▶ EngineEngine Manufacturer Mitsubishi LS Mtron Engine Model K38 L3C19-T Engine Type 3-cylinder turbocharged and intercooled diesel 3 Cylinder, Liquid-cooled, Diesel, TC, CRDI No. of Cylinders 3 3 Displacement 101 in³ 114.7 in³ Rated Engine Speed 2500 rpm 2600 rpm Engine Power (Gross) 41.6 hp 42 hp PTO Power Gear: 32.8 hp; HST: 31.6 hp H, HC: 33.6 hp; C: 35.7 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Not Published Dry Fuel System Common rail direct injection with electronic engine management Common rail direct injection (CRDI) Alternator Not Published 70 A, 12 V ▶ HydraulicsPump Type Engine-driven gear-type pump Gear pump, engine drive Implement Flow 11.6 gpm 8.2 gpm Steering Flow 6.8 gpm H: 5.5 gpm; HC: 6.8 gpm; C: 4.1 gpm Total Hydraulic Flow Not Published H: 13.7 gpm; HC: 15.0 gpm; C: 12.3 gpm Overall Hydraulic Pump Flow Not Published H: 13.7 gpm; HC: 15.0 gpm; C: 12.3 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow 11.6 gpm Not Published No. of Standard Remote Valves 1 2 Pair (1 Detent, 1 STD) No. of Optional Remote Valves Up to 3 3 Pair (2 Detent, 1 STD) ▶ Fluid CapacityFuel Tank Capacity 14.5 gal H: 10.6 gal; HC, C: 12.4 gal Coolant Capacity Not Published 2.3 gal Crankcase Capacity Not Published 1.6 gal Transmission / Hydraulic System Capacity Not Published 11.4 gal Front Axle Fluid Capacity Not Published 2.2 gal ▶ PTO & HitchPTO Type Independent, electro-hydraulically engaged Independent PTO Rear 540 rpm (1-3/8 in 6-spline) 540 rpm Mid-PTO Availability Optional, 2000 rpm Optional (2,000 rpm) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity Not Published 2,755 lb Hitch Lift Capacity (at 24”) 2,535 lb 2,469 lb Lift Control Type Position control; draft control optional Position & Draft ▶ Transmission & DrivetrainTransmission Type 12x12 power shuttle (4 gears, 3 ranges) or 3-range electronic Servo-HST H, HC: Hydrostatic (HST); C: Synchro shuttle No. of Speeds Power shuttle: 12F / 12R; Servo-HST: 3-range infinite H, HC: Infinite, 3 ranges (HST); C: F16 x R16 Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Wet multi-disc (power shuttle) Gear: Dry single clutch; HST: Not Applicable Differential Lock & Limited Slip Options Mechanical rear differential lock, right side heel pedal Mechanical rear differential lock ▶ Chassis, Steering & ControlsFrame Type Drop-axle rear with bull gear final drives Not Published Steering Power steering, tilt steering wheel Hydrostatic Power Steering Brakes Internal wet disc brakes, individual control via independent foot pedals Wet, Multi-disc Seat Suspension & Adjustability Deluxe suspended seat with armrests and seat belt (vinyl on ROPS, cloth on cab) Not Published Front Axle Type Cast steel 4WD front axle with center drive line and bevel-gear final drives Mechanical front-wheel drive (4WD) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 130.7 in 133 in Overall Width 64.2 in 62.5 in Wheelbase 71.1 in 73.2 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes Not Published 10.3 ft (3.1 m) Height to Top of ROPS Not Published H: 95 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 91.3 in HC, C: 90 in ▶ WeightTractor Weight (Base) ROPS: 3,638 lb; Cab: 4,068 lb H: 3,935 lb; HC: 4,446 lb; C: 4,380 lb Weight with ROPS and Loader Not Published H: 4,715 lb Weight with Cab and Loader Not Published HC: 5,226 lb; C: 5,160 lb ▶ Tire OptionsTire Size & Options Ag: 8-16 front, 12.4-24 rear (13.6-24 optional); turf: 27x8.50-15 front, 41x14.00-20 rear; industrial: 10-16.5 front, 17.5L-24 rear (also 250/75R16 front, 400/80R24 rear) R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front 8-16 9.5-16 R1 Agricultural - Rear 12.4-24 (13.6-24 optional) 13.6-24 R3 Turf - Front 27x8.50-15 28x8.5-15 R3 Turf - Rear 41x14.00-20 41x14-20 R4 Industrial - Front 10-16.5 or 250/75R16 12-16.5 R4 Industrial - Rear 17.5L-24 or 400/80R24 17.5L-24 ▶ Loader & AttachmentsQuick Attach Loader System DL125: universal skid steer or compact quick-attach tool carrier LL4106, LL4001: 2 lever skid steer coupler (universal skid steer attachments) Loader Model DL125 LL4106; LL4001 Loader Lift Height DL125: 102.4 in LL4106: 94.4 in; LL4001: 104.3 in Loader Lift Capacity (Full Height) DL125: 1,840 lb LL4106: 2,680 lb; LL4001: 2,998 lb Loader Breakout Force DL125: 2,190 lb LL4106: 4,063 lb; LL4001: 4,295 lb ▶ WarrantyWarranty Length & Coverage 5-year powertrain warranty 6-year limited powertrain warranty
