▶ EngineEngine Manufacturer Mitsubishi Mahindra Engine Model K38 NE342 Engine Type 3-cylinder turbocharged and intercooled diesel Not Published No. of Cylinders 3 3 Displacement 101 in³ 146 in³ Rated Engine Speed 2500 rpm 2100 rpm Engine Power (Gross) 41.6 hp 42 hp PTO Power Gear: 32.8 hp; HST: 31.6 hp 35 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Not Published Not Published Fuel System Common rail direct injection with electronic engine management Direct injection Alternator Not Published Not Published ▶ HydraulicsPump Type Engine-driven gear-type pump Not Published Implement Flow 11.6 gpm 11 gpm Steering Flow 6.8 gpm Not Published Total Hydraulic Flow Not Published Not Published Overall Hydraulic Pump Flow Not Published Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow 11.6 gpm Not Published No. of Standard Remote Valves 1 1 No. of Optional Remote Valves Up to 3 Not Published ▶ Fluid CapacityFuel Tank Capacity 14.5 gal Not Published Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Independent, electro-hydraulically engaged 2WD: Continuous; 4WD: Independent PTO Rear 540 rpm (1-3/8 in 6-spline) 540/1000 rpm Mid-PTO Availability Optional, 2000 rpm Not Published Category, 3-Point Hitch Category I Rear Type II/I Hitch Lift Capacity Not Published 3968 lb Hitch Lift Capacity (at 24”) 2,535 lb Not Published Lift Control Type Position control; draft control optional Position and draft control ▶ Transmission & DrivetrainTransmission Type 12x12 power shuttle (4 gears, 3 ranges) or 3-range electronic Servo-HST 2WD: constant mesh; 4WD: synchromesh shuttle No. of Speeds Power shuttle: 12F / 12R; Servo-HST: 3-range infinite 2WD: 8F/2R; 4WD: 8F/8R Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Wet multi-disc (power shuttle) Not Published Differential Lock & Limited Slip Options Mechanical rear differential lock, right side heel pedal Not Published ▶ Chassis, Steering & ControlsFrame Type Drop-axle rear with bull gear final drives Two-post folding ROPS Steering Power steering, tilt steering wheel Power steering Brakes Internal wet disc brakes, individual control via independent foot pedals 2WD: dry disc; 4WD: wet disc Seat Suspension & Adjustability Deluxe suspended seat with armrests and seat belt (vinyl on ROPS, cloth on cab) Not Published Front Axle Type Cast steel 4WD front axle with center drive line and bevel-gear final drives Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 130.7 in 145.4 in Overall Width 64.2 in 67.3 in Wheelbase 71.1 in Not Published Ground Clearance Not Published Not Published Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 91.3 in Not Published ▶ WeightTractor Weight (Base) ROPS: 3,638 lb; Cab: 4,068 lb 2WD: 4752 lb; 4WD: 5742 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Ag: 8-16 front, 12.4-24 rear (13.6-24 optional); turf: 27x8.50-15 front, 41x14.00-20 rear; industrial: 10-16.5 front, 17.5L-24 rear (also 250/75R16 front, 400/80R24 rear) Not Published R1 Agricultural - Front 8-16 2WD: 6-16; 4WD: 9.5-20 R1 Agricultural - Rear 12.4-24 (13.6-24 optional) 2WD: 13.6-28; 4WD: 14.9-26 R3 Turf - Front 27x8.50-15 Not Published R3 Turf - Rear 41x14.00-20 Not Published R4 Industrial - Front 10-16.5 or 250/75R16 Not Published R4 Industrial - Rear 17.5L-24 or 400/80R24 Not Published ▶ Loader & AttachmentsQuick Attach Loader System DL125: universal skid steer or compact quick-attach tool carrier Not Published Loader Model DL125 4WD: ML245; 2WD: ML260 Loader Lift Height DL125: 102.4 in ML245: 117.4 in; ML260: 107.5 in Loader Lift Capacity (Full Height) DL125: 1,840 lb ML245: 2480 lb; ML260: 2500 lb Loader Breakout Force DL125: 2,190 lb ML245: 4400 lb; ML260: 5000 lb ▶ WarrantyWarranty Length & Coverage 5-year powertrain warranty Not Published
