▶ EngineEngine Manufacturer Shibaura FPT Engine Model N4LDI-TA R 753 IE4 Engine Type 4-cylinder turbocharged intercooled diesel, liquid-cooled 3-cylinder, FPT turbocharged & aftercooled No. of Cylinders 4 3 Displacement 135.2 in³ 135.9 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 59.9 hp 60 hp PTO Power Mech: 46.1 hp; HST: 44.4 hp 51 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dry Dry Fuel System Common rail direct injection Electronic high pressure common rail Alternator Not Published 75 A ▶ HydraulicsPump Type Engine-driven gear-type pump Engine-driven dual gear-type Implement Flow Not Published 11.9 gpm Steering Flow Not Published 5.5 gpm Total Hydraulic Flow Not Published 17.4 gpm (11.9 + 5.5, computed) Overall Hydraulic Pump Flow 12x12 Power Shuttle: 12.7 gpm; HST: 12.6 gpm Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow 12.1 gpm Not Published No. of Standard Remote Valves Not Published 1 No. of Optional Remote Valves Up to 3 2 ▶ Fluid CapacityFuel Tank Capacity 14 gal 17.2 gal Coolant Capacity 7.08 qt Not Published Crankcase Capacity 6.87 qt Not Published Transmission / Hydraulic System Capacity Power Shuttle: 11.35 gal; HST: 9.25 gal Not Published Front Axle Fluid Capacity 9 qt Not Published ▶ PTO & HitchPTO Type Independent, with soft-start feature Independent PTO Rear 540 rpm (6-spline) 540 / 540E Mid-PTO Availability Optional, 2,000 rpm (not offered with the 12x12 power shuttle) Not Published Category, 3-Point Hitch Category I with extendable ball ends Category I/II Hitch Lift Capacity Not Published Not Published Hitch Lift Capacity (at 24”) 12x12 Power Shuttle: 3,307 lb; HST: 3,086 lb 2,701 lb Lift Control Type Draft control optional Mechanical Draft Control (MDC), top link sensing ▶ Transmission & DrivetrainTransmission Type 12 x 12 power shuttle or 3-range hydrostatic 8x8 mechanical shuttle (dry clutch) No. of Speeds 12 x 12 Power Shuttle (3 ranges, 4 gears); HST: 3-range, infinite speeds in each range 8F/8R Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Multiple stage wet type Dry clutch Differential Lock & Limited Slip Options Mechanical engagement via right side heel pedal Mechanical rear differential lock; MFD engagement mechanical; limited-slip MFD front axle ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Hydrostatic Brakes Internal wet disc brakes, independent foot pedals Wet disc Seat Suspension & Adjustability Suspended seat with armrests and seat belts (vinyl on ROPS, cloth on cab), tilt steering Contoured seat, adjustable Front Axle Type Cast-steel 4WD front axle, center driveline, bevel-gear final drives 2WD or MFD with limited slip Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 12x12 Power Shuttle: 71.1 in; HST: 65.4 in 67.5 in Wheelbase 12x12 Power Shuttle: 80.3 in; HST: 77.9 in 2WD: 77.5 in; MFD: 77.7 in Ground Clearance 14.8 in Not Published Min. Turn Radius without Brakes Not Published 2WD: 135.8 in; MFD: 190.9 in Height to Top of ROPS 12x12 Power Shuttle: 103.2 in; HST: 102.4 in 2WD: 92.7 in; MFD: 97.4 in Height to Top of ROPS (folded) Not Published 77 in Height to Top of Cab Model 12x12 Power Shuttle: 93.3 in; HST: 92.9 in Not Published Overall Length HST: 132.3 in 2WD: 129.5 in; MFD: 134.0 in ▶ WeightTractor Weight (Base) 12x12 Power Shuttle: 4,233 lb (ROPS base weight) 2WD: 4,442 lb; MFD: 5,060 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options AG, Turf, Industrial, Snow R1 (bar tread) 2WD or MFD; R4 (industrial tread) MFD R1 Agricultural - Front 9.5x16 2WD: 7.5x16; MFD: 8.3x24 R1 Agricultural - Rear 16.9x26 13.6x28 R3 Turf - Front 27x10.50-15 Not Published R3 Turf - Rear 44x18.00-20 Not Published R4 Industrial - Front 12-16.5 MFD: 12.5x18 R4 Industrial - Rear 18.4-24 MFD: 18.4x24 ▶ Loader & AttachmentsQuick Attach Loader System DL135: Skid steer quick attach Compatible loaders: L545, L555 Loader Model DL135 L545; L555 Loader Lift Height DL135: 111 in (at pivot pin) L545: 106 in; L555: 105 in Loader Lift Capacity (Full Height) DL135: 2,610 lb (at pivot pin, full height) L545 NSL: 1,565 lb; L545 MSL: 2,205 lb; L555 NSL: 1,940 lb; L555 MSL: 2,734 lb Loader Breakout Force DL135: 4,000 lb (at pivot pin) L545: 3,131 lb; L555: 3,527 lb ▶ WarrantyWarranty Length & Coverage Five-year powertrain warranty Not Published
