▶ EngineEngine Manufacturer Mitsubishi Yanmar Engine Model K38 3TNV86CT-KJPT Engine Type 3-cylinder turbocharged and intercooled diesel 4-cycle, inline, water-cooled diesel, turbocharged No. of Cylinders 3 3 Displacement 101 in³ 95.8 in³ Rated Engine Speed 2500 rpm 2800 rpm Engine Power (Gross) 41.6 hp 41.6 hp PTO Power Gear: 32.8 hp; HST: 31.6 hp 36.3 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid Air Cleaner Not Published Dry Fuel System Common-rail, direct injection, electronic engine management Direct injection Alternator Not Published 55 A, 12 V ▶ HydraulicsPump Type Engine-driven gear-type pump Two single-section external gear pumps, one either side of the engine Implement Flow 11.6 gpm 5.9 gpm Steering Flow 6.8 gpm 4.4 gpm Total Hydraulic Flow Not Published 10.3 gpm Overall Hydraulic Pump Flow Not Published 10.3 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow 11.6 gpm Not Published No. of Standard Remote Valves 1 None No. of Optional Remote Valves Up to 3 Loader mast mounted SCV (optional); 4th/5th SCV (optional) ▶ Fluid CapacityFuel Tank Capacity 14.5 gal 9.7 gal Coolant Capacity Not Published 1.3 gal Crankcase Capacity Not Published 1.1 gal Transmission / Hydraulic System Capacity Not Published 9.2 gal Front Axle Fluid Capacity Not Published 1.0 gal ▶ PTO & HitchPTO Type Independent, electro-hydraulically engaged Transmission driven PTO Rear 540 rpm (1-3/8 in 6-spline) 540 rpm at 2800 rpm engine (rated) Mid-PTO Availability Optional, 2000 rpm Not Published Category, 3-Point Hitch Category I Category I Hitch Lift Capacity Not Published Not Published Hitch Lift Capacity (at 24”) 2,535 lb 1,670 lb Lift Control Type Position control; draft control optional Position control ▶ Transmission & DrivetrainTransmission Type 12x12 power shuttle (4 gears, 3 ranges) or 3-range electronic Servo-HST 8F/8R synchromesh shuttle shift gear transmission No. of Speeds Power shuttle: 12F / 12R; Servo-HST: 3-range infinite 8F/8R Max Travel Speed (Forward) Not Published 12.9 mph Max Travel Speed (Reverse) Not Published Not Published Clutch Wet multi-disc (power shuttle) Single dry traction (mechanical) Differential Lock & Limited Slip Options Mechanical engagement via heel pedal Differential lock: Yes ▶ Chassis, Steering & ControlsFrame Type Drop-axle rear with bull gear final drives Not Published Steering Power steering, tilt steering wheel Power steering Brakes Internal wet disc brakes, independent foot pedals Wet disk Seat Suspension & Adjustability Suspended seat with armrests and seat belt (vinyl on ROPS, cloth on cab) Not Published Front Axle Type Cast-steel 4WD front axle, center driveline, bevel-gear final drives 4WD Front Axle Rating Not Published 1,940 lb Drawbar Capacity Not Published 1,102 lb (maximum static vertical load) ▶ Dimensions & ManeuverabilityOverall Width 64.2 in 57.3 in Wheelbase 71.1 in 62 in Ground Clearance Not Published 14 in Min. Turn Radius without Brakes Not Published 6.9 ft (with brake applied) Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 91.3 in Not Published Overall Length 130.7 in 111.2 in ▶ WeightTractor Weight (Base) ROPS: 3,638 lb; Cab: 4,068 lb 2,800 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Ag: 8-16 front, 12.4-24 rear (13.6-24 optional); turf: 27x8.50-15 front, 41x14.00-20 rear; industrial: 10-16.5 front, 17.5L-24 rear (also 250/75R16 front, 400/80R24 rear) R1 Bar, R3 Turf, R4 Industrial R1 Agricultural - Front 8-16 7-14 R1 Agricultural - Rear 12.4-24 (13.6-24 optional) 11.2-24 R3 Turf - Front 27x8.50-15 27X8.50-15 R3 Turf - Rear 41x14.00-20 Not Published R4 Industrial - Front 10-16.5 or 250/75R16 25X8.50-14 R4 Industrial - Rear 17.5L-24 or 400/80R24 15-19.5 ▶ Loader & AttachmentsQuick Attach Loader System DL125: universal skid steer or exclusive compact quick-attach implement tool carrier Quick-change attachment carrier Loader Model DL125 D160 Loader Lift Height DL125: 102.4 in (at pivot pin) 84 in (at pivot pin) Loader Lift Capacity (Full Height) DL125: 1,840 lb (at pivot pin, full height) 1,186 lb (at pivot point, maximum height) Loader Breakout Force DL125: 2,190 lb (at pivot pin) 1,704 lbf (at pivot point) ▶ WarrantyWarranty Length & Coverage 5-year powertrain warranty Basic 2 years or 2,000 hours; powertrain 6 years or 2,000 hours
