▶ EngineEngine Manufacturer Shibaura Simpson Engine Model Shibaura N4LDI-TA SJV326 Engine Type 4-cylinder turbocharged intercooled diesel, liquid-cooled 3-cylinder, turbocharged, intercooled, liquid-cooled diesel No. of Cylinders 4 3 Displacement 135.2 in³ 157.9 in³ Rated Engine Speed 2600 rpm 2000 rpm Engine Power (Gross) 59.9 hp 55 hp PTO Power 46.1 hp 46 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid cooled Air Cleaner Dry Not Published Fuel System Common rail direct injection Electronically controlled high-pressure common rail Alternator Not Published Not Published ▶ HydraulicsPump Type Engine-driven gear-type pump Mark 1A scotch yoke piston pump Implement Flow Not Published Not Published Steering Flow Not Published Not Published Total Hydraulic Flow Not Published 15.7 gpm Overall Hydraulic Pump Flow 12x12 Power Shuttle: 12.7 gpm; HST: 12.6 gpm 15.7 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow 12.1 gpm 10.6 gpm No. of Standard Remote Valves Not Published 1 No. of Optional Remote Valves Up to 3 Not Published ▶ Fluid CapacityFuel Tank Capacity 14.0 gal 14.5 gal Coolant Capacity 7.08 qt 4 gal Crankcase Capacity 6.87 qt 2.5 gal Transmission / Hydraulic System Capacity 12x12 Power Shuttle: 11.35 gal; HST: 9.25 gal 10.5 gal Front Axle Fluid Capacity 9.0 qt 4WD: 1.5 gal differential, plus 0.23 gal per wheel end ▶ PTO & HitchPTO Type Independent, with soft-start feature 2WD: Live; 4WD: Independent PTO Rear 540 rpm (1-3/8 in 6-spline) 540 rpm, 6-spline Mid-PTO Availability Optional, 2,000 rpm (not offered with the 12x12 power shuttle) Not Published Category, 3-Point Hitch Category I with extendable ball ends Category I and II Hitch Lift Capacity Not Published 4,519 lb Hitch Lift Capacity (at 24”) 12x12 Power Shuttle: 3,307 lb; HST: 3,086 lb 2,755 lb Lift Control Type Position and draft control Draft, position and response control ▶ Transmission & DrivetrainTransmission Type 12 x 12 power shuttle or 3-range hydrostatic 2WD: 8F x 2R SideShift sliding gear; 4WD: 8F x 8R synchro shuttle No. of Speeds 12x12 Power Shuttle: 12F / 12R; HST: 3-range infinite 2WD: 8 forward and 2 reverse; 4WD: 8 forward and 8 reverse Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Multiple stage wet type 2WD: dual stage dry; 4WD: split torque Differential Lock & Limited Slip Options Mechanical engagement via right side heel pedal Mechanical engagement via right-side heel pedal ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Hydrostatic power steering with separate reservoir Brakes Internal wet disc brakes, individual control via independent foot pedals Oil-immersed wet disc Seat Suspension & Adjustability Deluxe suspended seat with armrests and seatbelts (vinyl seat on ROPS, cloth seat on cab), tilt steering ReverseRise adjustable seat with fixed steering column Front Axle Type Cast steel 4WD front axle with center drive line and bevel-gear final drives 2WD: straight, telescopically adjustable; 4WD: heavy-duty planetary reduction Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 12x12 Power Shuttle: 170.1 in; HST: 132.3 in 2WD: 138 in; 4WD: 139 in Overall Width 12x12 Power Shuttle: 71.1 in; HST: 65.4 in 66.5 in Wheelbase 12x12 Power Shuttle: 80.3 in; HST: 77.9 in 2WD: 80.7 in; 4WD: 81.5 in Ground Clearance 14.8 in Not Published Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS 12x12 Power Shuttle: 103.2 in; HST: 102.4 in 91.3 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 12x12 Power Shuttle: 93.3 in; HST: 92.9 in Not Published ▶ WeightTractor Weight (Base) 12x12 Power Shuttle: 4,233 lb 2WD: 4,894 lb; 4WD: 5,394 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial 2WD standard (ag): 6.00x16 front, 13.6x28 rear; 2WD optional (ag): 7.5x16 front, 16.6x28 rear; 4WD standard (ag): 9.5x24 front, 14.9x28 rear; 4WD industrial: 10.5/80-18 front with 14.9x24 rear, or 12.5/80-18 front with 16.9x24 rear R1 Agricultural - Front 9.5x16 2WD: 6.00x16 (7.5x16 optional); 4WD: 9.5x24 R1 Agricultural - Rear 16.9x26 2WD: 13.6x28 (16.6x28 optional); 4WD: 14.9x28 R3 Turf - Front 27x10.50-15 Not Published R3 Turf - Rear 44x18.00-20 Not Published R4 Industrial - Front 12-16.5 4WD: 10.5/80-18 or 12.5/80-18 R4 Industrial - Rear 18.4-24 4WD: 14.9x24 or 16.9x24 ▶ Loader & AttachmentsQuick Attach Loader System DL135: Skid steer quick attach Skid steer style coupling Loader Model DL135 FLx2815 (2WD); 911X (4WD) Loader Lift Height DL135: 111 in FLx2815: 111 in; 911X: 114 in Loader Lift Capacity (Full Height) DL135: 2,610 lb FLx2815: 2,810 lb; 911X: 2,470 lb Loader Breakout Force DL135: 4,000 lb FLx2815: 4,240 lb; 911X: 2,755 lb ▶ WarrantyWarranty Length & Coverage 5-year powertrain warranty 5-year powertrain warranty
