▶ EngineEngine Manufacturer Mitsubishi KIOTI (Daedong) Engine Model K39 4A220T Engine Type 4-cylinder turbocharged and intercooled diesel Indirect injection, vertical, water-cooled, turbocharged 4-cycle diesel No. of Cylinders 4 4 Displacement 134.7 in³ 134.1 in³ Rated Engine Speed 2500 rpm 2600 rpm Engine Power (Gross) 53.6 hp 54 hp PTO Power Gear: 42.1 hp; HST: 40.9 hp 45.2 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Not Published High efficiency air filter with cyclone pre-cleaner canister Fuel System Common rail direct injection with electronic engine management Indirect injection Alternator Not Published 50 A, 12 V ▶ HydraulicsPump Type Engine-driven gear-type pump Tandem gear Implement Flow 11.6 gpm 9.88 gpm Steering Flow 6.8 gpm 4.33 gpm Total Hydraulic Flow Not Published 14.2 gpm Overall Hydraulic Pump Flow Not Published 14.2 gpm Hydraulic System Type Open center Not Published Rear Remote Hydraulic Flow 11.6 gpm Not Published No. of Standard Remote Valves 1 2 No. of Optional Remote Valves Up to 3 Not Published ▶ Fluid CapacityFuel Tank Capacity 14.5 gal 18.0 gal Coolant Capacity Not Published 2.51 gal Crankcase Capacity Not Published 2.25 gal Transmission / Hydraulic System Capacity Not Published 10.0 gal Front Axle Fluid Capacity Not Published 2.17 gal ▶ PTO & HitchPTO Type Independent, electro-hydraulically engaged Independent PTO Rear 540 rpm (1-3/8 in 6-spline) 540/1000 rpm Mid-PTO Availability Optional, 2000 rpm Not Published Category, 3-Point Hitch Category I Category II (Category I ends optional) Hitch Lift Capacity Not Published Not Published Hitch Lift Capacity (at 24”) 3,086 lb 2,654 lb Lift Control Type Position control; draft control optional Position, Draft and Mixed control ▶ Transmission & DrivetrainTransmission Type 12x12 power shuttle (4 gears, 3 ranges) or 3-range electronic Servo-HST Synchronized shuttle No. of Speeds Power shuttle: 12F / 12R; Servo-HST: 3-range infinite 12F/12R Max Travel Speed (Forward) Not Published 16.42 mph Max Travel Speed (Reverse) Not Published 13.59 mph Clutch Wet multi-disc (power shuttle) Dry type single plate, single stage Differential Lock & Limited Slip Options Mechanical rear differential lock, right side heel pedal Mechanical rear differential lock ▶ Chassis, Steering & ControlsFrame Type Drop-axle rear with bull gear final drives Not Published Steering Power steering, tilt steering wheel Hydrostatic power steering Brakes Internal wet disc brakes, individual control via independent foot pedals Wet disc type Seat Suspension & Adjustability Deluxe suspended seat with armrests and seat belt (vinyl on ROPS, cloth on cab) Adjustable seat Front Axle Type Cast steel 4WD front axle with center drive line and bevel-gear final drives 4WD (bevel gear front wheel drive, push-button engagement) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 132.3 in 128.6 in Overall Width 65.4 in 69.3 in Wheelbase 77.2 in 75.6 in Ground Clearance Not Published 17.5 in Min. Turn Radius without Brakes Not Published 145 in Height to Top of ROPS Not Published 106.5 in Height to Top of ROPS (folded) Not Published 85.5 in Height to Top of Cab Model 92.9 in 97.2 in ▶ WeightTractor Weight (Base) ROPS: 4,145 lb; Cab: 4,575 lb 4,795 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Ag: 9.5x16 front, 13.6x28 rear (16.9x24 optional); turf: 27x10.50-15 front, 44x18.00-20 rear; industrial: 10-16.5 front, 17.5L-24 rear (also 250/80R16 front, 360/80R28 rear) R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front 9.5-16 9.5-20 R1 Agricultural - Rear 13.6-28 (16.9-24 optional) 14.9-28 R3 Turf - Front 27x10.50-15 29x12.5-15 R3 Turf - Rear 44x18.00-20 44x18-20 R4 Industrial - Front 10-16.5 or 250/80R16 14x17.5 R4 Industrial - Rear 17.5L-24 or 360/80R28 18.4x24 ▶ Loader & AttachmentsQuick Attach Loader System DL135: universal skid steer or compact quick-attach tool carrier KL551: universal quick-attach bucket mount, 78 in QA bucket Loader Model DL135 KL551; KL1595 Loader Lift Height DL135: 110.2 in KL551: 113.58 in; KL1595: 127.52 in Loader Lift Capacity (Full Height) DL135: 2,420 lb KL551: 2,850 lb; KL1595: 2,685 lb Loader Breakout Force DL135: 2,860 lb KL551: 4,675 lb; KL1595: 4,500 lb ▶ WarrantyWarranty Length & Coverage 5-year powertrain warranty Limited: Tractors (Non-Commercial Application) 24 months parts & labor; Extended (driveline): 48 months parts & labor ▶ ITC Company AccessoriesAccessories that fit None tagged yet
