with o/r clutch PTO Rear 540 rpm (1-3/8 in 6-spline) 540 rpm @ 2376 rpm Mid-PTO Availability Not Published Optional; 2000 rpm @ 2526 rpm Category, 3-Point Hitch Category I CAT I with Telescoping Stabilizers & Flex Links Hitch Lift Capacity 2,205 lb Not Published Hitch Lift Capacity (at 24”) 1,600 lb 1,720 lb Lift Control Type Not Published Position control ▶ Transmission & DrivetrainTransmission Type 9 x 3 mechanical shift constant mesh gears or 3-range hydrostatic HST, 3 ranges No. of Speeds Gear: 9F / 3R; HST: 3-range infinite Infinite / 3 Ranges Max Travel Speed (Forward) Not Published 14.8 mph Max Travel Speed (Reverse) Not Published Not Published Clutch Gear: dry single disc Dry-Single Differential Lock & Limited Slip Options Mechanical engagement via heel pedal Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Hydrostatic Power Steering Brakes Internal wet brakes, single brake pedal on HST, two brake pedals on gear models Wet Disc Seat Suspension & Adjustability Suspended vinyl seat with retractable seatbelt, fixed steering wheel Seat with contoured cushions, folding armrests, adjustable legroom and retractable seat belt Front Axle Type Cast-steel 4WD front axle, center driveline, bevel-gear final drives Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 52.4 in 62 in Wheelbase 65.9 in 76.9 in Ground Clearance Not Published 12.8 in Min. Turn Radius without Brakes Not Published 9.2 ft (with brake applied) Height to Top of ROPS 97.6 in 91.5 in Height to Top of ROPS (folded) 63.8 in Not Published Height to Top of Cab Model Not Published Not Published Overall Length 116 in (without 3-point hitch) 127.8 in ▶ WeightTractor Weight (Base) Gear: 2,756 lb; HST: 2,789 lb 3,175 lb Weight with ROPS and Loader Not Published 3,798 lb (3,175 + 623, computed; 433.2 gal loader shipping weight) Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R3 Turf, R4 Industrial Agricultural, Industrial, Turf R1 Agricultural - Front Not Published 7 x 16 R1 Agricultural - Rear Not Published 11.2 x 24 R3 Turf - Front 27x8.50-15 27 x 10.5-15 R3 Turf - Rear 38x14.00-20 41 x 14-20 R4 Industrial - Front 27x8.50-15 28 x 8.5-15 R4 Industrial - Rear 15x19.5 43 x 16-20 ▶ Loader & AttachmentsQuick Attach Loader System FLx2407: skid steer or pin-type implement attachments Front loader with skid-steer couplers for superfast hookups Loader Model FLx2407 1640L (64 in bucket) Loader Lift Height FLx2407: 94.3 in (at pivot pin) Mahindra 1640L: 92 in; Measured as: maximum lift height Loader Lift Capacity (Full Height) FLx2407: 1,450 lb (at pivot pin, full height) Mahindra 1640L: 1,830 lb; Measured at: pivot pin, full height Loader Breakout Force FLx2407: 2,288 lb (at pivot pin) Mahindra 1640L: 2,777 lb ▶ WarrantyWarranty Length & Coverage 5-year powertrain warranty 7-year/3,000-hour, $0 deductible limited powertrain warranty
